Marantz PM8004 Service Manual

7
About the photos used for descriptions in the DISASSEMBLY" section.
• Thedirectionfromwhichthephotographsusedhereinwerephotographedisindicatedat"Directionofphotograph:***"
attheleftoftherespectivephotographs.
• Refertothetablebelowforadescriptionofthedirectioninwhichthephotosweretaken.
• Photographsforwhichnodirectionisindicatedweretakenfromabovetheproduct.
• ThephotographisPM-KI-PEARL-LITE.
1. FRONT PANEL ASSY
(1) Removethescrews.
(2) Removethescrews.
The viewpoint of each photograph
(Photografy direction)
［View from above］
Front side
Direction of photograph: B
Direction of
photograph: D
Direction of
photograph: C
Direction of photograph: A
Proceeding : TOP COVER
FRONT PANEL ASSY
→
View from bottom

Marantz PM8004 Specifications

General

Brand	Marantz
Model	PM8004
Category	Amplifier
Language	English
