K
Video connectors (VIDEO)
Used to connect devices equipped with video connectors.
0
“Connecting a set-top box (Satellite tuner/cable TV)” (v
p. 39)
0
“Connecting a DVD player or Blu-ray Disc player” (v p. 40)
L
Speaker terminals (SPEAKERS)
Used to connect speakers. (v p. 29)
M
AC inlet (AC IN)
Used to connect the power cord. (v p. 49)
NOTE
0
Do not touch the inner pins of the connectors on the rear panel. Electrostatic
discharge may cause permanent damage to the unit.
