(2)
Disconnecttheconnectorwires.Removethescrews.
4. SPK TERMINAL PWB ASSY
(1) Cutthewireclampband,thendisconnecttheconnectorwires.
Direction of photograph: D
J331
J283
→
Proceeding :
TOP COVER
SPK TERMINAL PWB ASSYREAR PANEL
→
STYLE PIN : Loose
cut
Direction of photograph: B
J754
J751
J755
