9
(5)
Removethenut.
2. REAR PANEL
(1) Removethescrews.
3. PHONO AMP PWB ASSY
(1) Removethescrews.
Direction of photograph: B
NUT
Proceeding : TOP COVER
REAR PANEL
→
Direction of
photograph: A
Proceeding : TOP COVER
→
PHONO AMP PWB ASSY
Direction of photograph: A
