Marantz DV7001 - Page 76

102
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.W.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POWER PWB P801
(
00MWG30AK202-
)
P801 C844 00MDF77103500 00MDF77103500 FILM CAP. 0.01UF M 250V AC
P801 C851 00MOB10803540 00MOB10803540 ELECT. CAP. LAO-35V102MS35P1W# 1000UF 35V
(
LF
)
P801 C852 00MOB10803540 00MOB10803540 ELECT. CAP. LAO-35V102MS35P1W# 1000UF 35V
(
LF
)
P801 C853 ns
p
00D2570512903 CER. CAP CK73F1E104ZT +1608
P801 C854 ns
p
00D2570512903 CER. CAP CK73F1E104ZT +1608
P801 C855 F N ns
p
134050028401S ELECT CAP ROS-16V221MH5#PE-T2
P801 C855
/
K1G ns
p
134050026405S ELECT CAP ROA-16V221MH4#-T2
P801 C855
/
N1B 134050028401S 134050028401S ELECT CAP ROS-16V221MH5#PE-T2
P801 C855
/
N1S 134050028401S 134050028401S ELECT CAP ROS-16V221MH5#PE-T2
P801 C855
/
U1B ns
p
134050026405S ELECT CAP ROA-16V221MH4#-T2
P801 C856 F N ns
p
134050028401S ELECT CAP ROS-16V221MH5#PE-T2
P801 C856
/
K1G ns
p
134050026405S ELECT CAP ROA-16V221MH4#-T2
P801 C856
/
N1B 134050028401S 134050028401S ELECT CAP ROS-16V221MH5#PE-T2
P801 C856
/
N1S 134050028401S 134050028401S ELECT CAP ROS-16V221MH5#PE-T2
P801 C856
/
U1B ns
p
134050026405S ELECT CAP ROA-16V221MH4#-T2
P801 C857 ns
p
00D2570512903 CER. CAP CK73F1E104ZT +1608
P801 C858 ns
p
00D2570512903 CER. CAP CK73F1E104ZT +1608
P801 C861 134010162006S 134010162006S ELECT CAP RA2-16V222MI6#8-S1
P801 C862 1340100215010 1340100215010 ELECT CAP RA2-10V221MF3#8-T2
P801 C863 00MOA10701020 00MOA10701020 ELECT. CAP. 100 UF M 10V RA-2
P801 C864 ns
p
00D2570512903 CER. CAP CK73F1E104ZT +1608
P801 C865 ns
p
00D2570512903 CER. CAP CK73F1E104ZT +1608
P801 C866 ns
p
00D2570512903 CER. CAP CK73F1E104ZT +1608
P801 C871 134010161003S 134010161003S ELECT CAP RA2-25V102MI5#8-S1
P801 C872 00MOA22405020 00MOA22405020 ELECT. CAP. 0.22 UF M 50V RA-2
P801 C873 00MOA10606320 00MOA10606320 ELECT. CAP. 10 UF 63V RA-2
P801 C874 00MOA10701020 00MOA10701020 ELECT. CAP. 100 UF M 10V RA-2
P801 D845 00MHD20029050 00MHD20029050 DIODE S5688G
(
TPA3,Q
)
P801 D851 00MHD20029050 00MHD20029050 DIODE S5688G
(
TPA3,Q
)
P801 D852 00MHD20029050 00MHD20029050 DIODE S5688G
(
TPA3,Q
)
P801 D853 00MHD20029050 00MHD20029050 DIODE S5688G
(
TPA3,Q
)
P801 D854 00MHD20029050 00MHD20029050 DIODE S5688G
(
TPA3,Q
)
P801 D871 00MHD20029050 00MHD20029050 DIODE S5688G
(
TPA3,Q
)
P801 D872 00MHD20029050 00MHD20029050 DIODE S5688G
(
TPA3,Q
)
P801 D873 00MHD20029050 00MHD20029050 DIODE S5688G
(
TPA3,Q
)
P801 D874 00MHD20029050 00MHD20029050 DIODE S5688G
(
TPA3,Q
)
P801 D875 00MHD20029050 00MHD20029050 DIODE S5688G
(
TPA3,Q
)
P801 D876 00MHD20029050 00MHD20029050 DIODE S5688G
(
TPA3,Q
)
P801 D877 00MHD20029050 00MHD20029050 DIODE S5688G
(
TPA3,Q
)
P801 D878 00MHD20029050 00MHD20029050 DIODE S5688G
(
TPA3,Q
)
P801 D879 00MHD20029050 00MHD20029050 DIODE S5688G
(
TPA3,Q
)
P801 F801 00MFS20250200 00MFS20250200 FUSE # T2.5A/250V TR5 NO.19372
(
T
P801 F851 00MFS20050200 00MFS20050200 FUSE # T500MA/250V TR5 NO.19372
(
TP
)
P801 F852 00MFS20050200 00MFS20050200 FUSE # T500MA/250V TR5 NO.19372
(
TP
)
P801 F854 00MFS20050200 00MFS20050200 FUSE # T500MA/250V TR5 NO.19372
(
TP
)
P801 L001 117010002000S 117010002000S FERRITE CORE TRCN-28-16-20
P801 L841 00MLY10060010 00MLY10060010 RELAY #SDT-S-106LMR TV-5 DC6V 250MW
P801 Q841 00MHT10001000 00MHT10001000 TRS. A1048,A933S,A1267,ETC.
P801 Q842 216450001502S 216450001502S TRS. DTC114EUA
P801 Q843 216450001502S 216450001502S TRS. DTC114EUA
P801 Q853 00D2631100063 00D2631100063 IC KIA7809API-U/P
P801 Q854 00D2631099048 00D2631099048 IC KIA7909PI
P801 Q861 00MHC3690521F 00MHC3690521F IC BA05T 5V/1A TO220
P801 Q862 00MHC36J3321F 00MHC36J3321F IC BA033T +3.3V 1A TYPE
P801 Q871 214050003506S 214050003506S TRS. 2SC4081
(
Q_R
)(
312000451210
)
P801 Q872 214050003506S 214050003506S TRS. 2SC4081
(
Q_R
)(
312000451210
)
P801 Q874 212050002507S 212050002507S TRS. 2SA1586
(
Y_GR
)
TE85L
P801 Q875 216450001502S 216450001502S TRS. DTC114EUA
P801 R821 F N ns
p
00D2472018903 CHIP RES. RM73B--0R0KT +1608
P801 R822
/
U1B ns
p
00D2472018903 CHIP RES. RM73B--0R0KT +1608
P801 R823
/
K1G ns
p
00D2472018903 CHIP RES. RM73B--0R0KT +1608
P801 R823
/
N1B ns
p
00D2472018903 CHIP RES. RM73B--0R0KT +1608
P801 R823
/
N1S ns
p
00D2472018903 CHIP RES. RM73B--0R0KT +1608
P801 R841 ns
p
00D2472011942 CHIP RES. RM73B--473JT +1608
P801 R842 ns
p
00D2472009909 CHIP RES. RM73B--472JT +1608
P801 R843 ns
p
00D2472009983 CHIP RES. RM73B--103JT +1608
POS. NO.
