Marantz DV7001 - Page 87

113
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.W.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
PF01 RF37 ns
p
00D2472007943 CHIP RES. RM73B--102JT +1608
PF01 RF38 ns
p
00D2472009983 CHIP RES. RM73B--103JT +1608
PF01 RF39 ns
p
00D2472009983 CHIP RES. RM73B--103JT +1608
PF01 RF40 ns
p
00D2472003947 CHIP RES. RM73B--220JT +1608
PF01 RF41 ns
p
00D2472003947 CHIP RES. RM73B--220JT +1608
PF01 RF42 ns
p
00D2472011942 CHIP RES. RM73B--473JT +1608
PF01 RF43 ns
p
00D2472003947 CHIP RES. RM73B--220JT +1608
PF01 RF45 ns
p
00D2472009983 CHIP RES. RM73B--103JT +1608
PF01 RF46 ns
p
00D2472009983 CHIP RES. RM73B--103JT +1608
PF01 RF49 ns
p
00D2472003947 CHIP RES. RM73B--220JT +1608
PF01 RF50 ns
p
00D2472003947 CHIP RES. RM73B--220JT +1608
PF01 RF51 ns
p
00D2472018903 CHIP RES. RM73B--0R0KT +1608
PF01 RF52 ns
p
00D2472009941 CHIP RES. RM73B--682JT +1608
PF01 RF53 ns
p
00D2472003947 CHIP RES. RM73B--220JT +1608
PF01 RF54 ns
p
00D2472003947 CHIP RES. RM73B--220JT +1608
PF01 RF55 ns
p
00D2472018903 CHIP RES. RM73B--0R0KT +1608
PF01 RF56 ns
p
00D2472018903 CHIP RES. RM73B--0R0KT +1608
PF01 RF57 ns
p
00D2472006902 CHIP RES. RM73B--331JT +1608
PF01 RF58 ns
p
00D2472006902 CHIP RES. RM73B--331JT +1608
PF01 SF01 662010001408S 662010001408S SW SKHVBF F0052759M
PF01 SF02 662010001408S 662010001408S SW SKHVBF F0052759M
PF01 SF03 662010001408S 662010001408S SW SKHVBF F0052759M
PF01 SF04 662010001408S 662010001408S SW SKHVBF F0052759M
PF01 SF05 662010001408S 662010001408S SW SKHVBF F0052759M
PF01 SF06 662010001408S 662010001408S SW SKHVBF F0052759M
PF01 SF07 662010001408S 662010001408S SW SKHVBF F0052759M
PF01 SF08 662010001408S 662010001408S SW SKHVBF F0052759M
PF01 VF01 172010001004M 172010001004M DISPLAY CH2163C
PF01 XF01 00MJX16006350 00MJX16006350 X'TAL 16MHZ XTAL SX-1319
PF01 ZF01 2620100010060 2620100010060 PHOTO UNIT RPM6936-V4
(
IR SENSOR
)
HDMI/AUDIO EX LED PWB PF02
(
00MWG30AK103-
)
PF02 DF01 2630100010090 2630100010090 L.E.D. LT3D8B RED LED
PF02 DF02 2630100010090 2630100010090 L.E.D. LT3D8B RED LED
STANDBY LED PWB PF03
(
00MWG30AK104-
)
PF03 DF03 2630100010090 2630100010090 L.E.D. LT3D8B RED LED
POWER SW PWB PF04
(
00MWG30AK105-
)
PF04 S801 0610500020060 0610500020060 SW ESB92S17B TV-5 STROKE=1.5MM
VIDEO PWB PV01
(
00MWG30AK201-
)
PV01 CE01
/
N1B 00MOA10701020 00MOA10701020 ELECT. CAP. 100 UF M 10V RA-2
PV01 CE01
/
N1S 00MOA10701020 00MOA10701020 ELECT. CAP. 100 UF M 10V RA-2
PV01 CE02
/
N1B ns
p
00D2570512903 CER. CAP CK73F1E104ZT +1608
PV01 CE02
/
N1S ns
p
00D2570512903 CER. CAP CK73F1E104ZT +1608
PV01 CE03
/
N1B ns
p
00D2570512903 CER. CAP CK73F1E104ZT +1608
PV01 CE03
/
N1S ns
p
00D2570512903 CER. CAP CK73F1E104ZT +1608
PV01 CE04
/
N1B 00MOA10606320 00MOA10606320 ELECT. CAP. 10 UF 63V RA-2
PV01 CE04
/
N1S 00MOA10606320 00MOA10606320 ELECT. CAP. 10 UF 63V RA-2
PV01 CE05
/
N1B ns
p
00D2570512903 CER. CAP CK73F1E104ZT +1608
PV01 CE05
/
N1S ns
p
00D2570512903 CER. CAP CK73F1E104ZT +1608
PV01 CE06
/
N1B 1340100715060 1340100715060 ELECT CAP RA2-50V220ME3#8-T2
PV01 CE06
/
N1S 1340100715060 1340100715060 ELECT CAP RA2-50V220ME3#8-T2
PV01 CE07
/
N1B 00MOA10606320 00MOA10606320 ELECT. CAP. 10 UF 63V RA-2
PV01 CE07
/
N1S 00MOA10606320 00MOA10606320 ELECT. CAP. 10 UF 63V RA-2
PV01 CE08
/
N1B 00MOA10606320 00MOA10606320 ELECT. CAP. 10 UF 63V RA-2
PV01 CE08
/
N1S 00MOA10606320 00MOA10606320 ELECT. CAP. 10 UF 63V RA-2
PV01 CE09
/
N1B 00MOA10606320 00MOA10606320 ELECT. CAP. 10 UF 63V RA-2
PV01 CE09
/
N1S 00MOA10606320 00MOA10606320 ELECT. CAP. 10 UF 63V RA-2
PV01 CE10
/
N1B 1340100235070 1340100235070 ELECT CAP RA2-10V471MG3#8-T2
PV01 CE10
/
N1S 1340100235070 1340100235070 ELECT CAP RA2-10V471MG3#8-T2
PV01 CE11
/
N1B 1340100235070 1340100235070 ELECT CAP RA2-10V471MG3#8-T2
PV01 CE11
/
N1S 1340100235070 1340100235070 ELECT CAP RA2-10V471MG3#8-T2
PV01 CE12
/
N1B 1340100235070 1340100235070 ELECT CAP RA2-10V471MG3#8-T2
PV01 CE12
/
N1S 1340100235070 1340100235070 ELECT CAP RA2-10V471MG3#8-T2
PV01 CE13
/
N1B 00MOA10800620 00MOA10800620 ELECT. CAP. 1000UF 6.3V M RA-2
PV01 CE13
/
N1S 00MOA10800620 00MOA10800620 ELECT. CAP. 1000UF 6.3V M RA-2
PV01 CE14
/
N1B 00MOA10701020 00MOA10701020 ELECT. CAP. 100 UF M 10V RA-2
PV01 CE14
/
N1S 00MOA10701020 00MOA10701020 ELECT. CAP. 100 UF M 10V RA-2
PV01 CE15
/
N1B ns
p
00D2570512903 CER. CAP CK73F1E104ZT +1608
