Marantz SC-11S1 Service Manual

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.W.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
PU71 QV58 00MBA21303000 00MBA21303000 TRS. DTC124EU RN1303 UMT TYPE
PU71 QV59 00MHW10006320 00MHW10006320 PHOTO UNIT ! PC-817 PHOTO CUPLER 1PAIR
PU71 RV52 ns
p
00MNN05473610 CHIP RES. 47K OHM +-5% 1/16W
PU71 RV53 ns
p
00MNN05101610 CHIP RES. 100 OHM +-5% 1/16W
PU71 RV54 ns
p
00MNN05103610 CHIP RES. 10K OHM +-5% 1/16W
PU71 RV55 ns
p
00MNN05101610 CHIP RES. 100 OHM +-5% 1/16W
PU71 RV56 ns
p
00MNN05103610 CHIP RES. 10K OHM +-5% 1/16W
PU71 RV57 ns
p
00MNN05101610 CHIP RES. 100 OHM +-5% 1/16W
PU71 RV58 ns
p
00MNN05101610 CHIP RES. 100 OHM +-5% 1/16W
PU71 RV59 ns
p
00MNN05103610 CHIP RES. 10K OHM +-5% 1/16W
PU71 RV60 ns
p
00MNN05101610 CHIP RES. 100 OHM +-5% 1/16W
PU71 RV61 ns
p
00MNN05102610 CHIP RES. 1K OHM +-5% 1/16W
PU71 RV62 ns
p
00MNN05472610 CHIP RES. 4.7K OHM +-5% 1/16W
PU71 RV63 ns
p
00MNN05561610 CHIP RES. 560 OHM +-5% 1/16W
PU71 RV65 ns
p
00MNN05103610 CHIP RES. 10K OHM +-5% 1/16W
PU71 RV66 ns
p
00MNN05103610 CHIP RES. 10K OHM +-5% 1/16W
PU71 RV67 ns
p
00MNN05104610 CHIP RES. 100K OHM +-5% 1/16W
PU71 RV68 ns
p
00MNN05104610 CHIP RES. 100K OHM +-5% 1/16W
PU71 SB51 00MSS02021620 00MSS02021620 SLIDE SW SSSU121700
100
