Marantz SC-11S1 Service Manual

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.W.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
PU01 CU42 00MEY10601070 00MEY10601070 TANTL.CAP CHIP 10UF/ 10V
PU01 CU43 ns
p
00MDK96103300 CER. CAP. 0.01UF +-10% 50V C1608JB1H103K
PU01 CU44 00MEY10601070 00MEY10601070 TANTL.CAP CHIP 10UF/ 10V
PU01 CU45 ns
p
00MDK96103300 CER. CAP. 0.01UF +-10% 50V C1608JB1H103K
PU01 CU46 ns
p
00MDK96103300 CER. CAP. 0.01UF +-10% 50V C1608JB1H103K
PU01 CU47 00MEY10601070 00MEY10601070 TANTL.CAP CHIP 10UF/ 10V
PU01 CU48 ns
p
00MDK96103300 CER. CAP. 0.01UF +-10% 50V C1608JB1H103K
PU01 CU49 00MEY10601070 00MEY10601070 TANTL.CAP CHIP 10UF/ 10V
PU01 CU50 ns
p
00MDK96103300 CER. CAP. 0.01UF +-10% 50V C1608JB1H103K
PU01 CU51 00MEY10601070 00MEY10601070 TANTL.CAP CHIP 10UF/ 10V
PU01 CU52 ns
p
00MDK96103300 CER. CAP. 0.01UF +-10% 50V C1608JB1H103K
PU01 CU53 ns
p
00MDK96103300 CER. CAP. 0.01UF +-10% 50V C1608JB1H103K
PU01 CU54 ns
p
00MDK96104300 CER. CAP. C1608X7R1H104K
PU01 DD02 00MHZ20018050 00MHZ20018050 CHIP DIODE 1SS302
PU01 DU61 00MHI10046080 00MHI10046080 L.E.D. BLUE LED SELU2E10C-P-E/F 3
PU01 DU62 00MHI10047080 00MHI10047080 L.E.D. SEL6E10C BLUE LED
PU01 DU63 00MHI10047080 00MHI10047080 L.E.D. SEL6E10C BLUE LED
PU01 DU71 00MHI10046080 00MHI10046080 L.E.D. BLUE LED SELU2E10C-P-E/F 3
PU01 DU72 00MHI10047080 00MHI10047080 L.E.D. SEL6E10C BLUE LED
PU01 DU73 00MHI10047080 00MHI10047080 L.E.D. SEL6E10C BLUE LED
PU01 LU01 00MFC90020210 00MFC90020210 FERRITE CORE MLB-1608-1000A-N2
PU01 LU02 00MFC90020210 00MFC90020210 FERRITE CORE MLB-1608-1000A-N2
PU01 LU03 00MFC90020210 00MFC90020210 FERRITE CORE MLB-1608-1000A-N2
PU01 LU04 00MFC90020210 00MFC90020210 FERRITE CORE MLB-1608-1000A-N2
PU01 LU05 00MFC90020210 00MFC90020210 FERRITE CORE MLB-1608-1000A-N2
PU01 LU06 00MFC90020210 00MFC90020210 FERRITE CORE MLB-1608-1000A-N2
PU01 LU07 00MFC90020210 00MFC90020210 FERRITE CORE MLB-1608-1000A-N2
PU01 LU08 00MFC90020210 00MFC90020210 FERRITE CORE MLB-1608-1000A-N2
PU01 LU09 00MFC90020210 00MFC90020210 FERRITE CORE MLB-1608-1000A-N2
PU01 LU10 00MFC90020210 00MFC90020210 FERRITE CORE MLB-1608-1000A-N2
PU01 LU11 00MFC90020210 00MFC90020210 FERRITE CORE MLB-1608-1000A-N2
PU01 LU12 00MFC90020210 00MFC90020210 FERRITE CORE MLB-1608-1000A-N2
PU01 LU13 00MFC90020210 00MFC90020210 FERRITE CORE MLB-1608-1000A-N2
