Marantz PM8006 Service Manual

CAUTION IN SERVICING
SAFETY PRECAUTIONS
NOTE FOR SCHEMATIC DIAGRAM
NOTE FOR PARTS LIST
INSTRUCTIONS FOR HANDLING SEMICONDUCTORS AND OPTICAL UNIT
Online Parts List
Accessing the Parts List
Logging in to New SDI and Accessing the Parts List
Accessing the Part List from the Model Asset Screen
PRINTED CIRCUIT BOARDS Parts Table
Downloading the Parts List as an Excel File
Revision History
Searching Part Numbers or Ref. Numbers
CAUTION IN SERVICING.
Initializing This Unit
2
Caution in
servicing
Electrical Mechanical Repair Information Updating

Marantz PM8006 Specifications

General

Amplifier class	-
Frequency range	5 - 100000 Hz
Input sensitivity	2 mV
Audio output channels	2.0 channels
Peak power per channel	70 W
Signal-to-Noise Ratio (SNR)	87 dB
Total Harmonic Distortion (THD)	0.02 %
RMS power output per channel (4 Ohm)	100 W
Product color	Gold, Silver
Volume control	Rotary
Remote control type	RC001PMND
Connectivity technology	Wired
Audio (L/R) in	6
Audio (L/R) out	1
Speaker selector	A / B
Power consumption (standby)	0.2 W
Power consumption (typical)	220 W
Certification	CE, EAC

Weight and Dimensions

Depth	379 mm
Width	440 mm
Height	128 mm
Weight	12000 g
