Marantz SA14 - 1.9 EXPLODED VIEW AND PARTS LIST

1-26
POS.
NO
VERS.
COLOR
PART NO.
(PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(PCS)
DESCRIPTION
PART NO.
(MJI)
001B /C1G
/S1G
/U1G
ASSY GOLD BLAST 410K248520
001B /F1N FRONT PANEL ASSY GOLD
AIR
410K248530
001B /U1B FRONT PANEL ASSY BLACK
LAST
410K248510
002B /C1G
/S1G
/U1G
FRONT PANEL GOLD BLAST 410K248110
002B /F1N FRONT PANEL GOLD
HAIR LINE
410K248120
002B /U1B FRONT PANEL BLACK 410K248010
003B /C1G
/S1G
/U1G
4822 426 10497 ESCUTCHEON GOLD 269J063110
003B /F1N 4822 426 10497 ESCUTCHEON GOLD 269J063110
003B /U1B 4822 426 10496 ESCUTCHEON BLACK 269J063010
005B GOLD 4822 381 12016 LENS IR GOLD 256J355030
005B BLACK 4822 381 12015 LENS IR BLACK 256J355040
006B GOLD RING GOLD NO.4 410K353120
006B BLACK RING BLACK NO.1 410K353010
007B SPRING FOR RING 410K115010
008B GOLD 9965 000 01554 BADGE MNTZ GOLD 313J251110
008B BLACK 9965 000 01553 BADGE MNTZ BLACK 313J251010
009B WINDOW 410K158010
010B GOLD BUSHING POWER/TRAY
GOLD
410K259110
010B BLACK BUSHING POWER/TRAY
BLACK
410K259010
012B GOLD BUSHING FL/PLAY BUTTON
GOLD
410K259120
012B BLACK BUSHING FL/PLAY BUTTON
BLACK
410K259020
014B INDICATOR SACD LOGO 410K265010
015B INDICATOR SACD/CD LENS 410K265020
016B LENS SACD/CD 392K355020
018B GOLD BUTTON POWER GOLD 410K270110
018B BLACK BUTTON POWER BLACK 410K270010
019B GOLD BUTTON PLAY/STOP GOLD 410K270120
019B BLACK BUTTON PLAY/STOP BLACK 410K270020
021B GOLD BUTTON OPEN/CLOSE GOLD 410K270130
021B BLACK BUTTON OPEN/CLOSE
BLACK
410K270030
028B BADGE SACD LOGO 410K251010
001D GOLD LID TOP GOLD 410K257110
001D BLACK LID TOP BLACK 410K257010
002D SHEET FOR TOP LID INSIDE 313J107010
005D GOLD 4822 502 14425 SCREW FOR TOP LID 323S010020
005D BLACK 4822 502 21693 SCREW FOR TOP LID 323S010030
006D GOLD 4822 426 10499 SIDE PANEL GOLD 269J249110
006D BLACK 4822 426 10498 SIDE PANEL BLACK 269J249010
009D GOLD 4822 502 14425 SCREW FOR SIDE PANEL 323S010020
009D BLACK 4822 502 21693 SCREW FOR SIDE PANEL 323S010030
004G LEG GOLD 163J057410
011G 9965 000 00588 POWER BUTTON LINK 376K121010
012G INSULATOR SHAFT
POWER BUTTON
410K120010
001M SCREW MECHANISM 410K010010
002M GOLD ESCUTCHEON GOLD 392K063150
002M BLACK ESCUTCHEON BLACK 392K063050
003M ESCUTCHEON SACD LOGO 392K063160
A001 GOLD MECHANISM SACD CDM-15M 392K304510
A001 BLACK MECHANISM SACD
CDM-15MB
392K304520
L001 /C1 MAINS TRANSF. 110/220V TS46010040
L001 /F1 MAINS TRANSF. 100V TS46010010
L001 /S1 MAINS TRANSF.MAIN 230V TS46010020
L001 /U1 MAINS TRANSF.MAIN 120V TS46010030
W001 /C1G MAINS CORD CORDSET
7A 250V
ZC02009010
W001 /F1N 4822 321 11337 MAINS CORD MITY
3P 12A 125V F
ZC01802080
W001 /S1G MAINS CORD S PORE
2P 10A 250V
ZC01804100
W001 /U1B MAINS CORD UL/CSA
10A 125V
ZC01803100
W001 /U1G MAINS CORD UL/CSA
10A 125V
ZC01803100
PACKING
001T /C1,/S1 USER GUIDE SA-14 410K851350
001T /F1 USER GUIDE SA-14 410K851110
001T /U1 USER GUIDE SA-14 410K851250
T100 UNIT KIT REMOTE
CONTROLLER RC-14SA
ZK410K0010
NOT STANDARD SPARE
PARTS
001S PACKING CASE 410K801010
002S CUSHION LEFT 410K809010
003S CUSION RIGHT 410K809020
006S PROTECTOR TRAY
ESCUTCHEON
392K269010
1.9 EXPLODED VIEW AND PARTS LIST
