Marantz MR2020 - Page 34

8-4
8-4
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST,
**
:EUROPE)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
PD04-CD SERVO DECODER
DAC CIRCUIT BOARD
PD04-CAPACITORS
C201 4822 126 13883 CER. CHIP 220pF ±5% CG 50V DD95221300
C202 4822 126 13883 CER. CHIP 220pF ±5% CG 50V DD95221300
C203 4822 126 12495 CER. CHIP 1500pF ±10% DK96152300
C204 4822 126 13883 CER. CHIP 220pF ±5% CG 50V DD95221300
C205 4822 126 13883 CER. CHIP 220pF ±5% CG 50V DD95221300
C206 4822 126 13883 CER. CHIP 220pF ±5% CG 50V DD95221300
C207 4822 126 14249 CER. CHIP 560PF ±10% DK96561300
C208 4822 126 13883 CER. CHIP 220pF ±5% CG 50V DD95221300
C210 4822 122 33788 CER. CHIP 82PF ±5% DD95820300
C212 4822 126 11567 CER. CHIP 0.022
µ
F ±10% XTR DK96223200
C213 4822 126 11687 CER. CHIP 0.1
µ
F +80%-20% DK98104200
C214 4822 126 12516 CER. CHIP 1000pF ±10% B 50V DK96102300
C215 4822 124 11131 ELECT CHIP 47
µ
F 6.3V EY47600620
C217 4822 126 11687 CER. CHIP 0.1
µ
F +80%-20% DK98104200
C218 4822 126 11567 CER. CHIP 0.022
µ
F ±10 % XTR DK96223200
C219 4822 126 11687 CER. CHIP 0.1
µ
F +80%-20% DK98104200
C221 4822 126 11687 CER. CHIP 0.1
µ
F +80%-20% DK98104200
C222 4822 124 11131 ELECT CHIP 47
µ
F 6.3V EY47600620
C223 4822 126 11687 CER. CHIP 0.1
µ
F +80%-20% DK98104200
C224 4822 126 11669 CER. CHIP 27pF ±5% DD95270300
C225 4822 126 11669 CER. CHIP 27pF ±5% DD95270300
C226 4822 122 33777 CER. CHIP 47pF ±5% C6 50V DD95470300
C233 4822 126 11687 CER. CHIP 0.1
µ
F +80%-20% DK98104200
C234 4822 124 11131 ELECT CHIP 47
µ
F 6.3V EY47600620
C236 4822 126 11687 CER. CHIP 0.1
µ
F +80%-20% DK98104200
C237 4822 126 11687 CER. CHIP 0.1
µ
F +80%-20% DK98104200
C238 4822 126 11687 CER. CHIP 0.1
µ
F +80%-20% DK98104200
C239 4822 124 11432 ELECT CHIP 100
µ
F 10V EY10701020
C251 4822 126 11685 CER. CHIP 4700pF ±10% DK96472300
C252 4822 126 11568 CER. CHIP 470pF ±10% DK96471300
C253 4822 126 11687 CER. CHIP 0.1
µ
F +80%-20% DK98104200
C254 4822 124 11432 ELECT CHIP 100
µ
F 10V EY10701020
C255 4822 126 11685 CER. CHIP 4700pF ±10% DK96472300
C256 4822 126 11568 CER. CHIP 470pF ±10% DK96471300
C257 4822 126 11687 CER. CHIP 0.1
µ
F +80%-20% DK98104200
C258 4822 124 11131 ELECT CHIP 47
µ
F 6.3V EY47600620
C261 4822 126 11687 CER. CHIP 0.1
µ
F +80%-20% DK98104200
C262 4822 126 11687 CER. CHIP 0.1
