Marantz DV7001 - Page 81

107
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.W.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
PA01 QH71 222010001404S 222010001404S F.E.T. 2SK369 BL VGDS-40V PD0.4W
PA01 QH72 222010001404S 222010001404S F.E.T. 2SK369 BL VGDS-40V PD0.4W
PA01 QH73 00MHX328731B0 00MHX328731B0 CHIP TRS. 2SC2873
(
Y
)
PA01 QH74 00MHX113121B0 00MHX113121B0 CHIP TRS. 2SA1312
(
B
)
PA01 QH75 00MHX113121B0 00MHX113121B0 CHIP TRS. 2SA1312
(
B
)
PA01 QH76 00MHX333241B0 00MHX333241B0 CHIP TRS. 2SC3324
(
B
)
PA01 QS01 213050005400S 213050005400S TRS. 2SC2240N-GR_BL
(
932202943676
)
PA01 QS02 211050004401S 211050004401S TRS. 2SA970
(
GR
)
OR
(
BL
)
TOSHIBA
PA01 QS04 00MBA20016050 00MBA20016050 TRS. HN1C03F
(
B
)(
NPNX2
(
MUTING
))
PA01 QS08 216450001502S 216450001502S TRS. DTC114EUA
PA01 QS09 00MBA10026210 00MBA10026210 TRS. DTA114EU
PA01 QS31 213050005400S 213050005400S TRS. 2SC2240N-GR_BL
(
932202943676
)
PA01 QS32 211050004401S 211050004401S TRS. 2SA970
(
GR
)
OR
(
BL
)
TOSHIBA
PA01 QS34 00MBA20016050 00MBA20016050 TRS. HN1C03F
(
B
)(
NPNX2
(
MUTING
))
PA01 QS38 216450001502S 216450001502S TRS. DTC114EUA
PA01 QS39 00MBA10026210 00MBA10026210 TRS. DTA114EU
PA01 QX01 213050005400S 213050005400S TRS. 2SC2240N-GR_BL
(
932202943676
)
PA01 QX02 211050004401S 211050004401S TRS. 2SA970
(
GR
)
OR
(
BL
)
TOSHIBA
PA01 QX04 00MBA20016050 00MBA20016050 TRS. HN1C03F
(
B
)(
NPNX2
(
MUTING
))
PA01 QX05 00MBA20016050 00MBA20016050 TRS. HN1C03F
(
B
)(
NPNX2
(
MUTING
))
PA01 QX08 216450001502S 216450001502S TRS. DTC114EUA
PA01 QX09 00MBA10026210 00MBA10026210 TRS. DTA114EU
PA01 QX31 213050005400S 213050005400S TRS. 2SC2240N-GR_BL
(
932202943676
)
PA01 QX32 211050004401S 211050004401S TRS. 2SA970
(
GR
)
OR
(
BL
)
TOSHIBA
PA01 QX33 00MBA20016050 00MBA20016050 TRS. HN1C03F
(
B
)(
NPNX2
(
MUTING
))
PA01 QX34 00MBA20016050 00MBA20016050 TRS. HN1C03F
(
B
)(
NPNX2
(
MUTING
))
PA01 QX38 216450001502S 216450001502S TRS. DTC114EUA
PA01 QX39 00MBA10026210 00MBA10026210 TRS. DTA114EU
PA01 RA01 00D2470009901 00D2470009901 CHIP RES. RM73B--472JT +2125
PA01 RA02 00D2470009901 00D2470009901 CHIP RES. RM73B--472JT +2125
PA01 RA03 00D2470008928 00D2470008928 CHIP RES. RM73B--222JT +2125
PA01 RA04 00D2470008928 00D2470008928 CHIP RES. RM73B--222JT +2125
PA01 RA05 00D2470008928 00D2470008928 CHIP RES. RM73B--222JT +2125
PA01 RA06 00D2470008928 00D2470008928 CHIP RES. RM73B--222JT +2125
PA01 RA07 00D2470010903 00D2470010903 CHIP RES. RM73B--123JT +2125
PA01 RA08 00D2470010903 00D2470010903 CHIP RES. RM73B--123JT +2125
PA01 RA09 00D2470010903 00D2470010903 CHIP RES. RM73B--123JT +2125
PA01 RA10 00D2470010903 00D2470010903 CHIP RES. RM73B--123JT +2125
PA01 RA11 ns
p
1210100094060 RES. CFPS1/4CMHTA100J
PA01 RA12 ns
p
1210100094060 RES. CFPS1/4CMHTA100J
PA01 RA13 00D2470010929 00D2470010929 CHIP RES. RM73B--153JT +2125
PA01 RA14 00D2470004964 00D2470004964 CHIP RES. RM73B--680JT +2125
PA01 RA15 00D2470004964 00D2470004964 CHIP RES. RM73B--680JT +2125
PA01 RA16 00D2470010929 00D2470010929 CHIP RES. RM73B--153JT +2125
PA01 RA17 ns
p
00D2472013908 CHIP RES. RM73B--224JT +1608
PA01 RA18 ns
p
00D2472008926 CHIP RES. RM73B--222JT +1608
PA01 RA19 ns
p
00D2472008926 CHIP RES. RM73B--222JT +1608
PA01 RA20 00D2470004964 00D2470004964 CHIP RES. RM73B--680JT +2125
PA01 RA26 ns
p
00D2472007943 CHIP RES. RM73B--102JT +1608
PA01 RA31 00D2470009901 00D2470009901 CHIP RES. RM73B--472JT +2125
PA01 RA32 00D2470009901 00D2470009901 CHIP RES. RM73B--472JT +2125
PA01 RA33 00D2470008928 00D2470008928 CHIP RES. RM73B--222JT +2125
PA01 RA34 00D2470008928 00D2470008928 CHIP RES. RM73B--222JT +2125
PA01 RA35 00D2470008928 00D2470008928 CHIP RES. RM73B--222JT +2125
PA01 RA36 00D2470008928 00D2470008928 CHIP RES. RM73B--222JT +2125
PA01 RA37 00D2470010903 00D2470010903 CHIP RES. RM73B--123JT +2125
PA01 RA38 00D2470010903 00D2470010903 CHIP RES. RM73B--123JT +2125
PA01 RA39 00D2470010903 00D2470010903 CHIP RES. RM73B--123JT +2125
PA01 RA40 00D2470010903 00D2470010903 CHIP RES. RM73B--123JT +2125
PA01 RA41 ns
p
1210100094060 RES. CFPS1/4CMHTA100J
PA01 RA42 ns
p
1210100094060 RES. CFPS1/4CMHTA100J
PA01 RA43 00D2470010929 00D2470010929 CHIP RES. RM73B--153JT +2125
PA01 RA44 00D2470004964 00D2470004964 CHIP RES. RM73B--680JT +2125
PA01 RA45 00D2470004964 00D2470004964 CHIP RES. RM73B--680JT +2125
PA01 RA46 00D2470010929 00D2470010929 CHIP RES. RM73B--153JT +2125
PA01 RA47 ns
p
00D2472013908 CHIP RES. RM73B--224JT +1608
PA01 RA48 ns
p
00D2472008926 CHIP RES. RM73B--222JT +1608
