Marantz SC-11S1 Service Manual

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.W.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
MAIN PWB P101
(
00MWG22AJ101-
)
P101 C127 00MOF55103580 00MOF55103580 FILM CAP. 0.01UF 100V +-5% FNS
P101 C128 ns
p
00MOA476025Z0 ELECT. CAP. ROS-25V 470M - G3 #PE - T2
(
47UF 25V
)
P101 C129 ns
p
00MOA476025Z0 ELECT. CAP. ROS-25V 470M - G3 #PE - T2
(
47UF 25V
)
P101 C405
/
K1G ns
p
00MOF55221590 FILM CAP. 220PF 200V +-5% FAS
P101 C405
/
N1G 00MOF55221590 00MOF55221590 FILM CAP. 220PF 200V +-5% FAS
P101 C405
/
N1S 00MOF55221590 00MOF55221590 FILM CAP. 220PF 200V +-5% FAS
P101 C406
/
K1G ns
p
00MOF55221590 FILM CAP. 220PF 200V +-5% FAS
P101 C406
/
N1G 00MOF55221590 00MOF55221590 FILM CAP. 220PF 200V +-5% FAS
P101 C406
/
N1S 00MOF55221590 00MOF55221590 FILM CAP. 220PF 200V +-5% FAS
P101 C407
/
K1G ns
p
00MOF55221590 FILM CAP. 220PF 200V +-5% FAS
P101 C407
/
N1G 00MOF55221590 00MOF55221590 FILM CAP. 220PF 200V +-5% FAS
P101 C407
/
N1S 00MOF55221590 00MOF55221590 FILM CAP. 220PF 200V +-5% FAS
P101 C408
/
K1G ns
p
00MOF55221590 FILM CAP. 220PF 200V +-5% FAS
P101 C408
/
N1G 00MOF55221590 00MOF55221590 FILM CAP. 220PF 200V +-5% FAS
P101 C408
/
N1S 00MOF55221590 00MOF55221590 FILM CAP. 220PF 200V +-5% FAS
P101 C409
/
K1G ns
p
00MOF55221590 FILM CAP. 220PF 200V +-5% FAS
P101 C409
/
N1G 00MOF55221590 00MOF55221590 FILM CAP. 220PF 200V +-5% FAS
P101 C409
/
N1S 00MOF55221590 00MOF55221590 FILM CAP. 220PF 200V +-5% FAS
P101 C410
/
K1G ns
p
00MOF55221590 FILM CAP. 220PF 200V +-5% FAS
P101 C410
/
N1G 00MOF55221590 00MOF55221590 FILM CAP. 220PF 200V +-5% FAS
P101 C410
/
N1S 00MOF55221590 00MOF55221590 FILM CAP. 220PF 200V +-5% FAS
P101 C411
/
K1G ns
p
00MOF55221590 FILM CAP. 220PF 200V +-5% FAS
P101 C411
/
N1G 00MOF55221590 00MOF55221590 FILM CAP. 220PF 200V +-5% FAS
P101 C411
/
N1S 00MOF55221590 00MOF55221590 FILM CAP. 220PF 200V +-5% FAS
P101 C412
/
K1G ns
p
00MOF55221590 FILM CAP. 220PF 200V +-5% FAS
P101 C412
/
N1G 00MOF55221590 00MOF55221590 FILM CAP. 220PF 200V +-5% FAS
P101 C412
/
N1S 00MOF55221590 00MOF55221590 FILM CAP. 220PF 200V +-5% FAS
P101 C413 ns
p
00MOA106035Z0 ELECT. CAP. ROS-35V 100M - F3 #PE - T2
(
10UF 35V
)
P101 C414 ns
p
00MOA106035Z0 ELECT. CAP. ROS-35V 100M - F3 #PE - T2
(
10UF 35V
)
P101 C415 ns
p
00MOA106035Z0 ELECT. CAP. ROS-35V 100M - F3 #PE - T2
(
10UF 35V
)
P101 C416 ns
p
00MOA106035Z0 ELECT. CAP. ROS-35V 100M - F3 #PE - T2
(
10UF 35V
)
P101 C417 ns
p
