Marantz SC-11S1 Service Manual

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.W.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
P101 C453 ns
p
00MOA477025R0 ELECT. CAP. ROA-25V 471M -I6 #PE - S13
(
470UF 25V
)
P101 C454 ns
p
00MOA477025R0 ELECT. CAP. ROA-25V 471M -I6 #PE - S13
(
470UF 25V
)
P101 C455 ns
p
00MOA477025R0 ELECT. CAP. ROA-25V 471M -I6 #PE - S13
(
470UF 25V
)
P101 C456 ns
p
00MOA477025R0 ELECT. CAP. ROA-25V 471M -I6 #PE - S13
(
470UF 25V
)
P101 C501 ns
p
00MOA227025R0 ELECT. CAP. ROA-25V 221M -H5 #PE - T2
(
220UF 25V
)
P101 C502 ns
p
00MOA227025R0 ELECT. CAP. ROA-25V 221M -H5 #PE - T2
(
220UF 25V
)
P101 C503 ns
p
00MOA227016Z0 ELECT. CAP. ROS-16V 221M - H5 #PE - T2
(
220UF 16V
)
P101 C504 ns
p
00MOA227016Z0 ELECT. CAP. ROS-16V 221M - H5 #PE - T2
(
220UF 16V
)
P101 C505 ns
p
00MOA476025R0 ELECT. CAP. ROA-25V 470M -G3 # - T2
P101 C506 ns
p
00MOA476025R0 ELECT. CAP. ROA-25V 470M -G3 # - T2
P101 C507 ns
p
00MOA476025Z0 ELECT. CAP. ROS-25V 470M - G3 #PE - T2
(
47UF 25V
)
P101 C508 ns
p
00MOA476025Z0 ELECT. CAP. ROS-25V 470M - G3 #PE - T2
(
47UF 25V
)
P101 C509 ns
p
00MOA226025Z0 ELECT. CAP. ROA-25V 220M - F3 #PE - T2
(
22UF 25V
)
P101 C510 ns
p
00MOA226025Z0 ELECT. CAP. ROA-25V 220M - F3 #PE - T2
(
22UF 25V
)
P101 C513 ns
p
00MOA476025Z0 ELECT. CAP. ROS-25V 470M - G3 #PE - T2
(
47UF 25V
)
P101 C514 ns
p
00MOA476025Z0 ELECT. CAP. ROS-25V 470M - G3 #PE - T2
(
47UF 25V
)
P101 C515 00MOF56681540 00MOF56681540 FILM CAP. STAR
(
126
)
100VDC681J7-10
P101 C516 00MOF56681540 00MOF56681540 FILM CAP. STAR
(
126
)
100VDC681J7-10
P101 C517 00MOF56331540 00MOF56331540 FILM CAP. STAR
(
126
)
100VDC331J7-10
P101 C518 00MOF56331540 00MOF56331540 FILM CAP. STAR
(
126
)
100VDC331J7-10
P101 C519 ns
p
00MOA476025Z0 ELECT. CAP. ROS-25V 470M - G3 #PE - T2
(
47UF 25V
)
P101 C520 ns
p
00MOA476025Z0 ELECT. CAP. ROS-25V 470M - G3 #PE - T2
(
47UF 25V
)
P101 C521 ns
p
00MOA226025R0 ELECT. CAP. ROA-25V 220M - F3#PE - T2
(
22UF 25V
)
P101 C522 ns
p
00MOA226025R0 ELECT. CAP. ROA-25V 220M - F3#PE - T2
(
22UF 25V
)
P101 C523 ns
p
00MOA226025R0 ELECT. CAP. ROA-25V 220M - F3#PE - T2
(
22UF 25V
)
P101 C524 ns
p
00MOA226025R0 ELECT. CAP. ROA-25V 220M - F3#PE - T2
(
22UF 25V
)
P101 C525 ns
p
00MOA477025R0 ELECT. CAP. ROA-25V 471M -I6 #PE - S13
(
470UF 25V
)
P101 C526 ns
p
00MOA477025R0 ELECT. CAP. ROA-25V 471M -I6 #PE - S13
(
470UF 25V
)
P101 C527 ns
p
00MOA477025R0 ELECT. CAP. ROA-25V 471M -I6 #PE - S13
(
470UF 25V
)
P101 C528 ns
p
00MOA477025R0 ELECT. CAP. ROA-25V 471M -I6 #PE - S13
(
470UF 25V
)
P101 C529 ns
p
00MOA477025R0 ELECT. CAP. ROA-25V 471M -I6 #PE - S13
(
470UF 25V
)
P101 C530 ns
p
00MOA477025R0 ELECT. CAP. ROA-25V 471M -I6 #PE - S13
(
470UF 25V
