Marantz MA-9S2 - Electrical Parts List

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.W.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
001B 99M339J248410 99M339J248410 FRONT PANEL FRONT PANEL ASSY
002B 00M339J248120 00M339J248120 FRONT PANEL FRONT PANEL
003B 00M339J063110 00M339J063110 ESCUTCHEON ESCUTCHEON LEFT
004B 00M339J063120 00M339J063120 ESCUTCHEON ESCUTCHEON RIGHT
006B 00M339J353210 00M339J353210 RING RING FOR METER
007B 00M339J158010 00M339J158010 WINDOW WINDOW FOR METER
008B 00M339J353120 00M339J353120 RING RING FOR POWER SWITCH
009B 00M339J265010 00M339J265010 INDICATOR INDICATOR FOR METER FRONT
011B 00M339J259010 00M339J259010 BUSHING BUSH FOR POWER SWITCH
013B 00M339J259020 00M339J259020 BUSHING BUSH FOR METER SWITCH
017B 00M339J270110 00M339J270110 BUTTON BUTTON FOR POWER SWITCH
021B 00M339J154110 00M339J154110 KNOB KNOB FOR SELECTOR SWITCH
024B 00M339J270120 00M339J270120 BUTTON BUTTON FOR METER SWITCH
028B 00M339J265020 00M339J265020 INDICATOR INDICATOR FOR METER
029B 00M339J355020 00M339J355020 LENS LENS FOR STAR MARK
033B 00M339J355010 00M339J355010 LENS LENS FOR SIDE LIGHTING
043B 00M04AJ251010 00M04AJ251010 BADGE MARANTZ BADGE
(
GOLD
)
049B 00M339J251010 00M339J251010 BADGE BADGE FOR STAR MARK
001D 00M339J249110 00M339J249110 SIDE PANEL SIDE PANEL LEFT
002D 00M339J249120 00M339J249120 SIDE PANEL SIDE PANEL RIGHT
003D 00M339J063140 00M339J063140 ESCUTCHEON ESCUTCHEON
007D 00M339J257110 00M339J257110 LID TOP LID
008D 00M339J063130 00M339J063130 ESCUTCHEON ESCUTCHEON FOR TOP LID
010D 00M339J202010 00M339J202010 NET NET FOR ESCUTCHEON
002G 00M163J057220 00M163J057220 LEG LEG
(
CUPPER
)
914G 00M426T154010 00M426T154010 KNOB KNOB FOR ATT SWITCH
918G 00M339J053110 00M339J053110 COVER COVER FOR SPEAKER TERMINAL
920G 00M339J259030 00M339J259030 BUSHING BUSH FOR RCA TERMINAL
C001 00MOB33906320 00MOB33906320 ELECT. CAP. ! 33000UF 63V LKG1J333MSGOZT
C002 00MOB33906320 00MOB33906320 ELECT. CAP. ! 33000UF 63V LKG1J333MSGOZT
J001 00MYJ04002550 00MYJ04002550 JACK ! INLET TYPE HF-301
J005 00MYT02011300 00MYT02011300 TERMINAL EW-2560T-LH-B
J006 00MYT02011300 00MYT02011300 TERMINAL EW-2560T-LH-B
J007 00MYJ01004760 00MYJ01004760 JACK NC3FDL-B-1
(
NEUTRIC
)
J008 00MYT01010360 00MYT01010360 TERMINAL WBT-0765 POLE TERMINAL RED
J009 00MYT01010370 00MYT01010370 TERMINAL WBT-0765 POLE TERMINAL WHT
J010 00MYT01010360 00MYT01010360 TERMINAL WBT-0765 POLE TERMINAL RED
J011 00MYT01010370 00MYT01010370 TERMINAL WBT-0765 POLE TERMINAL WHT
L001 F N ns
p
00MZK339J0010 UNIT KIT ! POWER TRANSF. ASSY FOR 100V
L001
/
K1G ns
p
00MZK339J0030 UNIT KIT ! POWER TRANSF. ASSY FOR 230V
L001
/
N1G 00MZK339J0030 00MZK339J0030 UNIT KIT ! POWER TRANSF. ASSY FOR 230V
L001
/
U1G ns
p
00MZK339J0020 UNIT KIT ! POWER TRANSF. ASSY FOR 120V
L002 00MFN21010050 00MFN21010050 EMI FILTER ! 0.18HX2 CHOKE COIL
L003 00MFC50160030 00MFC50160030 FERRITE CORE FERRITE CORE TFCK-16813
L004 00MFC50160030 00MFC50160030 FERRITE CORE FERRITE CORE TFCK-16813
L005 00MFC50160030 00MFC50160030 FERRITE CORE FERRITE CORE TFCK-16813
P201 ns
p
ns
p
PWB ASSY INPUT ATT PWB
P401 ns
p
ns
p
PWB ASSY MODE SEL PWB
P501 ns
p
ns
p
PWB ASSY INPUT AMP PWB
P601 ns
p
ns
p
PWB ASSY MAIN AMP PWB
P671 ns
p
ns
p
PWB ASSY H POWER TR PWB
P681 ns
p
ns
p
PWB ASSY N POWER TR PWB
P691 ns
p
ns
p
PWB ASSY IDLING ADJ PWB
P801 ns
p
ns
p
PWB ASSY POWER SUPPLY PWB
P851 ns
p
ns
p
PWB ASSY AC INLET PWB
P871 ns
p
ns
p
PWB ASSY POWER SW PWB
P941 ns
p
ns
p
PWB ASSY LEVEL ON/OFF SW PWB
P951 ns
p
ns
p
PWB ASSY LEVEL METER PWB
P971 ns
p
ns
p
PWB ASSY L LED PWB
P981 ns
p
ns
p
PWB ASSY R LED PWB
P991 ns
p
ns
p
PWB ASSY POSISTOR PWB
PH01 ns
p
ns
p
PWB ASSY HDAM-SA S2 PWB
PACKING
001T F N ns
p
00M339J851120 USER GUIDE USER GUIDE MA-9S2
(
F
)
001T
/
K1G ns
p
00M339J851350 USER GUIDE USER GUIDE MA-9S2
(
K
)
001T
/
N1G 00M339J851320 00M339J851320 USER GUIDE USER GUIDE MA-9S2
(
N
)
001T
/
U1G ns
p
00M339J851320 USER GUIDE USER GUIDE MA-9S2
(
N
)
POS. NO.
25
