Marantz SC-11S1 Service Manual

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.W.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
PU01 QU37 00MBA21303000 00MBA21303000 TRS. DTC124EU RN1303 UMT TYPE
PU01 QU38 00MBA21303000 00MBA21303000 TRS. DTC124EU RN1303 UMT TYPE
PU01 QU39 00MBA21303000 00MBA21303000 TRS. DTC124EU RN1303 UMT TYPE
PU01 RU01 ns
p
00MNN05473610 CHIP RES. 47K OHM +-5% 1/16W
PU01 RU04 ns
p
00MNN05473610 CHIP RES. 47K OHM +-5% 1/16W
PU01 RU05 ns
p
00MNN05103610 CHIP RES. 10K OHM +-5% 1/16W
PU01 RU06 ns
p
00MNN05103610 CHIP RES. 10K OHM +-5% 1/16W
PU01 RU07 ns
p
00MNN05103610 CHIP RES. 10K OHM +-5% 1/16W
PU01 RU08 ns
p
00MNN05473610 CHIP RES. 47K OHM +-5% 1/16W
PU01 RU09 ns
p
00MNN05473610 CHIP RES. 47K OHM +-5% 1/16W
PU01 RU10 ns
p
00MNN05473610 CHIP RES. 47K OHM +-5% 1/16W
PU01 RU11 ns
p
00MNN05473610 CHIP RES. 47K OHM +-5% 1/16W
PU01 RU12 ns
p
00MNN05473610 CHIP RES. 47K OHM +-5% 1/16W
PU01 RU13 ns
p
00MNN05473610 CHIP RES. 47K OHM +-5% 1/16W
PU01 RU14 ns
p
00MNN05473610 CHIP RES. 47K OHM +-5% 1/16W
PU01 RU15 ns
p
00MNN05154610 CHIP RES. 150K OHM +-5% 1/16W
PU01 RU16 ns
p
00MNN05103610 CHIP RES. 10K OHM +-5% 1/16W
PU01 RU17 ns
p
00MNN05101610 CHIP RES. 100 OHM +-5% 1/16W
PU01 RU19 ns
p
00MNN05473610 CHIP RES. 47K OHM +-5% 1/16W
PU01 RU20 ns
p
00MNN05473610 CHIP RES. 47K OHM +-5% 1/16W
PU01 RU21 ns
p
00MNN05473610 CHIP RES. 47K OHM +-5% 1/16W
PU01 RU22 ns
p
00MNN05223610 CHIP RES. 22K OHM +-5% 1/16W
PU01 RU23 ns
p
00MNN05104610 CHIP RES. 100K OHM +-5% 1/16W
PU01 RU24 ns
p
00MNN05223610 CHIP RES. 22K OHM +-5% 1/16W
PU01 RU25 ns
p
00MNN05223610 CHIP RES. 22K OHM +-5% 1/16W
PU01 RU26 ns
p
00MNN05103610 CHIP RES. 10K OHM +-5% 1/16W
PU01 RU27 ns
p
00MNN05103610 CHIP RES. 10K OHM +-5% 1/16W
PU01 RU28 ns
p
00MNN05103610 CHIP RES. 10K OHM +-5% 1/16W
PU01 RU32 ns
p
00MNN05330610 CHIP RES. 33 OHM +-5% 1/16W
PU01 RU33 ns
p
00MNN05223610 CHIP RES. 22K OHM +-5% 1/16W
PU01 RU34 ns
p
00MNN05101610 CHIP RES. 100 OHM +-5% 1/16W
PU01 RU37 ns
p
00MNN05473610 CHIP RES. 47K OHM +-5% 1/16W
PU01 RU38 ns
p
00MNN05103610 CHIP RES. 10K OHM +-5% 1/16W
PU01 RU39 ns
p
00MNN05102610 CHIP RES. 1K OHM +-5% 1/16W
PU01 RU40 ns
p
00MNN05821610 CHIP RES. 820 OHM +-5% 1/16W
PU01 RU41 ns
p
00MNN05103610 CHIP RES. 10K OHM +-5% 1/16W
PU01 RU42 ns
p
00MNN05222610 CHIP RES. 2.2K OHM +-5% 1/16W
PU01 RU43 ns
p
00MNN05103610 CHIP RES. 10K OHM +-5% 1/16W
PU01 RU44 ns
p
00MNN05222610 CHIP RES. 2.2K OHM +-5% 1/16W
PU01 RU45 ns
p
00MNN05103610 CHIP RES. 10K OHM +-5% 1/16W
PU01 RU46 ns
p
00MNN05102610 CHIP RES. 1K OHM +-5% 1/16W
PU01 RU47 ns
p
00MNN05821610 CHIP RES. 820 OHM +-5% 1/16W
PU01 RU48 ns
p
00MNN05103610 CHIP RES. 10K OHM +-5% 1/16W
PU01 RU49 ns
p
00MNN05222610 CHIP RES. 2.2K OHM +-5% 1/16W
PU01 RU50 ns
p
00MNN05103610 CHIP RES. 10K OHM +-5% 1/16W
PU01 RU51 ns
p
00MNN05222610 CHIP RES. 2.2K OHM +-5% 1/16W
PU01 RU52 ns
p
00MNN05103610 CHIP RES. 10K OHM +-5% 1/16W
PU01 RU53 ns
p
00MNN05122610 CHIP RES. 1.2K OHM +-5% 1/16W
PU01 RU54 ns
p
00MNN05122610 CHIP RES. 1.2K OHM +-5% 1/16W
PU01 RU55 ns
p
00MNN05472610 CHIP RES. 4.7K OHM +-5% 1/16W
PU01 RU56 ns
p
00MNN05122610 CHIP RES. 1.2K OHM +-5% 1/16W
PU01 RU57 ns
p
00MNN05122610 CHIP RES. 1.2K OHM +-5% 1/16W
PU01 RU58 ns
p
00MNN05472610 CHIP RES. 4.7K OHM +-5% 1/16W
PU01 RU59 ns
p
00MNN05103610 CHIP RES. 10K OHM +-5% 1/16W
PU01 RU60 ns
p
00MNN05103610 CHIP RES. 10K OHM +-5% 1/16W
PU01 RU64 ns
p
00MNN05103610 CHIP RES. 10K OHM +-5% 1/16W
PU01 RU65 ns
p
00MNN05103610 CHIP RES. 10K OHM +-5% 1/16W
PU01 SU51 00MSP01013370 00MSP01013370 PUSH SW EVQ11L05R H/5MM 160GF
PU01 SU52 00MSP01013370 00MSP01013370 PUSH SW EVQ11L05R H/5MM 160GF
PU01 SU53 00MSP01013370 00MSP01013370 PUSH SW EVQ11L05R H/5MM 160GF
PU01 SU56 00MSP01013370 00MSP01013370 PUSH SW EVQ11L05R H/5MM 160GF
PU01 SU57 00MSP01013370 00MSP01013370 PUSH SW EVQ11L05R H/5MM 160GF
PU01 SU58 00MSP01013370 00MSP01013370 PUSH SW EVQ11L05R H/5MM 160GF
PU01 XU01 00MFQ08004060 00MFQ08004060 CER. VIB. CSTS MG 8MHZ
(
15PF
)
PU01 XU02 00MXO001001T0 00MXO001001T0 X'TAL DT-38 32.768KHZ
DISPLAY PWB PU21
(
00MWG22AJ302-
)
PU21 CV05 ns
p
00MDD95102300 CER. CAP. C GRM1882C1H102JA01D
PU21 CV07 ns
p
00MDK96104300 CER. CAP. C1608X7R1H104K
98