00MOA106035Z0 ELECT. CAP. ROS-35V 100M - F3 #PE - T2
(
10UF 35V
)
P101 C418 ns
p
00MOA106035Z0 ELECT. CAP. ROS-35V 100M - F3 #PE - T2
(
10UF 35V
)
P101 C419 ns
p
00MOA106035Z0 ELECT. CAP. ROS-35V 100M - F3 #PE - T2
(
10UF 35V
)
P101 C420 ns
p
00MOA106035Z0 ELECT. CAP. ROS-35V 100M - F3 #PE - T2
(
10UF 35V
)
P101 C421 00MOF56331540 00MOF56331540 FILM CAP. STAR
(
126
)
100VDC331J7-10
P101 C422 00MOF56331540 00MOF56331540 FILM CAP. STAR
(
126
)
100VDC331J7-10
P101 C423 00MOF56331540 00MOF56331540 FILM CAP. STAR
(
126
)
100VDC331J7-10
P101 C424 00MOF56331540 00MOF56331540 FILM CAP. STAR
(
126
)
100VDC331J7-10
P101 C425 00MOF56331540 00MOF56331540 FILM CAP. STAR
(
126
)
100VDC331J7-10
P101 C426 00MOF56331540 00MOF56331540 FILM CAP. STAR
(
126
)
100VDC331J7-10
P101 C427 00MOF56331540 00MOF56331540 FILM CAP. STAR
(
126
)
100VDC331J7-10
P101 C428 00MOF56331540 00MOF56331540 FILM CAP. STAR
(
126
)
100VDC331J7-10
P101 C429 ns
p
00MGD05000160 RES. 0 OHM +-5% 1/6W
P101 C430 ns
p
00MGD05000160 RES. 0 OHM +-5% 1/6W
P101 C431 ns
p
00MGD05000160 RES. 0 OHM +-5% 1/6W
P101 C432 ns
p
00MGD05000160 RES. 0 OHM +-5% 1/6W
P101 C433 ns
p
00MGD05000160 RES. 0 OHM +-5% 1/6W
P101 C434 ns
p
00MGD05000160 RES. 0 OHM +-5% 1/6W
P101 C435 ns
p
00MGD05000160 RES. 0 OHM +-5% 1/6W
P101 C436 ns
p
00MGD05000160 RES. 0 OHM +-5% 1/6W
P101 C437 ns
p
00MOA227025R0 ELECT. CAP. ROA-25V 221M -H5 #PE - T2
(
220UF 25V
)
P101 C438 ns
p
00MOA227025R0 ELECT. CAP. ROA-25V 221M -H5 #PE - T2
(
220UF 25V
)
P101 C439 ns
p
00MOA227025R0 ELECT. CAP. ROA-25V 221M -H5 #PE - T2
(
220UF 25V
)
P101 C440 ns
p
00MOA227025R0 ELECT. CAP. ROA-25V 221M -H5 #PE - T2
(
220UF 25V
)
P101 C441 ns
p
00MOA227025R0 ELECT. CAP. ROA-25V 221M -H5 #PE - T2
(
220UF 25V
)
P101 C442 ns
p
00MOA227025R0 ELECT. CAP. ROA-25V 221M -H5 #PE - T2
(
220UF 25V
)
P101 C443 ns
p
00MOA227025R0 ELECT. CAP. ROA-25V 221M -H5 #PE - T2
(
220UF 25V
)
P101 C444 ns
p
00MOA227025R0 ELECT. CAP. ROA-25V 221M -H5 #PE - T2
(
220UF 25V
)
P101 C445 ns
p
00MGD05000160 RES. 0 OHM +-5% 1/6W
P101 C446 ns
p
00MGD05000160 RES. 0 OHM +-5% 1/6W
P101 C447 ns
p
00MGD05000160 RES. 0 OHM +-5% 1/6W
P101 C448 ns
p
00MGD05000160 RES. 0 OHM +-5% 1/6W
P101 C449 00MOF56331540 00MOF56331540 FILM CAP. STAR
(
126
)
100VDC331J7-10
P101 C450 00MOF56331540 00MOF56331540 FILM CAP. STAR
(
126
)
100VDC331J7-10
P101 C451 ns
p
00MOA476025Z0 ELECT. CAP. ROS-25V 470M - G3 #PE - T2
(
47UF 25V
)
P101 C452 ns
p
00MOA476025Z0 ELECT. CAP. ROS-25V 470M - G3 #PE - T2
(
47UF 25V
)
