Marantz SA14 - Page 24

POS.
NO
VERS.
COLOR
PART NO.
(PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(PCS)
DESCRIPTION
PART NO.
(MJI)
Q705
4822 130 63929 CHIP TRS. 2SC3324 (B) HX333241B0
Q708
Q709
4822 130 63928 CHIP TRS. 2SA1312 (B) HX113121B0
Q712
Q713
4822 130 63929 CHIP TRS. 2SC3324 (B) HX333241B0
Q716
Q717 4822 130 63928 CHIP TRS. 2SA1312 (B) HX113121B0
Q718 4822 130 63928 CHIP TRS. 2SA1312 (B) HX113121B0
Q801 IC PQ05RD21 5V 2A HC31905320
Q803 9965 000 03397 IC BA033FP HC96J33210
Q810 4822 130 43954 CHIP TRS. 2SD999 HX409992A0
Q811 4822 130 42836 F.E.T. 2SK246 (GR) HF202461C0
Q813 4822 130 43954 CHIP TRS. 2SD999 HX409992A0
Q815 4822 130 63929 CHIP TRS. 2SC3324 (B) HX333241B0
Q817 4822 130 61541 CHIP TRS. 2SC4116 HX341162B0
Q821 IC PQ09RF1 HC31909320
Q841 4822 130 43954 CHIP TRS. 2SD999 HX409992A0
Q851 4822 130 42836 F.E.T. 2SK246 (GR) HF202461C0
Q852 TRS. 2SD1415A HT41415100
Q853 4822 130 43233 TRS. 2SC2240 (GR BL) HT322402A0
Q855 4822 130 42836 F.E.T. 2SK246 (GR) HF202461C0
Q856 TRS. 2SB1020A HT21020100
Q857 4822 130 42949 TRS. 2SA970 (GR BL) HT109702A0
PP16-MISCELLANEOUS
FZ01 SERAMIC VIB. 432KHz
CSB432EB
FQ04323030
F801 /C1,/S1 4822 070 31002 FUSE 1 A 250V BS LISTED FS10100850
F801 /F1,/U1 FUSE 1.6A 250V UL CSA FS10160350
F811 /C1,/S1 4822 253 30394 FUSE T315MA 250V
BS LISTED
FS10031850
F811 /F1,/U1 FUSE 1A 250V UL CSA FS10100350
F812 /C1,/S1 4822 070 38001 FUSE 800 MA 250V BS LISTED FS10080850
F812 /F1,/U1 FUSE 1A 250V UL CSA FS10100350
F851 /C1,/S1 4822 070 38001 FUSE 800 MA 250V BS LISTED FS10080850
F851 /F1,/U1 FUSE 1A 250V UL CSA FS10100350
F852 /C1,/S1 4822 070 38001 FUSE 800 MA 250V BS LISTED FS10080850
F852 /F1,/U1 FUSE 1A 250V UL CSA FS10100350
JF51 4822 267 41009 TERMINAL RCA PIN JACK 2P YT02020890
JT02 4822 290 81638 TERMINAL RCA PIN JACK 1P YT02010790
JT03 4822 267 31369 OPT. CONNECTOR GP1F32T YJ15000090
J403 4822 290 61214 TERMINAL RCA PIN JACK 1P
GOLD
YT02010820
J404 4822 290 61214 TERMINAL RCA PIN JACK 1P
GOLD
YT02010820
J703 4822 265 20653 JACK XLR CANON PLUG YJ01003810
J704 4822 265 20653 JACK XLR CANON PLUG YJ01003810
LF01 4822 158 60654 FERRITE CORE BLM31A02 FC90030070
LT01 4822 142 60422 PULSE TRANSF. TP41042030
LT02 4822 158 60654 FERRITE CORE BLM31A02 FC90030070
LT03 4822 158 60654 FERRITE CORE BLM31A02 FC90030070
L400 4822 280 10353 RELAY NA-9-WK DC9V LY20090090
L503 4822 158 60654 FERRITE CORE BLM31A02 FC90030070
L504 CHIP INDUCTANCE
3.3
H NL322522
LU12332010
L505
4822 158 60654 FERRITE CORE BLM31A02 FC90030070
L508
L803 4822 158 60654 FERRITE CORE BLM31A02 FC90030070
L804 4822 158 60654 FERRITE CORE BLM31A02 FC90030070
L805 4822 158 60654 FERRITE CORE BLM31A02 FC90030070
SF01 4822 277 21559 SLIDE SWITCH SS02021150
S401 4822 277 21559 SLIDE SWITCH SS02021150
X501 4822 242 10818 CRYSTAL 33.8688MHz JX33001380
ZY01 PHOTO UNIT RPM6936-H4 HW10008210
PY16-FRONT CIRCUIT BOARD
PY16-CAPACITORS
CF21 4822 126 11558 CER. 0.1
F Z 50V DA17104110
CF22 4822 126 11558 CER. 0.1
F Z 50V DA17104110
CF23 4822 126 11558 CER. 0.1
F Z 50V DA17104110
CY01 4822 126 11558 CER. 0.1
F Z 50V DA17104110
CY02 4822 124 90352 ELECT 10
F M 16V OA10601620
CY03 4822 126 11558 CER. 0.1
F Z 50V DA17104110
CY04 4822 124 90354 ELECT 100
F M 16V OA10701620
CY05 4822 126 11558 CER. 0.1
F Z 50V DA17104110
CY06 4822 126 13089 CER. 33pF
5% DA15330110
CY07 4822 126 13089 CER. 33pF
5% DA15330110
CY08 4822 126 13089 CER. 33pF
5% DA15330110
CY09 4822 124 22274 ELECT 4.7
F M 50V OA47505020
CY10 4822 126 11558 CER. 0.1
F Z 50V DA17104110
PY16-RESISTORS(COMMON)
R
CARBON FILM FIXED RES.
5% 1/6W : RY03 RY04 RY06
RY08-RY11 RY13-RY23 RY25
RY26 RY29-RY36 RY41-RY45
PY16-SEMICONDUCTORS
DY05 4822 130 80326 L.E.D. LT3D8B RED HI10062320
DY06 4822 130 80326 L.E.D. LT3D8B RED HI10062320
DY11 4822 130 10667 ZENER DIODE 4.7V HD30471000
QY01 IC MN12510F FTD DRIVER HC10171020
QY03 4822 209 63184 IC LC74HC86 HC708600B0
QY05 4822 130 42715 TRS. 2SA1048 2SA933S
2SA1267
HT10001000
QY06 4822 130 42715 TRS. 2SA1048 2SA933S
2SA1267
HT10001000
QY07 4822 130 42715 TRS. 2SA1048 2SA933S
2SA1267
HT10001000
QY08 4822 130 41947 TRS. 2SC2458 2SC1740S
2SC3199
HT30001000
PY16-MISCELLANEOUS
JY02 JACK 15FE-ST-VK-N YJ07020110
LY21 FERRITE CORE
BL02RN2-R62T2 BEAD
FC90050130
LY22 FERRITE CORE
BL02RN2-R62T2 BEAD
FC90050130
LY23 FERRITE CORE
BL02RN2-R62T2 BEAD
FC90050130
SY01
SY08
4822 276 13537 PUSH SWITCH SKHVBF
260GF RED
SP01012030
VY01 4822 135 00194 DISPLAY UNIT 10-BT-196GK HQ31004410
XY01 4822 242 72527 SERAMIC VIB. CST4.00MGW FQ04004030
1-34
