POS.
NO
VERS.
COLOR
PA RT NO.
(PCS)
DESCRIPTION
PA RT NO.
(MJI)
POS.
NO
VERS.
COLOR
PA R T NO .
(PCS)
DESCRIPTION
PA RT NO.
(MJI)
002B FRONT PA NEL (PA 02 F) 02AS248010
006B 4822 381 11893 LED LENS 269J355010
008B FRONT COVER 02AS053010
009B NET (PANEL-FRONT COVER) 02AS202010
010B SCREW FOR FRONT COVER 02AS010010
012B VOLUME KNOB (L R) 02AS154010
014B BUFFER FOR LID nsp
016B REFLECTOR FOR TEMP. LED nsp
018B REFRECTOR FOR POWER
PEAK LED
nsp
002D LID nsp
004D HANDLE nsp
002G MAIN CHASSIS nsp
004G LID BOTTOM COVER nsp
008G TRANSF. CHASSIS nsp
012G SCREW FOR TRANS 02AS010020
014G FRONT BRACKET (R) nsp
018G FRONT BRACKET (L) nsp
022G VOLUME BRACKET nsp
025G SPA CER FOR VR BRACKET nsp
028G LED PCB BRACKET nsp
031G CLAMPER FOR LED PCB 284J005010
032G SHIELD nsp
037G LEG 288S057120
042G SUPPORT FOR POWER PCB nsp
044G CLAMPER FOR WIRE BIND
PCB
284J005010
046G SHIELD FOR V-AMP PCB nsp
047G INSULATOR FOR SHIELD
(046G)
nsp
902G REAR PA NEL nsp
910G REAR PA NEL SP TERMINAL nsp
914G SPA CER FOR SPK.TERMINAL nsp
002L MAIN HEATSINK nsp
004L SUB HEATSINK nsp
006L HEATSINK BRACKET nsp
010L HEATSINK STAY nsp
016L INSULATOR FOR TR 02AS120010
022L RETAINER FOR FAN PCB nsp
032L FAN BUFFER nsp
034L CLAMPER FOR STAY+PCB 284J005010
040L HEATSINK FOR V-AMP PCB nsp
042L INSULATOR FOR TR 01AS120020
046L HEATSINK FOR FAN
CONTROL PCB
nsp
FA01 D.C MOTOR FAL6F12LLS
SCIROCCO FAN
MM01200380
F001 FUSE 15A 250V SM15
MITI 32-1246
FS11500540
JS01 TERMINAL SP RED YT01010780
JS02 TERMINAL SP WHT YT01010770
JS03 TERMINAL SP WHT YT01010770
JS04 TERMINAL SP RED YT01010780
J001 JACK AC INLET TYPE HF-301 YJ04002550
J002 4822 256 30232 JACK FUSE HOLDER YJ08000300
S001 MAINS SWITCH
JW-L11RKK
SC01010580
T001 MAINS TRANSF. FOR PA 02
R-700
TS87001010
W001 MAINS CORD
CORDSET FOR F OFC 2P
ZC01803130
002T U
PACKING
SER GUIDE 02AS851110
NOT STANDARD SPARE
PARTS
002S PA CKING CASE 02AS801010
004S CUSHION 02AS809010
005S CUSHION 02AS809020
010T TOOL HEX-
KEY
WRENCH 9710100070
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
