Marantz SA-7S1 - Display

10
ENGLISH
DISPLAY
a Main display
The time display and text information of the disc to be played
as well as the setting menus and other displays appear on
the main display.
b 1-20, (music calendar)
The number of tracks recorded on the disc to be played,
the number of remaining tracks to be played, and the num-
ber of tracks programmed by program play appear here.
“ ” light when 21 or more tracks have been recorded on
the disc.
c
33
33
3 (play) indicator
This lights during disc play.
d
88
88
8 (pause) indicator
This lights when play is paused (temporarily stopped).
e , ALL, 1 (repeat) indicator
This lights during repeat play.
f A-B (A-B repeat) indicator
This lights during A-B repeat play.
g TRK (track) indicator
This lights above the display of the track number now play-
ing, for instance.
h PROG (program) indicator
This lights during program play.
i RNDM (random) indicator
This lights during random play.
j AMS (automatic music scan) indicator
This lights during AMS playback.
k CD, Super Audio CD, STEREO Disc indicator
This indicates the type of disc on the disc tray.
l TOTAL (total time) indicator
When the total remaining time or the total program time is
displayed, this lights above the display.
m REMAIN (remaining time) indicator
When the remaining playback time of a track is displayed,
this lights above the display.
n N SHP (noise shaper) indicator
This lights when the noise shaper is turned on. (See page
14)
o FIL 1 2 3 (filter 1, filter 2, filter 3) indicator
This indicates which filter among filter 1, filter 2, or filter 3
is currently selected. (See page 15)
p DCF (DC filter) indicator
This lights when the DC filter is turned on. (See page 14)
q D OFF (digital output off) indicator
This lights when the digital output setting for the CD signal
is set to off. (See page 14)
a b
cedfghj lmoqpnki
NAMES AND FUNCTIONS