µ
F +80%-20% DK98104200
C263 4822 126 11687 CER. CHIP 0.1
µ
F +80%-20% DK98104200
C265
4822 126 11687 CER. CHIP 0.1
µ
F +80%-20% DK98104200
C268
C271 4822 116 82487 CHIP 0
Ω
±5% 1/16W NN05000610
C401 4822 126 11687 CER. CHIP 0.1
µ
F +80%-20% DK98104200
C402 4822 124 11432 ELECT CHIP 100
µ
F 10V EY10701020
C411 4822 124 11074 ELECT CHIP 10
µ
F 16V EY10601620
C412 4822 124 11074 ELECT CHIP 10
µ
F 16V EY10601620
C413 4822 126 14249 CER. CHIP 560PF ±10% DK96561300
C414 4822 126 14249 CER. CHIP 560PF ±10% DK96561300
C425 4822 126 11687 CER. CHIP 0.1
µ
F +80%-20% DK98104200
C451 4822 126 11568 CER. CHIP 470pF ±10% DK96471300
C452 4822 126 11568 CER. CHIP 470pF ±10% DK96471300
C453 4822 126 11759 CER. CHIP 100PF ±5% DD95101300
C454 4822 126 11759 CER. CHIP 100PF ±5% DD95101300
C455 4822 124 11074 ELECT CHIP 10
µ
F 16V EY10601620
C456 4822 124 11074 ELECT CHIP 10
µ
F 16V EY10601620
C459 4822 124 11226 ELECT CHIP 22
µ
F 6.3V EY22600620
C460 4822 126 11687 CER. CHIP 0.1
µ
F +80%-20% DK98104200
C461 4822 124 11226 ELECT CHIP 22
µ
F 6.3V EY22600620
PD04-RESISTORS
R201
4822 051 30103 CHIP 10k
Ω
±5% 1/16W NN05103610
R206
R209 4822 126 12339 CER. 2200PF 10% DK96222300
R210 4822 051 30223 CHIP 22k
Ω
±5% 1/16W NN05223610
R212 4822 051 30332 CHIP 3.3k
Ω
±5% 1/16W NN05332610
R213 4822 051 30223 CHIP 22k
Ω
±5% 1/16W NN05223610
R214 4822 051 30104 CHIP 100k
Ω
±5% 1/16W NN05104610
R215 4822 116 82487 CHIP 0
Ω
±5% 1/16W NN05000610
R219 4822 051 30472 CHIP 4.7k
Ω
±5% 1/16W NN05472610
R222 4822 051 30224 CHIP 220k
Ω
±5% 1/16W NN05224610
R223 4822 051 30105 CHIP 1M
Ω
±5% 1/16W NN05105610
R224 4822 051 30151 CHIP 150
Ω
±5% 1/16W NN05151610
R225 4822 051 30471 CHIP 470
Ω
±5% 1/16W NN05471610
R229 4822 051 30223 CHIP 22k
Ω
±5% 1/16W NN05223610
R231 4822 116 83208 CHIP 12k
Ω
±5% 1/16W NN05123610
R232 4822 051 30223 CHIP 22k
Ω
±5% 1/16W NN05223610
R233 4822 116 83208 CHIP 12k
Ω
±5% 1/16W NN05123610
R235 4822 051 30273 CHIP 27k
Ω
±5% 1/16W NN05273610
R236 4822 051 30273 CHIP 27k
Ω
±5% 1/16W NN05273610
R238 4822 051 30471 CHIP 470
Ω
±5% 1/16W NN05471610
R239 4822 051 30471 CHIP 470
Ω
±5% 1/16W NN05471610
R240 4822 051 30471 CHIP 470
Ω
±5% 1/16W NN05471610
R241 4822 051 30222 CHIP 2.2k
Ω
±5% 1/16W NN05222610
R242 4822 051 30101 CHIP 100
Ω
±5% 1/16W NN05101610
R251 4822 051 30102 CHIP 1k
Ω
±5% 1/16W NN05102610
