Marantz PMD580 - Page 56

78
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
PWB
NAME
POS.
NO.
VERS.
COLOR
QTY PART NO. PART NAME DESCRIPTION
J700 1 00MYJ04002450 !3P AC INLET M1910-D EMUDEN
L710 1 00MFC50220010 TFC-16-8-16 (TROIDAL FERRITE CLAMP)
L720 1 00MYJ90014730 TFP2014-T
L730 1 00MFC20310010 FERRITE CORE : KITAGAWA FPC-31-12-3 FPC-31-12-3 Ferrite core 100MHZ >30
Ω
V990 1 00MKZ03302210 RCU7276Y-B LCD UNIT FOR PMD580 DISPLAY LCD UNIT
W002 1 00MYE05040950 SRA-UL1015 AWG18 L=9CM
W016 1 00M43BS152010 ULTUBE (INNER DIA.Ø4.6-L36) RoHS
W018 1 00M43BS152010 ULTUBE (INNER DIA.Ø4.6-L36) RoHS
5101 99MZZ09CS1000
MAIN PCB ASSY
P101 B101 1 00MYJ14000080 20H-1T (CR2032 HOLDER) SANYO
P101 C002 1 00MEY10700620 100µF/6.3V 100µF/6.3V
P101 C004 1 00MEY10700620 100µF/6.3V 100µF/6.3V
P101 C006 1 00MEY10700620 100µF/6.3V 100µF/6.3V
P101 C007 1 00MEY10700620 100µF/6.3V 100µF/6.3V
P101 C018 1 00MEY10701620 100µF/16V 100µF/16V
P101 C087 1 00MEY10701620 100µF/16V 100µF/16V
P101 C091 1 00MEY10601620 10µF/16V 10µF/16V
P101 C100 1 00MEY10601620 10µF/16V 10µF/16V
P101 C126 1 00MEY10501670 SVSP1C 1µF/16V SVSP1C 1µF/16V
P101 C151 1 00MEY10700620 100µF/6.3V 100µF/6.3V
P101 C152 1 00MEY10700620 100µF/6.3V 100µF/6.3V
P101 C165 1 00MEY10700620 100µF/6.3V 100µF/6.3V
P101 C168 1 00MEY10701620 100µF/16V 100µF/16V
P101 C169 1 00MEY10700620 100µF/6.3V 100µF/6.3V
P101 C179 1 00MEY10700620 100µF/6.3V 100µF/6.3V
P101 C182 1 00MEY10700620 100µF/6.3V 100µF/6.3V
P101 C420 1 00MEY10701620 100µF/16V 100µF/16V
P101 C437 1 00MEY10601620 10µF/16V 10µF/16V
P101 CU37 1 00MEL47501010 APXA100ARA4R7MD55G 4.7µF/10V (PXA)
P101 D006 1 00D2760683943 UDZS3.6B-TE17
P101 D007 1 00D2760560901 DAN202KT146 +C
P101 D013 1 00D3939631903 TLGU1002A(T02)
P101 D014 1 00MHI10038050 TLSU1002A(T02)
P101 D016 1 00MHZ30012060 NSAD500F SURGE ABSORBER
P101 D018 1 00D2760833900 ESD PROTECTOR(6802)
P101 D019 1 00D2760833900 ESD PROTECTOR(6802)
P101 D023 1 00D2760833900 ESD PROTECTOR(6802)
P101 D024 1 00D2760833900 ESD PROTECTOR(6802)
