Marantz PMD620 Service Manual

55
PWB
NAME
POS.
NO.
QTY
PART NO.
(FOR EUR)
PART NO.
(D&M)
PART NAME DESCRIPTION
P100 MAIN PWB KIT ( 00MWI10CS1000 )
P101 MAIN PWB ( 00MWI10CS1010 )
P101 J201 1 00MYJ90014790 00MYJ90014790 CONNECTOR SDKR-9BRS-K13-G
P101 J203 1 00MYJ90014780 00MYJ90014780 CONNECTOR CSS 5005-0402F
P101 S203 1 00MSP01014720 00MSP01014720 PUSH SWITCH PUSH SW SPVP110100
P102 SUB PWB ( 00MWI10CS1020 )
P102 J601 1 00MYJ04002270 00MYJ04002270 JACK HEC3600-016110
P102 J603 1 00MYJ01080260 00MYJ01080260 JACK LGY2209-0300F
P102 J604 1 00MYJ01080260 00MYJ01080260 JACK LGY2209-0300F
P102 J605 1 00MYJ01080270 00MYJ01080270 JACK LGY3009-0200F
P102 J606 1 00MYJ01080270 00MYJ01080270 JACK LGY3009-0200F
P102 J701 1 00MYJ01004520 00MYJ01004520 JACK HSJ 1637-010512
P102 S701 1 00MSP01014710 00MSP01014710 PUSH SWITCH SKRELJE010
P102 S702 1 00MSP01014710 00MSP01014710 PUSH SWITCH SKRELJE010
P102 S703 1 00MSS01030430 00MSS01030430 SLIDE SWITCH SSSS7A0202
P102 S704 1 00MSS01021150 00MSS01021150 SLIDE SWITCH SSSS710607
P102 Z701 1 00MZB09050090 00MZB09050090 BATTERY CR1220/1FC
P102 Z702 1 00M10CS123020 00M10CS123020 CONTACTOR PLUS CONTACTOR
P102 Z703 1 00M10CS123030 00M10CS123030 CONTACTOR MINUS CONTACTOR
