Marantz SA14 - 2.7 ELECTRICAL PARTS LIST

2-37
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
301 9965 000 06889 SACD MECHAMISM ASSY
MOTOR DC <=37.5W
*ZZ001620R
303 9965 000 06890 HOLDER, STEEL MECHANISM 392K271200
309 9965 000 06891 SHOCK ABSORBER
FLOAT RUBBER
392K130200
312 9965 000 06892 SHOCK ABSORBER
FLOAT RUBBER
392K130210
315 9965 000 06893 STEEL TRAY GOLD 392K163200
319 9965 000 06894 DISC, STEEL STABILIZER 392K104200
320 9965 000 06895 HOLDER, STEEL SHAFT A 392K106200
321 9965 000 06896 HOLDER, STEEL SHAFT B 392K106210
323 9965 000 06897 PLATE, STEEL YOKE 392K104210
324 9965 000 06898 LEVER, STEEL LIFT 392K354200
325 9965 000 06899 SPRING HOLD 392K116200
326 9965 000 06900 BELT, DRIVING TIMING 392K264200
327 9965 000 06901 PULLEY, STEEL 392K262200
328 9965 000 06902 TOOTHED WHEEL GEAR 392K058200
329 9965 000 06903 TOOTHED
WHEEL TRAY GEAR
392K058210
340 9965 000 06904 GEAR TRAY RACK GEAR 392K058220
345 9965 000 06905 MAGNET 392K305200
346 9965 000 06906 DISC, PLASTIC
HIMELON SHEET
392K107200
709 9965 000 06907 SCREW, STEEL 392K010200
M703 9965 000 06908 LOADING MOTOR ASSY
MOTOR DC <=37.5W
*ZZ001630R
PWB-
D1-D3
9965 000 06909 PR.CIRCUIT, COMPACT DISC
TRAY SENSOR/SWITCH/
PICKUP IN S
*ZZ001650R
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
CNP
501
9965 000 06886 CONNECTOR, PLUG 4P *YP200040R
CNS
501
9965 000 06887 CONNECTOR, SOCKET 30P *YJ002240R
CNS
502
9965 000 06888 CONNECTOR, SOCKET 11P *YJ002250R
D0501 9965 000 06882 DIODE, RB521S30
POWER RECTIFIER
*HZ200150R
D0502 9965 000 06882 DIODE, RB521S30
POWER RECTIFIER
*HZ200150R
D0503 9965 000 06882 DIODE, RB521S30
POWER RECTIFIER
*HZ200150R
D0504 9965 000 06882 DIODE, RB521S30
POWER RECTIFIER
*HZ200150R
D0505 9965 000 06882 DIODE, DAP202U
POWER RECTIFIER
HZ20001210
D0801 9965 000 06882 DIODE, DAN202K
POWER RECTIFIER
HZ20002210
D0802 9965 000 06882 DIODE, DAP202U
POWER RECTIFIER
HZ20001210
DZ501 9340 548 52115 DIODE, PDZ5.1B REFERENCE *HZ300050R
FL801 9965 000 06884 FILTER, CERAMIC 20MHz *FQ000510R
IC501 9965 000 06864 IC TA1244FN I/V CONVERTER *HC106400R
IC502 9965 000 06865 PROCESSOR IX1517GE
RF SIGNAL
*HC106410R
IC503 9965 000 06866 IC IX2842AF
STEPPING MOTOR DRIVER
*HC106430R
IC504 9965 000 06867 IC NJM234V
SPINDLE MOTOR DRIVER
*HC106440R
IC506 9965 000 06868 IC BA6796FP
LOADING/FOCUS/TRACKING/
SPIN/SLED DRIVER
*HC106450R
IC507 9965 000 06869 IC NJM2904M ANA SWITCH *HC106470R
IC601 9965 000 06870 IC AD8052AR ANA AMPLIFIER *HC106480R
IC602 9965 000 06871 PROCESSOR IX1474GE
SACD DATA
*HC106490R
IC603 9965 000 06872 IC SC514870SJ 4M DRAM *HC106500R
IC606 9965 000 06873 IC IX1473GE
DIGITAL SERVO
*HC106510R
IC801 9965 000 06874 NON PROGRAMMED
MICROPROCESSOR
*HC106520R
IC802 9965 000 06875 IC IX1535GE
INPUT/OUTPUT EXPANDER
*HC106530R
IC803 4822 209 13204 IC PST9129N RESET *HC106540R
IC804 9965 000 06876 IC IX2839AF 1M SRAM *HC106550R
IC805 9965 000 06877 IC IX1539GE FLASH ROM *HC106560R
IC901 9965 000 06878 PROCESSOR CXD2751Q
SACD PLAYBACK SIGNAL
*HC106570R
IC902 9965 000 06879 IC ADC08351
A/D CONVERTER
*HC106580R
IC903 9965 000 06880 IC IX2840AF
SDRAM
*HC106590R
PH051 9965 000 06883 COUPLER, OPTO/PHOTO
RP1222
*HC200100R
PH052 9965 000 06883 COUPLER, OPTO/PHOTO
RP1222
*HC200100R
PH053 9965 000 06883 COUPLER, OPTO/PHOTO
RP1222
*HC200100R
Q0501 4822 130 60729 DIG.TRS, <1W DTC124EK *BA001040R
Q0502 4822 130 60729 DIG.TRS, <1W DTC124EK *BA001040R
Q0503 4822 130 60729 DIG.TRS, <1W DTC124EK *BA001040R
Q0504 9965 000 06881 DIG.TRS, <1W 2SA1955A *HX100080R
Q0505 9965 000 06881 DIG.TRS, <1W 2SA1955A *HX100080R
Q0601 4822 130 60729 DIG.TRS, <1W DTC124EK *BA001040R
Q0602 4822 130 60326 DIG.TRS, <1W DTA144EK *BA001050R
Q0801 4822 130 60729 DIG.TRS, <1W DTC124EK *BA001040R
X0601 9965 000 06885 CRYSTAL 54000MHz *JX000710R
2.7 ELECTRICAL PARTS LIST
GOLD
315 9965 000 06893 STEEL TRAY BLACK 392K163210BLACK
