Specifications
o
Audio section
0
Power amplifier
Rated output: 100 W + 100 W (8 Ω/ohms, 20 Hz - 20 kHz with 0.05 % T.H.D.)
125 W + 125 W (4 Ω/ohms, 1 kHz with 0.05 % T.H.D.)
Output connectors: 4 – 16 Ω/ohms
S/N (IHF-A): OPTICAL IN, HDMI IN (ARC/eARC): 105 dB
LINE IN: 91 dB
Frequency response: 20 Hz - 40 kHz ±3 dB
0
Analog (LINE IN)
Input sensitivity/impedance: 200 mV/20 kΩ/kohms
Maximum allowable input level: 2.5 V
