Marantz MM7025 Product Information

www.marantz.eu
FEATURES MM7025
Channels 2
Current Feedback Topology o
Phono EQ: Standard/Current Feedback/Constant
Current Feedback
- / - /-
HDAM version -
Power Transformer: Toroidal/El - / o
High Grade Audio Components o
Customised Components o
Symmetric PCB layout -
Aluminium extrusion heatsink o
Copper plated chassis -
Tri-Tone Control (Bass/Mid/Treble)
Balance/Bass/Treble/Loudness -
OTHER
Linear Drive Power Supply o
BTL possibility -
Bi-Amp and Multichannel option -
Shottkey diodes -
Input Buffer Amp (All inputs/CD only) o / -
Seperate solid heatsinks -
System block shielding: copper/metal/none - / - /-
Double layer bottom plate -
Source Direct -
Power Amp Direct -
Standby mode - / - / - / -
INPUTS/OUTPUTS
Phono Input: MM/MC - / -
Balanced In/Out 2 / -
Pre-Out/Main In - / 2
Power Amp Direct In o
Gold Plated Chinch -
Speaker A/B -
Speaker terminal: Screw/Marantz/WBT o / - / -
Number of terminals 2
Marantz remote bus o
Remote power control (Trigger In/Out) o
Flasher In/IR receiver In o / -
Headphone Out -
SPECIFICATIONS
Power Output (8/6 Ohm RMS) 140/170 Watts
Power Output (8/6 Ohm DIN) -
Power Output (8/6 Ohm IHF) -
Bridged Power Output (8 Ohm RMS) -
Frequency Response 8Hz-100kHz
Total Harmonic Distortion 0.03%
Damping Factor 100dB
Input Sensitivity: MM -
Input Sensitivity: MC -
Signal to Noise Ratio: MM/MC - / -
Input Sensitivity: High level 1.2V/22kohm
Input Sensitivity: Balanced High level 2.4V/30kohm
Signal to Noise Ratio: High level 105dB
GENERAL
Available colors: Gold/Silver/Black/Silver-Gold - / - / o / -
Metal Front Panel o
Power Consumption in W 220
Standby Consumption in W 0.4
Auto Power off o
Detachable Power Cable o
Remote Control -
System Remote Function -
Maximum Dimensions (W x D x H) in mm 440x350x126
Weight in kg 10.5
Design and specifications are subject to change by Marantz without notice.
MM7025 Stereo Main aMplifier

Marantz MM7025 Specifications

General

Output level	2.4 mV
Damping factor	100
Amplifier class	-
Frequency range	20 - 20000 Hz
Output impedance	30000 Ω
Input sensitivity	1.2 mV
Audio output channels	2.0 channels
Peak power per channel	170 W
Signal-to-Noise Ratio (SNR)	105 dB
Total Harmonic Distortion (THD)	0.03 %
RMS power output per channel (8 Ohm)	140 W
AC (power) in	Yes
Audio (L/R) in	2
Line inputs (RCA)	1
Speakers connectivity type	XLR
Material	Metal
Cooling type	Passive
Product color	Black
Connectivity technology	Wired
Power consumption (standby)	0.4 W
Power consumption (typical)	220 W

Weight and Dimensions

Depth	350 mm
Width	440 mm
Height	126 mm
Weight	10500 g
