Marantz PM8005 Getting Started

3
2
Connect the speakers to the amplifier
(R)
w q
(L)
w q
Connecting the speaker cables
q Peel off about 3/8 inch (10 mm)
of sheathing from the tip of the
speaker cable, then either twist
the core wire tightly or apply
solder to it.
w Turn the speaker terminal
counterclockwise to loosen it.
e Insert the speaker cable’s core
wire to all the way into the
speaker terminal.
r Turn the speaker terminal
clockwise to tighten it.

Marantz PM8005 Specifications

General

Amplifier class	-
Frequency range	5 - 100000 Hz
Audio output channels	- channels
Peak power per channel	100 W
Signal-to-Noise Ratio (SNR)	125 dB
Total Harmonic Distortion (THD)	0.02 %
Purpose	Home
Product color	Black
Channels quantity	2 channels
Connectivity technology	Wired
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	0.2 W
Power consumption (typical)	220 W

Weight and Dimensions

Depth	379 mm
Width	440 mm
Height	128 mm
Weight	12000 g
