Marantz DV7001 - Page 89

115
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.W.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
PV01 CV15 1340100715060 1340100715060 ELECT CAP RA2-50V220ME3#8-T2
PV01 CV16 00MOA10701020 00MOA10701020 ELECT. CAP. 100 UF M 10V RA-2
PV01 CV17 1340100715060 1340100715060 ELECT CAP RA2-50V220ME3#8-T2
PV01 CV18 00MOA10701020 00MOA10701020 ELECT. CAP. 100 UF M 10V RA-2
PV01 CV19 1340100715060 1340100715060 ELECT CAP RA2-50V220ME3#8-T2
PV01 CV20 00MOA10701020 00MOA10701020 ELECT. CAP. 100 UF M 10V RA-2
PV01 CV21 ns
p
00D2570512903 CER. CAP CK73F1E104ZT +1608
PV01 CV22
/
N1B ns
p
00D2570512903 CER. CAP CK73F1E104ZT +1608
PV01 CV22
/
N1S ns
p
00D2570512903 CER. CAP CK73F1E104ZT +1608
PV01 CV31 ns
p
00D2570512903 CER. CAP CK73F1E104ZT +1608
PV01 CY91 F N ns
p
00D2570512903 CER. CAP CK73F1E104ZT +1608
PV01 CY92 F N ns
p
00D2570512903 CER. CAP CK73F1E104ZT +1608
PV01 JE01
/
N1B 00MYT02210100 00MYT02210100 TERMINAL AJ-2050/ SCART
PV01 JE01
/
N1S 00MYT02210100 00MYT02210100 TERMINAL AJ-2050/ SCART
PV01 JT01 00MYJ90014720 00MYJ90014720 JACK YKC22-0874V
PV01 JV01 00MYT02021810 00MYT02021810 TERMINAL RJ-1144/04-0500A RCA 2PIN YELLOW
PV01 JV02 00MYJ11000700 00MYJ11000700 JACK JY-5040/030 S TERMINAL
PV01 JV03 00MYT02030800 00MYT02030800 TERMINAL RJ-1165/07-0500A RCA 3PIN COMPONENT
PV01 JY91 F N ns
p
00D2046755003 TERMINAL D-CONNECTOR
(
AU
)
PV01 LE01
/
N1B 00MLU12472010 00MLU12472010 CHIP INDUCT NLV32T-4R7J-PF
PV01 LE01
/
N1S 00MLU12472010 00MLU12472010 CHIP INDUCT NLV32T-4R7J-PF
PV01 LE02
/
N1B 00MLU12472010 00MLU12472010 CHIP INDUCT NLV32T-4R7J-PF
PV01 LE02
/
N1S 00MLU12472010 00MLU12472010 CHIP INDUCT NLV32T-4R7J-PF
PV01 LE21
/
N1B 00MLU12472010 00MLU12472010 CHIP INDUCT NLV32T-4R7J-PF
PV01 LE21
/
N1S 00MLU12472010 00MLU12472010 CHIP INDUCT NLV32T-4R7J-PF
PV01 LE41
/
N1B ns
p
00D2472018903 CHIP RES. RM73B--0R0KT +1608
PV01 LE41
/
N1S ns
p
00D2472018903 CHIP RES. RM73B--0R0KT +1608
PV01 LE42
/
N1B ns
p
00D2472018903 CHIP RES. RM73B--0R0KT +1608
PV01 LE42
/
N1S ns
p
00D2472018903 CHIP RES. RM73B--0R0KT +1608
PV01 LE43
/
N1B ns
p
00D2472018903 CHIP RES. RM73B--0R0KT +1608
PV01 LE43
/
N1S ns
p
00D2472018903 CHIP RES. RM73B--0R0KT +1608
PV01 LE44
/
N1B ns
p
00D2472018903 CHIP RES. RM73B--0R0KT +1608
PV01 LE44
/
N1S ns
p
