Marantz SC-11S1 Service Manual

72
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.W.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
012D F N ns
p
00M21AJ003110 PERFORATED TOP COVER NET GOLD
012D
/
K1G ns
p
00M21AJ003110 PERFORATED TOP COVER NET GOLD
012D
/
N1G 00M21AJ003110 00M21AJ003110 PERFORATED TOP COVER NET GOLD
012D
/
N1S 00M21AJ003210 00M21AJ003210 PERFORATED TOP COVER NET SILVER
012D
/
U1G ns
p
00M21AJ003110 PERFORATED TOP COVER NET GOLD
004G F N ns
p
00M04AJ057510 LUG EYELET LEGS GOLD
004G
/
K1G ns
p
00M04AJ057510 LUG EYELET LEGS GOLD
004G
/
N1G 00M04AJ057510 00M04AJ057510 LUG EYELET LEGS GOLD
004G
/
N1S 00M04AJ057520 00M04AJ057520 LUG EYELET LEGS SILVER
004G
/
U1G ns
p
00M04AJ057510 LUG EYELET LEGS GOLD
J001 00MYJ04002640 00MYJ04002640 JACK # R-301
(
21
)
AC INLET MAXES CABLE CO.LTD
L001 F N ns
p
00MTS40701080 TRANSF. # POWER TRANS FOR SC-11S1 100V
L001
/
K1G ns
p
00MTS40701100 TRANSF. # POWER TRANS FOR SC-11S1 230V
L001
/
N1G 00MTS40701100 00MTS40701100 TRANSF. # POWER TRANS FOR SC-11S1 230V
L001
/
N1S 00MTS40701100 00MTS40701100 TRANSF. # POWER TRANS FOR SC-11S1 230V
L001
/
U1G ns
p
00MTS40701090 TRANSF. # POWER TRANS FOR SC-11S1 120V
L002 00MFN21010070 00MFN21010070 EMI FILTER ! CHOKE INDUCTOR FOR SC-11S1
L003 00MFC50160030 00MFC50160030 FERRITE CORE FERRITE CORE FOR W018 W020
L004 00MFC50160030 00MFC50160030 FERRITE CORE FERRITE CORE FOR W019
L005 00MFC50160030 00MFC50160030 FERRITE CORE FERRITE CORE FOR W021
L006 00MFC50160030 00MFC50160030 FERRITE CORE FERRITECORE FOR W007
P101 ns
p
ns
p
PWB ASSY MAIN PWB ASSY
P301 ns
p
ns
p
PWB ASSY PHONO PWB ASSY
P601 ns
p
ns
p
PWB ASSY UNBALANCE PWB ASSY
P851 ns
p
ns
p
PWB ASSY MAIN CAP. PWB ASSY
P871 ns
p
ns
p
PWB ASSY POWER SUPPLY PWB ASSY
P881 ns
p
ns
p
PWB ASSY FUSE PWB ASSY
P891 ns
p
ns
p
PWB ASSY POWER SW ASSY
P951 ns
p
ns
p
PWB ASSY PHONE PWB ASSY
PH81 ns
p
ns
p
PWB ASSY BIAS PWB ASSY
PU01 ns
p
ns
p
PWB ASSY FRONT PWB ASSY
PU21 ns
p
ns
p
PWB ASSY DISPLAY PWB ASSY
PU31 ns
p
ns
p
PWB ASSY BACK LIGHT PWB ASSY
PU41 ns
p
ns
p
PWB ASSY I/R SENSOR PWB ASSY
PU51 ns
p
ns
p
PWB ASSY INPUT SELECTOR PWB ASSY
PU61 ns
p
ns
p
PWB ASSY VOLUME PWB ASSY
PU71 ns
p
ns
p
PWB ASSY FCBS PWB ASSY
VD01 00MHQ22901990 00MHQ22901990 DISPLAY LCD MODULE FOR PM-11S1
W023 ns
p
00MYU14100520 FPC FFC 14P JU07 TO JV01
PACKING
001T F N ns
p
00M22AJ851110 USER GUIDE USER GUIDE SC-11S1 F
001T
/
K1G ns
p
00M22AJ851350 USER GUIDE USER GUIDE SC-11S1 K
001T
/
N1G 00M22AJ851310 00M22AJ851310 USER GUIDE USER GUIDE SC-11S1 N
001T
/
N1S 00M22AJ851310 00M22AJ851310 USER GUIDE USER GUIDE SC-11S1 N
001T
/
U1G ns
p
00M22AJ851310 USER GUIDE USER GUIDE SC-11S1 N
W001 F N ns
p
00D2062141002 MAINS CORD # MAINS CORD FOR JAPAN
W001
/
K1G ns
p
00MZC01808030 MAINS CORD # MAINS CORD 250V 10A FOR CHINA
W001
/
N1G 00MZC01803080 00MZC01803080 MAINS CORD # MAINS CORD 10A 250V CLASS2 FOR EUROPE
W001
/
N1S 00MZC01803080 00MZC01803080 MAINS CORD # MAINS CORD 10A 250V CLASS2 FOR EUROPE
W001
/
U1G ns
p
00MZC01802100 MAINS CORD # MAINS CORD 125V13A UL/CSA FOR USA
Z001 00MZK340J0020 00MZK340J0020 UNIT KIT REMOTE CONTROLER RC001PM
NOT STANDARD SPARE PART
001S ns
p
00M22AJ801010 PACKING CASE PACKING CASE
002S
/
N1G ns
p
00M22AJ805010 MASS CARTON MASTER CARTON
002S
/
N1S ns
p
00M22AJ805010 MASS CARTON MASTER CARTON
003S ns
p
00M31AK809010 CUSHION CUSHION L
004S ns
p
00M31AK809020 CUSHION CUSHION R
