Marantz SA-15S1 - Page 19

1-27
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
PCB
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
001B
/
F N ns
p
99M24AK248410 PANEL ASSY FRONT PANEL AL ASSY GL
001B
/
K1G ns
p
99M24AK248410 PANEL ASSY FRONT PANEL AL ASSY GL
001B
/
L1G ns
p
99M24AK248410 PANEL ASSY FRONT PANEL AL ASSY GL
001B
/
N1G 99M24AK248410 99M24AK248410 PANEL ASSY FRONT PANEL AL ASSY GL
001B
/
N1S 99M24AK248420 99M24AK248420 PANEL ASSY FRONT PANEL AL ASSY SL
001B
/
S1G ns
p
99M24AK248410 PANEL ASSY FRONT PANEL AL ASSY GL
010B 00M256J35503
0
00M256J35503
0
LENS IR LENS
(
MD
)
015B
/
F N ns
p
00M18AK259110 BUSHING BUSH SOUND BUTTON GL
015B
/
K1G ns
p
00M18AK259110 BUSHING BUSH SOUND BUTTON GL
015B
/
L1G ns
p
00M18AK259110 BUSHING BUSH SOUND BUTTON GL
015B
/
N1G 00M18AK259110 00M18AK259110 BUSHING BUSH SOUND BUTTON GL
015B
/
N1S 00M18AK259120 00M18AK259120 BUSHING BUSH SOUND BUTTON SL
015B
/
S1G ns
p
00M18AK259110 BUSHING BUSH SOUND BUTTON GL
020B
/
F N ns
p
00M18AK105130 CHASSIS CHASSIS FRONT MOLD GL
020B
/
K1G ns
p
00M18AK105130 CHASSIS CHASSIS FRONT MOLD GL
020B
/
L1G ns
p
00M18AK105130 CHASSIS CHASSIS FRONT MOLD GL
020B
/
N1G 00M18AK105130 00M18AK105130 CHASSIS CHASSIS FRONT MOLD GL
020B
/
N1S 00M18AK105230 00M18AK105230 CHASSIS CHASSIS FRONT MOLD SL
020B
/
S1G ns
p
00M18AK105130 CHASSIS CHASSIS FRONT MOLD GL
025B
/
F N ns
p
00M18AK158010 WINDOW WINDOW GL/SL
025B
/
K1G ns
p
00M18AK158010 WINDOW WINDOW GL/SL
025B
/
L1G ns
p
00M18AK158010 WINDOW WINDOW GL/SL
025B
/
N1G 00M18AK158010 00M18AK158010 WINDOW WINDOW GL/SL
025B
/
N1S 00M18AK158010 00M18AK158010 WINDOW WINDOW GL/SL
025B
/
S1G ns
p
00M18AK158010 WINDOW WINDOW GL/SL
058B
/
F N ns
p
00M18AK270120 BUTTON BUTTON SOUND GL
058B
/
K1G ns
p
00M18AK270120 BUTTON BUTTON SOUND GL
058B
/
L1G ns
p
00M18AK270120 BUTTON BUTTON SOUND GL
058B
/
N1G 00M18AK270120 00M18AK270120 BUTTON BUTTON SOUND GL
058B
/
N1S 00M18AK270220 00M18AK270220 BUTTON BUTTON SOUND SL
058B
/
S1G ns
p
00M18AK270120 BUTTON BUTTON SOUND GL
075B 00M18AK355010 00M18AK355010 LENS LENS SIDE
085B
/
F N ns
p
00M04AJ25921
0
BUSHING BUSH FOR FUNCTION BUTTONS GL
085B
/
K1G ns
p
00M04AJ25921
0
BUSHING BUSH FOR FUNCTION BUTTONS GL
085B
/
L1G ns
p
00M04AJ25921
0
BUSHING BUSH FOR FUNCTION BUTTONS GL
085B
/
N1G 00M04AJ25921
0
00M04AJ25921
0
BUSHING BUSH FOR FUNCTION BUTTONS GL
085B
/
N1S 00M04AJ25911
0
00M04AJ25911
0
BUSHING BUSH FOR FUNCTION BUTTONS SL
085B
/
S1G ns
p
00M04AJ25921
0
BUSHING BUSH FOR FUNCTION BUTTONS GL
088B
/
F N ns
p
00M04AJ27013
0
BUTTON FUNCTION BUTTONS GL
088B
/
K1G ns
p
00M04AJ27013
0
BUTTON FUNCTION BUTTONS GL
088B
/
L1G ns
p
00M04AJ27013
0
BUTTON FUNCTION BUTTONS GL
088B
/
N1G 00M04AJ27013
0
00M04AJ27013
0
BUTTON FUNCTION BUTTONS GL
088B
/
N1S 00M04AJ27023
0
00M04AJ27023
0
BUTTON FUNCTION BUTTONS SL
088B
/
S1G ns
p
00M04AJ27013
0
BUTTON FUNCTION BUTTONS GL
090B
/
F N ns
p
00M18AK063110 ESCUTCHEON ESCUTCHEON AL L SIDE GL
090B
/
K1G ns
p
00M18AK063110 ESCUTCHEON ESCUTCHEON AL L SIDE GL
090B
/
L1G ns
p
00M18AK063110 ESCUTCHEON ESCUTCHEON AL L SIDE GL
090B
/
N1G 00M18AK063110 00M18AK063110 ESCUTCHEON ESCUTCHEON AL L SIDE GL
090B
/
N1S 00M18AK063210 00M18AK063210 ESCUTCHEON ESCUTCHEON AL L SIDE SL
090B
/
S1G ns
p
00M18AK063110 ESCUTCHEON ESCUTCHEON AL L SIDE GL
093B
/
F N ns
p
00M18AK063120 ESCUTCHEON ESCUTCHEON AL R SIDE GL
093B
/
K1G ns
p
00M18AK063120 ESCUTCHEON ESCUTCHEON AL R SIDE GL
093B
/
L1G ns
p
00M18AK063120 ESCUTCHEON ESCUTCHEON AL R SIDE GL
093B
/
N1G 00M18AK063120 00M18AK063120 ESCUTCHEON ESCUTCHEON AL R SIDE GL
093B
/
N1S 00M18AK063220 00M18AK063220 ESCUTCHEON ESCUTCHEON AL R SIDE SL
093B
/
S1G ns
p
00M18AK063120 ESCUTCHEON ESCUTCHEON AL R SIDE GL
110B 00M18AK121010 00M18AK121010 LINK LINK POWER
111B 00M18AK112010 00M18AK112010 SHAFT SHAFT POWER
112B
/
F N ns
p
00M18AK270110 BUTTON BUTTON POWER GL
112B
/
K1G ns
p
00M18AK270110 BUTTON BUTTON POWER GL
112B
/
L1G ns
p
00M18AK270110 BUTTON BUTTON POWER GL
112B
/
N1G 00M18AK270110 00M18AK270110 BUTTON BUTTON POWER GL
112B
/
N1S 00M18AK270210 00M18AK270210 BUTTON BUTTON POWER SL
112B
/
S1G ns
p
00M18AK270110 BUTTON BUTTON POWER GL
150B
/
F N ns
p
00M18AK063130 ESCUTCHEON ESCUTCHEON TRAY GL MZ378
150B
/
K1G ns
p
00M18AK063130 ESCUTCHEON ESCUTCHEON TRAY GL MZ378
150B
/
L1G ns
p
00M18AK063130 ESCUTCHEON ESCUTCHEON TRAY GL MZ378
POS. NO.