)
P101 C531 ns
p
00MOA477025R0 ELECT. CAP. ROA-25V 471M -I6 #PE - S13
(
470UF 25V
)
P101 C532 ns
p
00MOA477025R0 ELECT. CAP. ROA-25V 471M -I6 #PE - S13
(
470UF 25V
)
P101 C596 ns
p
00MOA476025Z0 ELECT. CAP. ROS-25V 470M - G3 #PE - T2
(
47UF 25V
)
P101 C801 ns
p
00MOA225100Z0 ELECT. CAP. ROS-100V2R2 F3 #PE-T2
P101 C802 ns
p
00MOA225100Z0 ELECT. CAP. ROS-100V2R2 F3 #PE-T2
P101 C803 ns
p
00MOA477025R0 ELECT. CAP. ROA-25V 471M -I6 #PE - S13
(
470UF 25V
)
P101 C804 ns
p
00MOA477025R0 ELECT. CAP. ROA-25V 471M -I6 #PE - S13
(
470UF 25V
)
P101 C805 ns
p
00MOA477025R0 ELECT. CAP. ROA-25V 471M -I6 #PE - S13
(
470UF 25V
)
P101 C806 ns
p
00MOA477025R0 ELECT. CAP. ROA-25V 471M -I6 #PE - S13
(
470UF 25V
)
P101 C807 ns
p
00MOA477025R0 ELECT. CAP. ROA-25V 471M -I6 #PE - S13
(
470UF 25V
)
P101 C808 ns
p
00MOA477025R0 ELECT. CAP. ROA-25V 471M -I6 #PE - S13
(
470UF 25V
)
P101 C809 ns
p
00MOA477025R0 ELECT. CAP. ROA-25V 471M -I6 #PE - S13
(
470UF 25V
)
P101 C810 ns
p
00MOA477025R0 ELECT. CAP. ROA-25V 471M -I6 #PE - S13
(
470UF 25V
)
P101 C811 ns
p
00MOA10605020 ELECT. CAP. 10 UF M 50V RA-2
P101 C812 ns
p
00MOA10605020 ELECT. CAP. 10 UF M 50V RA-2
P101 C814 ns
p
00MOA226025Z0 ELECT. CAP. ROS-25V 220M - F3 #PE - T2
(
22UF 25V
)
P101 CF01 ns
p
00MGD05000160 RES. 0 OHM +-5% 1/6W
P101 CF02 ns
p
00MGD05000160 RES. 0 OHM +-5% 1/6W
P101 CF03 ns
p
00MOA225100Z0 ELECT. CAP. ROS-100V2R2 F3 #PE-T2
P101 CF04 ns
p
00MOA225100Z0 ELECT. CAP. ROS-100V2R2 F3 #PE-T2
P101 CF05 ns
p
00MOA225100Z0 ELECT. CAP. ROS-100V2R2 F3 #PE-T2
P101 CF06 ns
p
00MOA225100Z0 ELECT. CAP. ROS-100V2R2 F3 #PE-T2
P101 CF07 ns
p
00MOA227025R0 ELECT. CAP. ROA-25V 221M -H5 #PE - T2
(
220UF 25V
)
P101 CF08 ns
p
00MOA227025R0 ELECT. CAP. ROA-25V 221M -H5 #PE - T2
(
220UF 25V
)
P101 CF09 ns
p
00MOA227025R0 ELECT. CAP. ROA-25V 221M -H5 #PE - T2
(
220UF 25V
)
P101 CF10 ns
p
00MOA227025R0 ELECT. CAP. ROA-25V 221M -H5 #PE - T2
(
220UF 25V
)
P101 CH01 ns
p
00MOA226025Z0 ELECT. CAP. ROA-25V 220M - F3 #PE - T2
(
22UF 25V
)
P101 CH02 ns
p
00MOA226025Z0 ELECT. CAP. ROA-25V 220M - F3 #PE - T2
(
22UF 25V
)
P101 CH03 ns
p
00MOA226025Z0 ELECT. CAP. ROA-25V 220M - F3 #PE - T2
(
22UF 25V
)
P101 CH04 ns
p
00MOA226025Z0 ELECT. CAP. ROA-25V 220M - F3 #PE - T2
(
22UF 25V
)
P101 CH05 ns
p
00MOA476025R0 ELECT. CAP. ROA-25V 470M -G3 # - T2
P101 CH06 ns
p
00MOA476025R0 ELECT. CAP. ROA-25V 470M -G3 # - T2
P101 CH11 ns
p
00MOA476025Z0 ELECT. CAP. ROS-25V 470M - G3 #PE - T2
(
47UF 25V
)
P101 CH12 ns
p
00MOA476025Z0 ELECT. CAP. ROS-25V 470M - G3 #PE - T2
(
47UF 25V
)
P101 CH13 ns
p
00MOA227025R0 ELECT. CAP. ROA-25V 221M -H5 #PE - T2
(
220UF 25V
)
P101 CH14 ns
p
00MOA227025R0 ELECT. CAP. ROA-25V 221M -H5 #PE - T2
(
220UF 25V
)
81