R253 4822 051 30103 CHIP 10k
Ω
±5% 1/16W NN05103610
R254 4822 116 82487 CHIP 0
Ω
±5% 1/16W NN05000610
R255 4822 051 30102 CHIP 1k
Ω
±5% 1/16W NN05102610
R257 4822 051 30103 CHIP 10k
Ω
±5% 1/16W NN05103610
R258 4822 116 82487 CHIP 0
Ω
±5% 1/16W NN05000610
R259 4822 051 30102 CHIP 1k
Ω
±5% 1/16W NN05102610
R260 4822 051 30102 CHIP 1k
Ω
±5% 1/16W NN05102610
R261 4822 051 30102 CHIP 1k
Ω
±5% 1/16W NN05102610
R263 4822 051 30103 CHIP 10k
Ω
±5% 1/16W NN05103610
R264 4822 116 82487 CHIP 0
Ω
±5% 1/16W NN05000610
R265 4822 051 30102 CHIP 1k
Ω
±5% 1/16W NN05102610
R267 4822 116 82487 CHIP 0
Ω
±5% 1/16W NN05000610
R268 4822 116 82487 CHIP 0
Ω
±5% 1/16W NN05000610
R271 4822 116 82487 CHIP 0
Ω
±5% 1/16W NN05000610
R272 4822 116 82487 CHIP 0
Ω
±5% 1/16W NN05000610
R411 4822 051 30332 CHIP 3.3k
Ω
±5% 1/16W NN05332610
R412 4822 051 30332 CHIP 3.3k
Ω
±5% 1/16W NN05332610
R413 4822 051 30104 CHIP 100k
Ω
±5% 1/16W NN05104610
R414 4822 051 30104 CHIP 100k
Ω
±5% 1/16W NN05104610
R415
4822 051 30471 CHIP 470
Ω
±5% 1/16W NN05471610
R418
R419 FERRITE BEADS
BK1608HM102-T
FC90020120
R420 FERRITE BEADS
BK1608HM102-T
FC90020120
R421 4822 116 82487 CHIP 0
Ω
±5% 1/16W NN05000610
R422 4822 116 82487 CHIP 0
Ω
±5% 1/16W NN05000610
R423 4822 116 82487 CHIP 0
Ω
±5% 1/16W NN05000610
R425 4822 117 11374 CHIP 120k
Ω
±1% 1/10W NI01124110
R426 4822 117 12024 CHIP 27k
Ω
±1% 1/10W NI01273110
R451
4822 051 30223 CHIP 22k
Ω
±5% 1/16W NN05223610
R456
R459 4822 051 30102 CHIP 1k
Ω
±5% 1/16W NN05102610
R460 4822 051 30102 CHIP 1k
Ω
±5% 1/16W NN05102610
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST,
**
:EUROPE)
PD04-SEMICONDUCTORS
D221 4822 130 83715 CHIP DIODE 1SS301 DAN202U HZ21005000
Q201 4822 209 16855 IC TDA1300T HF AMP AND
LASER CONT
HC10172490
Q221 4822 209 91174 IC SAA7372GP SERVO HC10132490
Q251 4822 209 16372 IC TDA7073AT
DUAL BTL DRIVER
HC10165490
Q252 4822 209 16372 IC TDA7073AT
DUAL BTL DRIVER
HC10165490
Q401 4822 209 32196 IC TDA1311AT CC-DAC HC10173490
Q425 4822 209 15595 IC RN5RL35AA
V-REGULATOR 3.5V
HC10021770
Q451 4822 209 33165 IC TDA1308 POWER OP AMP HC10138490
PD04-MISCELLANEOUS
F201
4822 157 10313 HF50ACC453215 FN31020010
F207
L221 4822 157 53872 CHIP INDUCTANCE
NL322522-100K
LU12103010
WD01 4822 320 12646 JUMPER LEAD FFC YU15073500
X221 4822 242 11017 CRYSTAL CM309S 8.4672MHz JX08001320
