Explicación de
términos
Especificaciones
Salida potencia nominal
(de 20 Hz a 20 kHz/THD = 0,08 %, conducida dos canales):
150 W/ch, 8 Ω
180 W/ch, 6 Ω
Potencia salida máxima efectiva
(de 1 kHz, 6 Ω, 10% conducida dos canales): 210 W/ch, 6 Ω
Conectores de salida: 6 – 8 Ω
Respuesta de frecuencia (1 W, 8 Ω): 8 Hz – 100 kHz (±3 dB)
Factor de descarga: 100
Sensibilidad entrada/impedancia: 1,2 V / 22 kΩ (UNBALANCED)
2,4 V / 30 kΩ (BALANCED)
Proporción señal-ruido (IHF-A): 105 dB
Nivel amplificación voltaje: 29 dB
Voltaje alimentación: CA 120V, 60 Hz
Consumo potencia: 800 W
Potencia en modo de espera: 0,4 W
Con el propósito de introducir mejoras, las especificaciones y el diseño del equipo están sujetos a cambios
sin previo aviso.
