Marantz PMD580 - Page 61

83
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
PWB
NAME
POS.
NO.
VERS.
COLOR
QTY PART NO. PART NAME DESCRIPTION
P201 DC01 1 00MHI10202050 TLOU1002A(T02)
P201 DC02 1 00D3939631903 TLGU1002A(T02)
P201 DC03 1 00D2760560901 DAN202KT146 +C
P201 DC04 1 00D2760559909 DAP202KT146 +C
P201 DD01 1 00D2760560901 DAN202KT146 +C
P201 DD02 1 00D2760559909 DAP202KT146 +C
P201 DD03 1 00D2760560901 DAN202KT146 +C
P201 DD04 1 00D2760559909 DAP202KT146 +C
P201 DD05 1 00D2760560901 DAN202KT146 +C
P201 DD06 1 00D2760559909 DAP202KT146 +C
P201 DD07 1 00D2760833900 ESD PROTECTOR(6802)
P201 DD08 1 00D2760833900 ESD PROTECTOR(6802)
P201 JA01 1 00D2051254007 XLR IN (JY-5033U) JY-5033U*030
P201 JA02 1 00D2051254007 XLR IN (JY-5033U) JY-5033U*030
P201 JA03 1 00MYT02021200 YKC21-3091N 14X14 RA 2L2P W/R NI FLM-GND
P201 JA04 1 00MYP06010450 B5B-EH-TS (LF)(SN) 5P RADIAL TAPING B5B-EH 5P RADIAL TAPING
P201 JB01 1 00D2051255006 XLR OUT (JY-5032A) JY-5032A*030
P201 JB02 1 00D2051255006 XLR OUT (JY-5032A) JY-5032A*030
P201 JB03 1 00MYT02021200 YKC21-3091N 14X14 RA 2L2P W/R NI FLM-GND
P201 JB04 1 00MYJ06006260 B6B-PH-K-S (LF)(SN) HP CONNECTOR B6B-PH-K-S
P201 JC01 1 00MYJ01080220 YKB21-5265 6.3mm STREO PHONE JACK
P201 JC02 1 00MYJ90014700 TM11R-5M2-88-LP HIROSE RJ45 LAN
P201 JC03 1 00MYJ07019740 B4B-PH-SM4-TB (LF)(SN) LAN CONNECTOR B4B-PH-SM4
P201 JD01 1 00D2051254007 XLR IN (JY-5033U) JY-5033U*030
P201 JD02 1 00MYT02021220 YKC21-3248V 14X14 RA 2L2P BLK NI FLM-GND RCA2P(BLK/BLK)
P201 JD03 1 00D2051255006 XLR OUT (JY-5032A) JY-5032A*030
P201 JD06 1 00MYJ07014260 20FMN-BMTTN-A-TFT
P201 JD07 1 00MYJ07014280 22FMN-BMTTN-TFT JST 22FMN-BMTTN-TFT JST
P201 LA01 1 00MFC90020110 BLM18BD601SN1D
P201 LA02 1 00MFC90020110 BLM18BD601SN1D
P201 LA03 1 00MFC90020110 BLM18BD601SN1D
P201 LA04 1 00MFC90020110 BLM18BD601SN1D
P201 LA05 1 00MNN05102610 1k
Ω
±5% 1/16W 1K OHM 1/16W +- 5%
P201 LA06 1 00MNN05102610 1k
Ω
±5% 1/16W 1K OHM 1/16W +- 5%
P201 LB01 1 00MFC90020110 BLM18BD601SN1D
P201 LB02 1 00MFC90020110 BLM18BD601SN1D
P201 LB03 1 00MFC90020110 BLM18BD601SN1D
P201 LB04 1 00MFC90020110 BLM18BD601SN1D
P201 LB05 1 00MFC90020110 BLM18BD601SN1D
P201 LB06 1 00MFC90020110 BLM18BD601SN1D
P201 LB07 1 00MFC90020110 BLM18BD601SN1D
P201 LB08 1 00MFC90020110 BLM18BD601SN1D
P201 LB09 1 00D2140127003 RELAY(RY-12W)
P201 LB10 1 00D2140127003 RELAY(RY-12W)
P201 LB11 1 00MFN31010030 BLM18B102SN1D BLM11B102S 1608 EMIFILTER
P201 LB12 1 00MFN31010030 BLM18B102SN1D BLM11B102S 1608 EMIFILTER
P201 LB13 1 00MFN31010030 BLM18B102SN1D BLM11B102S 1608 EMIFILTER
P201 LC01 1 00MFN21020040 DLP11SN161SL2 COMMON MODE CHOKE COILS
P201 LC02 1 00MFN21020040 DLP11SN161SL2 COMMON MODE CHOKE COILS
P201 LC03 1 00MFC90020110 BLM18BD601SN1D
P201 LC04 1 00MFC90020110 BLM18BD601SN1D
P201 LD01 1 00MTP41042010 PULS TRANS FOR CD PULS TRANS FOR CD