PU01 LU14 00MFC90020210 00MFC90020210 FERRITE CORE MLB-1608-1000A-N2
PU01 LU15 00MFC90020210 00MFC90020210 FERRITE CORE MLB-1608-1000A-N2
PU01 LU16 00MFC90020210 00MFC90020210 FERRITE CORE MLB-1608-1000A-N2
PU01 LU17 00MFC90020210 00MFC90020210 FERRITE CORE MLB-1608-1000A-N2
PU01 LU22 00MFC90020210 00MFC90020210 FERRITE CORE MLB-1608-1000A-N2
PU01 LU25 00MFC90020210 00MFC90020210 FERRITE CORE MLB-1608-1000A-N2
PU01 LU26 00MFC90020210 00MFC90020210 FERRITE CORE MLB-1608-1000A-N2
PU01 LU27 00MFC90020210 00MFC90020210 FERRITE CORE MLB-1608-1000A-N2
PU01 LU31 00MFC90090010 00MFC90090010 FERRITE CORE ZBF503D-00
(
TA
)
-01
PU01 LU32 00MFC90090010 00MFC90090010 FERRITE CORE ZBF503D-00
(
TA
)
-01
PU01 QU01 00MHC60037010 00MHC60037010 U-PRO HD64F3687H FLASH
PU01 00M22AJ499A00 00M22AJ499A00 SOFTWARE SOFRWARE FOR QU01 SC-11S1 VER. 001
PU01 QU02 00MHC10229210 00MHC10229210 IC BD4727G 2.7V RESET IC
PU01 QU03 00MHC10433990 00MHC10433990 IC AT24C08AN-10SI-2.7
PU01 QU06 00MBA21303000 00MBA21303000 TRS. DTC124EU RN1303 UMT TYPE
PU01 QU07 00MBA21303000 00MBA21303000 TRS. DTC124EU RN1303 UMT TYPE
PU01 QU08 00MBA21303000 00MBA21303000 TRS. DTC124EU RN1303 UMT TYPE
PU01 QU09 00MBA21303000 00MBA21303000 TRS. DTC124EU RN1303 UMT TYPE
PU01 QU10 00MBA21303000 00MBA21303000 TRS. DTC124EU RN1303 UMT TYPE
PU01 QU12 00D2622018902 00D2622018902 IC TC4S30F
(
TE85L
)
+C
PU01 QU17 00MBA21303000 00MBA21303000 TRS. DTC124EU RN1303 UMT TYPE
PU01 QU18 00MBA21303000 00MBA21303000 TRS. DTC124EU RN1303 UMT TYPE
PU01 QU19 00MBA21303000 00MBA21303000 TRS. DTC124EU RN1303 UMT TYPE
PU01 QU21 00MBA21303000 00MBA21303000 TRS. DTC124EU RN1303 UMT TYPE
PU01 QU22 00MBA12303000 00MBA12303000 TRS. DTA124EU RN2303 UMT TYPE
PU01 QU23 00MHX300012A0 00MHX300012A0 CHIP TRS. 2SC4081
(
Q R
)
2SC4116
(
Y GR
)
PU01 QU24 00MHX300012A0 00MHX300012A0 CHIP TRS. 2SC4081
(
Q R
)
2SC4116
(
Y GR
)
PU01 QU25 00MHX300012A0 00MHX300012A0 CHIP TRS. 2SC4081
(
Q R
)
2SC4116
(
Y GR
)
PU01 QU30 00MBA12303000 00MBA12303000 TRS. DTA124EU RN2303 UMT TYPE
PU01 QU31 00MBA21303000 00MBA21303000 TRS. DTC124EU RN1303 UMT TYPE
PU01 QU32 00MHT600121A0 00MHT600121A0 TRS. KTA1268 PNP TRANSISTOR RANK=GR
PU01 QU33 00MHC809449R0 00MHC809449R0 IC 74HC4094BT
PU01 QU34 00MBA21303000 00MBA21303000 TRS. DTC124EU RN1303 UMT TYPE
PU01 QU35 00MBA21303000 00MBA21303000 TRS. DTC124EU RN1303 UMT TYPE
PU01 QU36 00MBA21303000 00MBA21303000 TRS. DTC124EU RN1303 UMT TYPE
97
