Marantz DV7001 - Page 68

94
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.W.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
K003 00MZK30AK0030 00MZK30AK0030 PWB ASSY PCB ASSY PSU06P30 867000029882
K004 00MZK30AK0040 00MZK30AK0040 PWB ASSY PCB ASSY RS232C BOARD 876000029883
L002 117010005009S 117010005009S FERRITE CORE TFCK-23-11-14 KITAGAWA
L003 117010005009S 117010005009S FERRITE CORE TFCK-23-11-14 KITAGAWA
L004 1170100010070 1170100010070 FERRITE CORE FERRITE CORE TFCK-16813
M001 00M30AK304010 00M30AK304010 MECHANISM
MECHA LOADER AND TRAVERSE
PHILIPS 867000029878
P801 ns
p
ns
p
PWB ASSY POWER PWB ASSY
PA01 ns
p
ns
p
PWB ASSY AUDIO PWB ASSY
PF01 ns
p
ns
p
PWB ASSY FRONT PWB ASSY
PF02 ns
p
ns
p
PWB ASSY HDMI/AUDIO EX LED PWB ASSY
PF03 ns
p
ns
p
PWB ASSY STANDBY LED PWB ASSY
PF04 ns
p
ns
p
PWB ASSY POWER SW PWB ASSY
PV01 ns
p
ns
p
PWB ASSY VIDEO PWB ASSY
W304 ns
p
00MYU30240520 FPC SMCD-30X240-BDX8
(
BL
)
-P1.0-S4-MUL2896
WD03 ns
p
00MYU12250520 FPC SMCD-12X250-BDX8
(
BL
)
-P1.0-S4-MUL2896
WD04 ns
p
00MYU11120520 FPC SMCD-11X120-BDX6
(
BL
)
-P1.0-S4-M
WF03 ns
p
00MYU09120520 FPC SMCD-9X120-BDX8
(
BL
)
-P1.0-S4-MUL2896
WV11 ns
p
00MYU13100520 FPC SMCD-13X100-BDX6-P1.0-S4.0+4.0-M UL2896
WV12 ns
p
00MYU07140520 FPC SMCD-7X140-BDX8
(
BL
)
-P1.0-S4-MUL2896
WV13 ns
p
00MYU16320520 FPC SMCD-16X320-BDX8
(
BL
)
-P1.0-S4-MUL2896
WV14 ns
p
00MYU30350520 FPC SMCD-30X350-BDX8
(
BL
)
-P1.0-S4-MUL2896
WV15 ns
p
00MYU17100520 FPC SMCD-17X100-BDX6
(
BL
)
-P1.0-S4-M
PACKING
005T F N ns
p
00M30AK851110 USER GUIDE USER MANUAL DV7001 F
005T
/
K1G ns
p
00M30AK851350 USER GUIDE USER MANUAL DV7001 K
005T
/
N1B 00M30AK851310 00M30AK851310 USER GUIDE USER MANUAL DV7001 N
005T
/
N1S 00M30AK851310 00M30AK851310 USER GUIDE USER MANUAL DV7001 N
005T
/
U1B ns
p
00M30AK851250 USER GUIDE USER MANUAL DV7001 U
001Z 00MZK20CW0010 00MZK20CW0010 UNIT KIT REMOTE CONTROLLER RC001DV
W001 F N ns
p
00MZC01802080 MAINS CORD # MAINS CORD DC-316-N01
W001
/
K1G ns
p
00MZC01808030 MAINS CORD # MAINS CORD CHINA 250V 10A
W001
/
N1B 0110500020010 0110500020010 MAINS CORD # MAINS CORD 970304/1 EUROPEAN
W001
/
N1S 0110500020010 0110500020010 MAINS CORD # MAINS CORD 970304/1 EUROPEAN
W001
/
U1B ns
p
611050010006S MAINS CORD # MAINS CORD UL/CSA 10A 125V
NOT STANDARD SPARE PART
005S ns
p
00M28AK809010 CUSHION CUSHION
(
L R
)
SA7001
010S ns
p
00M30AK801010 PACKING CASE PACKING CASE DV7001
111D F N ns
p
00M14AJ257120 LID TOP COVER GL SLIT LESS
111D
/
K1G ns
p
00M14AJ257120 LID TOP COVER GL SLIT LESS
111D
/
N1B ns
p
00M14AJ257020 LID TOP COVER BL SLIT LESS
111D
/
N1S ns
p
00M14AJ257220 LID TOP COVER SL SLIT LESS
111D
/
U1B ns
p
00M14AJ257020 LID TOP COVER BL SLIT LESS
003Z ns
p
00MZD01500410 CONN. CORD YAF11-0745N 3PIN RCA
(
VIDEO&L/R
)
1.5M
004Z ns
p
605010002002S CONN. CORD TWIN SHIELDED WIRE WITH RCA PLUGS
