Marantz SC-11S1 Service Manual

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.W.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
PU21 CV09 ns
p
00MDK96104300 CER. CAP. C1608X7R1H104K
PU21 CV10 ns
p
00MDK96104300 CER. CAP. C1608X7R1H104K
PU21 CV11 ns
p
00MDK98105200 CER. CAP. 1UF 10V F
PU21 CV12 ns
p
00MDK98105200 CER. CAP. 1UF 10V F
PU21 CV13 ns
p
00MDK98105200 CER. CAP. 1UF 10V F
PU21 CV14 ns
p
00MDK98105200 CER. CAP. 1UF 10V F
PU21 CV15 ns
p
00MDK98105200 CER. CAP. 1UF 10V F
PU21 DV01 00MHI10046080 00MHI10046080 L.E.D. BLUE LED SELU2E10C-P-E/F 3
PU21 DV02 00MHI10005340 00MHI10005340 L.E.D. HLMF-K200 #2UL RED H=9 3MM
PU21 DV03 00MHZ30751000 00MHZ30751000 CHIP DIODE 7.5V ZENER MA8075-M UDPS7.5B
PU21 QV02 00MBA21303000 00MBA21303000 TRS. DTC124EU RN1303 UMT TYPE
PU21 QV03 00MBA21303000 00MBA21303000 TRS. DTC124EU RN1303 UMT TYPE
PU21 RV02 ns
p
00MNN05222610 CHIP RES. 2.2K OHM +-5% 1/16W
PU21 RV03 ns
p
00MNN05103610 CHIP RES. 10K OHM +-5% 1/16W
PU21 RV04 ns
p
00MNN05331610 CHIP RES. 330 OHM +-5% 1/16W
PU21 RV05 ns
p
00MNN05103610 CHIP RES. 10K OHM +-5% 1/16W
PU21 RV06 ns
p
00MNN05222610 CHIP RES. 2.2K OHM +-5% 1/16W
PU21 RV07 ns
p
00MNN05823610 CHIP RES. 82K OHM +-5% 1/16W
PU21 RV08 ns
p
00MNN05473610 CHIP RES. 47K OHM +-5% 1/16W
PU21 RV09 ns
p
00MNN05823610 CHIP RES. 82K OHM +-5% 1/16W
BACK LIGHT PWB PU31
(
00MWG22AJ303-
)
PU31 CV31 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PU31 DV31 00MHI10005980 00MHI10005980 L.E.D. NSPW515BS-S-CO
PU31 RV31 ns
p
00MNN05103610 CHIP RES. 10K OHM +-5% 1/16W
I/R SENSOR PWB PU41
(
00MWG22AJ304-
)
PU41 CU82 ns
p
00MDK96104300 CER. CAP. C1608X7R1H104K
PU41 QU28 00MBA12303000 00MBA12303000 TRS. DTA124EU RN2303 UMT TYPE
PU41 QU29 00MHX300012A0 00MHX300012A0 CHIP TRS. 2SC4081
(
Q R
)
2SC4116
(
Y GR
)
PU41 QU81 00MHW10004210 00MHW10004210 PHOTO UNIT RPM6936-V4
(
IR SENSOR
)
PU41 RU35 ns
p
00MNN05473610 CHIP RES. 47K OHM +-5% 1/16W
PU41 RU36 ns
p
00MNN05183610 CHIP RES. 18K OHM +-5% 1/16W
PU41 RU81 ns
p
00MNN05101610 CHIP RES. 100 OHM +-5% 1/16W
INPUT SELECTOR PWB PU51
(
00MWG22AJ305-
)
PU51 CU71 ns
p
00MDK96103300 CER. CAP. 0.01UF +-10% 50V C1608JB1H103K
PU51 CU72 ns
p
00MDK96103300 CER. CAP. 0.01UF +-10% 50V C1608JB1H103K
PU51 SU72 00MSR01120070 00MSR01120070 ROTARY SW SRRSIC
VOLUME PWB PU61
(
00MWG22AJ306-
)
PU61 RU71 ns
p
00MNN05103610 CHIP RES. 10K OHM +-5% 1/16W
PU61 RU72 ns
p
00MNN05103610 CHIP RES. 10K OHM +-5% 1/16W
PU61 RU73 ns
p
00MNN05103610 CHIP RES. 10K OHM +-5% 1/16W
PU61 RU74 ns
p
00MNN05103610 CHIP RES. 10K OHM +-5% 1/16W
PU61 SU71 00MSR02010140 00MSR02010140 ROTARY SW EC12E2470811
FCBS PWB PU71
(
00MWG22AJ307-
)
PU71 CV52 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PU71 CV53 ns
p
00MOA106035Z0 ELECT. CAP. ROS-35V 100M - F3 #PE - T2
(
10UF 35V
)
PU71 CV54 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PU71 CV55 ns
p
00MDK96104300 CER. CAP. C1608X7R1H104K
PU71 CV56 ns
p
00MDK96104300 CER. CAP. C1608X7R1H104K
PU71 CV57 ns
p
00MDK96102300 CER. CAP. 1000 PF +-10 % B 50V GR36
PU71 CV58 ns
p
00MDK96102300 CER. CAP. 1000 PF +-10 % B 50V GR36
PU71 CV59 ns
p
00MDK96102300 CER. CAP. 1000 PF +-10 % B 50V GR36
PU71 CV60 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PU71 CV61 ns
p
00MDK98104200 CER. CAP. GRM39F104Z16 0.1UF
PU71 DV52 00MHZ21005000 00MHZ21005000 CHIP DIODE 1SS301 DAN202U UMT TYPE
PU71 DV53 00MHZ20018050 00MHZ20018050 CHIP DIODE 1SS302
PU71 DV54 00MHZ20018050 00MHZ20018050 CHIP DIODE 1SS302
PU71 JV52 00MYJ01004670 00MYJ01004670 JACK LGY6501-0600 3.5 MINI JACK
PU71 JV53 00MYJ01004670 00MYJ01004670 JACK LGY6501-0600 3.5 MINI JACK
PU71 JV54 00MYJ01004670 00MYJ01004670 JACK LGY6501-0600 3.5 MINI JACK
PU71 JV55 00MYJ01004670 00MYJ01004670 JACK LGY6501-0600 3.5 MINI JACK
PU71 LV52 00D2140208003 00D2140208003 RELAY RELAY
(
NA24W-K
)
PU71 LV53 00MFC90020210 00MFC90020210 FERRITE CORE MLB-1608-1000A-N2
PU71 QV51 00MBA21303000 00MBA21303000 TRS. DTC124EU RN1303 UMT TYPE
PU71 QV52 00MHT600121A0 00MHT600121A0 TRS. KTA1268 PNP TRANSISTOR RANK=GR
PU71 QV53 00MHT600121A0 00MHT600121A0 TRS. KTA1268 PNP TRANSISTOR RANK=GR
PU71 QV54 00MBA21303000 00MBA21303000 TRS. DTC124EU RN1303 UMT TYPE
PU71 QV56 00MBA21303000 00MBA21303000 TRS. DTC124EU RN1303 UMT TYPE
PU71 QV57 00MBA10013050 00MBA10013050 TRS. RN2303
(
PNPX1
(
22K+22K
))
99
