Marantz SC-11S1 Service Manual

71
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.W.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
000B F N ns
p
99M22AJ248410 PANEL ASSY FRONT PANEL ASSY SC-11S1 GOLD
000B
/
K1G ns
p
99M22AJ248410 PANEL ASSY FRONT PANEL ASSY SC-11S1 GOLD
000B
/
N1G 99M22AJ248410 99M22AJ248410 PANEL ASSY FRONT PANEL ASSY SC-11S1 GOLD
000B
/
N1S 99M22AJ248420 99M22AJ248420 PANEL ASSY FRONT PANEL ASSY SC-11S1 SILVER
000B
/
U1G ns
p
99M22AJ248410 PANEL ASSY FRONT PANEL ASSY SC-11S1 GOLD
006B 00M10AJ158010 00M10AJ158010 WINDOW WINDOW
010B 00M22AJ355010 00M22AJ355010 LENS IR LENS
012B 00M10AJ105050 00M10AJ105050 CHASSIS FRONT MOLD CHASSIS
023B F N ns
p
00M10AJ265110 INDICATOR INDICATOR GOLD
023B
/
K1G ns
p
00M10AJ265110 INDICATOR INDICATOR GOLD
023B
/
N1G 00M10AJ265110 00M10AJ265110 INDICATOR INDICATOR GOLD
023B
/
N1S 00M10AJ265210 00M10AJ265210 INDICATOR INDICATOR SILVER
023B
/
U1G ns
p
00M10AJ265110 INDICATOR INDICATOR GOLD
024B 00M04AJ355010 00M04AJ355010 LENS LENS-S.MARK/OPERATE
031B F N ns
p
00M04AJ270110 BUTTON POWER BUTTON GOLD
031B
/
K1G ns
p
00M04AJ270110 BUTTON POWER BUTTON GOLD
031B
/
N1G 00M04AJ270110 00M04AJ270110 BUTTON POWER BUTTON GOLD
031B
/
N1S 00M04AJ270210 00M04AJ270210 BUTTON POWER BUTTON SILVER
031B
/
U1G ns
p
00M04AJ270110 BUTTON POWER BUTTON GOLD
035B 00M18AK355010 00M18AK355010 LENS SIDE LENS
037B F N ns
p
00M22AJ063110 ESCUTCHEON SIDE ESCUTCHEON L GOLD
037B
/
K1G ns
p
00M22AJ063110 ESCUTCHEON SIDE ESCUTCHEON L GOLD
037B
/
N1G 00M22AJ063110 00M22AJ063110 ESCUTCHEON SIDE ESCUTCHEON L GOLD
037B
/
N1S 00M22AJ063210 00M22AJ063210 ESCUTCHEON SIDE ESCUTCHEON L SILVER
037B
/
U1G ns
p
00M22AJ063110 ESCUTCHEON SIDE ESCUTCHEON L GOLD
039B F N ns
p
00M22AJ063120 ESCUTCHEON SIDE ESCUTCHEON R GOLD
039B
/
K1G ns
p
00M22AJ063120 ESCUTCHEON SIDE ESCUTCHEON R GOLD
039B
/
N1G 00M22AJ063120 00M22AJ063120 ESCUTCHEON SIDE ESCUTCHEON R GOLD
039B
/
N1S 00M22AJ063220 00M22AJ063220 ESCUTCHEON SIDE ESCUTCHEON R SILVER
039B
/
U1G ns
p
00M22AJ063120 ESCUTCHEON SIDE ESCUTCHEON R GOLD
041B F N ns
p
00M04AJ259210 BUSHING FUNCTION BUTTON BUSH GOLD
041B
/
K1G ns
p
00M04AJ259210 BUSHING FUNCTION BUTTON BUSH GOLD
041B
/
N1G 00M04AJ259210 00M04AJ259210 BUSHING FUNCTION BUTTON BUSH GOLD
041B
/
N1S 00M04AJ259110 00M04AJ259110 BUSHING FUNCTION BUTTON BUSH SILVER
041B
/
U1G ns
p
00M04AJ259210 BUSHING FUNCTION BUTTON BUSH GOLD
042B F N ns
p
00M04AJ270120 BUTTON FUNCTION BUTTON LIGHTING
(
GL
)
042B
/
K1G ns
p
00M04AJ270120 BUTTON FUNCTION BUTTON LIGHTING
(
GL
)
042B
/
N1G 00M04AJ270120 00M04AJ270120 BUTTON FUNCTION BUTTON LIGHTING
(
GL
)
042B
/
N1S 00M04AJ270220 00M04AJ270220 BUTTON FUNCTION BUTTON LIGHTING
(
SL
)
042B
/
U1G ns
p
00M04AJ270120 BUTTON FUNCTION BUTTON LIGHTING
(
GL
)
043B F N ns
p
00M04AJ270130 BUTTON FUNCTION BUTTON GOLD
043B
/
K1G ns
p
00M04AJ270130 BUTTON FUNCTION BUTTON GOLD
043B
/
N1G 00M04AJ270130 00M04AJ270130 BUTTON FUNCTION BUTTON GOLD
043B
/
N1S 00M04AJ270230 00M04AJ270230 BUTTON FUNCTION BUTTON SILVER
043B
/
U1G ns
p
00M04AJ270130 BUTTON FUNCTION BUTTON GOLD
046B 00M04AJ112110 00M04AJ112110 SHAFT VOLUME SHAFT
049B 00M04AJ259060 00M04AJ259060 BUSHING VOLUME JOINT BUSH
053B F N ns
p
00M04AJ353110 RING MASTER KNOB RING GOLD
053B
/
K1G ns
p
00M04AJ353110 RING MASTER KNOB RING GOLD
053B
/
N1G 00M04AJ353110 00M04AJ353110 RING MASTER KNOB RING GOLD
053B
/
N1S 00M04AJ353210 00M04AJ353210 RING MASTER KNOB RING SILVER
053B
/
U1G ns
p
00M04AJ353110 RING MASTER KNOB RING GOLD
054B F N ns
p
00M10AJ154110 KNOB MASTER KNOB GOLD
054B
/
K1G ns
p
00M10AJ154110 KNOB MASTER KNOB GOLD
054B
/
N1G 00M10AJ154110 00M10AJ154110 KNOB MASTER KNOB GOLD
054B
/
N1S 00M10AJ154210 00M10AJ154210 KNOB MASTER KNOB SILVER
054B
/
U1G ns
p
00M10AJ154110 KNOB MASTER KNOB GOLD
001D F N ns
p
00M18AK249110 SIDE PANEL SIDE PANEL GOLD
001D
/
K1G ns
p
00M18AK249110 SIDE PANEL SIDE PANEL GOLD
001D
/
N1G 00M18AK249110 00M18AK249110 SIDE PANEL SIDE PANEL GOLD
001D
/
N1S 00M18AK249210 00M18AK249210 SIDE PANEL SIDE PANEL SILVER
001D
/
U1G ns
p
00M18AK249110 SIDE PANEL SIDE PANEL GOLD
005D F N ns
p
00M21AJ257110 LID TOP LID GOLD
005D
/
K1G ns
p
00M21AJ257110 LID TOP LID GOLD
005D
/
N1G 00M21AJ257110 00M21AJ257110 LID TOP LID GOLD
005D
/
N1S 00M21AJ257210 00M21AJ257210 LID TOP LID SILVER
005D
/
U1G ns
p
00M21AJ257110 LID TOP LID GOLD
POS. NO.
