Marantz NR1608 - Front Dolby Atmos Enabled Speaker Connections

o
Example connections when using front Dolby Atmos Enabled speakers
This 7.1-channel surround system is the same as a basic 5.1-channel system but with front Dolby Atmos Enabled speakers.
.
C
SWFL FR
SL SR
FDL FDR
0
Set “Assign Mode” to “Front Dolby” in the menu. (v p. 182)
.
CSRSL
SW
FLFR
FDR FDL
