3
3
1
2
3
1
2
3
1
2
AC IN
MODEL NO. SC-11S1
STEREO
BI-AMP
F.C.B.S. AMP MODE
REMOTE POWER CONTROL
TRIGGER OUT
12IN OUT
R
L
R
L
R
PRE OUT
IN OUT IN OUT
12
-
RECORDER
-
PRE OUT2 BALANCED
L L
PUSH
CONNECT
All LCD's are disappear
全消灯
OK is displayed when there is no problem with the communication
Connect connector
IN and Out of F.C.B.S
NG is displayed when there is problem with the communication
All LCD's and
All indicator lightup
全点灯
Press
Press
PressPressPress
After 3
seconds
TO [A] THE TRIM CHECK MODE
TRIM ࠴ࠚ࠶ࠢࡕ࠼߳
TO [B] EACH SWITCH CHECK MODE
ฦࠬࠗ࠶࠴ߩ࠴ࠚ࠶ࠢࡕ࠼߳
3
1
2
3
1
2
3
1
2
3
1
2
3
1
2
3
1
2
AC IN
MODEL NO. SC-11S1
STEREO
BI-AMP
PHONO
GND
F.C.B.S. AMP MODE
REMOTE POWER CONTROL
TRIGGER OUT
12IN OUT
R R
L
R
L
R
L
R
PHONO CD 1 2
-
LINE
-
PRE OUT
IN OUT IN OUT
12
-
RECORDER
-
PRE OUT2INPUT1 BALANCED
INPUT
LLR L
PUSH
PUSH
PUSH
PUSH
AC VoltmeterAC Voltmeter
Oscillator
4. SERVICE MODE
1. To enter the Service Mode, press the POWER ON/OFF
button with pressing the
DISPLAY and ATT buttons to
turn on the unit. (Or when the remote code "
166363" is
received while power is ON.)
When into the Service Mode, the memory is cleared and
the unit is initialized.
2. The Model name and Version number are displayed on
the Front LCD.
Whenever press the
DISPLAY button, the display
changes as follows.
Turn off power to quit service mode.
[A] THE TRIM CHECK MODE
Before press the TONE button, following connection and
setup are required.
1. 本体のDISPLAYボタンとATTボタンを押しながらPOW ER
ON/OFF
ボタンを押します。
（または、電源ON中にリモコンコード"166363"を受信し
ます。）これでサービスモードに入ります。
注意：サービスモードに入ると、全ての設定がクリアされ出荷
状態になります。
2. 始めにモデル名、バージョンが表示されます。
DISPLAYボタンを押すたびに下記の表示となります。
POWER ON/OFFボタンを押し、電源を切るとサービスモ
ードが解除されます。
[A] TRIMチェックモード
TONE ボタンを押す前に、下記の接続と設定を行います。
To Next Page