00D2472018903 CHIP RES. RM73B--0R0KT +1608
PV01 LT01 00MFN31010060 00MFN31010060 EMI FILTER EMI FILTER BLM11P600S
PV01 LT22 00D2350147912 00D2350147912 EMI FILTER BLM21PG600SN1
PV01 LT23 00D2350147912 00D2350147912 EMI FILTER BLM21PG600SN1
PV01 LT24 00D2350147912 00D2350147912 EMI FILTER BLM21PG600SN1
PV01 LT25 00MLU12472010 00MLU12472010 CHIP INDUCT NLV32T-4R7J-PF
PV01 LT26 00MLU12472010 00MLU12472010 CHIP INDUCT NLV32T-4R7J-PF
PV01 LV01 00MLU12472010 00MLU12472010 CHIP INDUCT NLV32T-4R7J-PF
PV01 QE01
/
N1B 00MHC10102550 00MHC10102550 IC MM1623XFBE VIDEO AMP
PV01 QE01
/
N1S 00MHC10102550 00MHC10102550 IC MM1623XFBE VIDEO AMP
PV01 QE21
/
N1B 216450001502S 216450001502S TRS. DTC114EUA
PV01 QE21
/
N1S 216450001502S 216450001502S TRS. DTC114EUA
PV01 QE22
/
N1B 214050003506S 214050003506S TRS. 2SC4081
(
Q_R
)(
312000451210
)
PV01 QE22
/
N1S 214050003506S 214050003506S TRS. 2SC4081
(
Q_R
)(
312000451210
)
PV01 QE23
/
N1B 214050003506S 214050003506S TRS. 2SC4081
(
Q_R
)(
312000451210
)
PV01 QE23
/
N1S 214050003506S 214050003506S TRS. 2SC4081
(
Q_R
)(
312000451210
)
PV01 QE24
/
N1B 00MHX115762A0 00MHX115762A0 CHIP TRS. 2SA1576
(
FQ,FR
)
PV01 QE24
/
N1S 00MHX115762A0 00MHX115762A0 CHIP TRS. 2SA1576
(
FQ,FR
)
PV01 QT01 214050003506S 214050003506S TRS. 2SC4081
(
Q_R
)(
312000451210
)
PV01 QT21 00MHC36908090 00MHC36908090 IC NJM7808DL1A
PV01 QT22 00MHC98233990 00MHC98233990 IC NCP5662DS33R4G
PV01 QT23 00MHC98818990 00MHC98818990 IC NCP1117STAT3 1.25-18.8V ADJ REG.800MA
PV01 QT24 00MHF701492A0 00MHF701492A0 F.E.T. SI2302ADS-T1-E3
PV01 QT25 214050003506S 214050003506S TRS. 2SC4081
(
Q_R
)(
312000451210
)
PV01 QT26 00MHF701492A0 00MHF701492A0 F.E.T. SI2302ADS-T1-E3
PV01 QT27 214050003506S 214050003506S TRS. 2SC4081
(
Q_R
)(
312000451210
)
PV01 QV01 00D2623365900 00D2623365900 IC BH7868FS
PV01 QV02
/
N1B 216450001502S 216450001502S TRS. DTC114EUA
PV01 QV02
/
N1S 216450001502S 216450001502S TRS. DTC114EUA
PV01 RE01
/
N1B ns
p
00D2472005903 CHIP RES. RM73B--101JT +1608
PV01 RE01
/
N1S ns
p
00D2472005903 CHIP RES. RM73B--101JT +1608
PV01 RE02
/
N1B ns
p
00D2472004904 CHIP RES. RM73B--390JT +1608
PV01 RE02
/
N1S ns
p
00D2472004904 CHIP RES. RM73B--390JT +1608
PV01 RE03
/
N1B ns
p
00D2472003989 CHIP RES. RM73B--330JT +1608
PV01 RE03
/
N1S ns
p
00D2472003989 CHIP RES. RM73B--330JT +1608
