Marantz SR4021 - Page 24

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
FRONT R933 ns
p
ns
p
RES. 1K OHM 1/5W J CRD20TJ102T
FRONT R935 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103T
FRONT R936 ns
p
ns
p
RES. 1K OHM 1/5W J CRD20TJ102T
FRONT R937 ns
p
ns
p
RES. 1K OHM 1/5W J CRD20TJ102T
FRONT R938 ns
p
ns
p
RES. 1K OHM 1/5W J CRD20TJ102T
FRONT R939 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473T
FRONT R940 ns
p
ns
p
RES. 1K OHM 1/5W J CRD20TJ102T
FRONT R941 ns
p
ns
p
RES. 47K OHM 1/5W J CRD20TJ473T
FRONT R942 ns
p
ns
p
RES. 18K OHM 1/5W J CRD20TJ183T
FRONT R943 ns
p
ns
p
RES. 1K OHM 1/5W J CRD20TJ102T
FRONT R944 ns
p
ns
p
RES. 1.5K OHM 1/5W J CRD20TJ152T
FRONT R945 ns
p
ns
p
RES. 1.5K OHM 1/5W J CRD20TJ152T
FRONT R946 ns
p
ns
p
RES. 1.8K OHM 1/5W J CRD20TJ182T
FRONT R947 ns
p
ns
p
RES. 2.7K OHM 1/5W J CRD20TJ272T
FRONT R948 ns
p
ns
p
RES. 1K OHM 1/5W J CRD20TJ102T
FRONT R949 ns
p
ns
p
RES. 1.8K OHM 1/5W J CRD20TJ182T
FRONT R950 ns
p
ns
p
RES. 3.3K OHM 1/5W J CRD20TJ332T
FRONT R951 ns
p
ns
p
RES. 5.6K OHM 1/5W J CRD20TJ562T
FRONT R952 ns
p
ns
p
RES. 5.6K OHM 1/5W J CRD20TJ562T
FRONT R953 ns
p
ns
p
RES. 1K OHM 1/5W J CRD20TJ102T
FRONT R954 ns
p
ns
p
RES. 1.5K OHM 1/5W J CRD20TJ152T
FRONT R956 ns
p
ns
p
RES. 1.8K OHM 1/5W J CRD20TJ182T
FRONT R957 ns
p
ns
p
RES. 2.7K OHM 1/5W J CRD20TJ272T
FRONT R958 ns
p
ns
p
RES. 3.3K OHM 1/5W J CRD20TJ332T
FRONT R961
/
N1B ns
p
ns
p
RES. 1K OHM 1/5W J CRD20TJ102T
FRONT R961
/
N1S ns
p
ns
p
RES. 1K OHM 1/5W J CRD20TJ102T
FRONT R962
/
N1B ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103T
FRONT R962
/
N1S ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103T
FRONT R964
/
N1B ns
p
ns
p
RES. 680 OHM 1W CRG1ANJ681H
FRONT R964
/
N1S ns
p
ns
p
RES. 680 OHM 1W CRG1ANJ681H
FRONT R965
/
N1B ns
p
ns
p
RES. 1K OHM 1/5W J CRD20TJ102T
FRONT R965
/
N1S ns
p
ns
p
RES. 1K OHM 1/5W J CRD20TJ102T
FRONT R970 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103T
FRONT R971 ns
p
ns
p
RES. 100 OHM 1/5W J CRD20TJ101T
FRONT R976 ns
p
ns
p
RES. 22K OHM 1/5W J CRD20TJ223T
FRONT R977 ns
p
ns
p
RES. 22K OHM 1/5W J CRD20TJ223T
FRONT R978 ns
p
ns
p
RES. 22K OHM 1/5W J CRD20TJ223T
FRONT R979
/
N1B ns
p
ns
p
RES. 22K OHM 1/5W J CRD20TJ223T
FRONT R979
/
N1S ns
p
ns
p
RES. 22K OHM 1/5W J CRD20TJ223T
FRONT R980
/
N1B ns
p
ns
p
RES. 22K OHM 1/5W J CRD20TJ223T
FRONT R980
/
N1S ns
p
ns
p
RES. 22K OHM 1/5W J CRD20TJ223T
FRONT S901 90M-SP001210R 90M-SP001210R SW SKHV10910G TACT CST1A012ZT
FRONT S902 90M-SP001210R 90M-SP001210R SW SKHV10910G TACT CST1A012ZT
FRONT S903 90M-SP001210R 90M-SP001210R SW SKHV10910G TACT CST1A012ZT
FRONT S904 90M-SP001210R 90M-SP001210R SW SKHV10910G TACT CST1A012ZT
FRONT S905 90M-SP001210R 90M-SP001210R SW SKHV10910G TACT CST1A012ZT
FRONT S906 90M-SP001210R 90M-SP001210R SW SKHV10910G TACT CST1A012ZT
FRONT S909 90M-SP001210R 90M-SP001210R SW SKHV10910G TACT CST1A012ZT
FRONT S910 90M-SP001210R 90M-SP001210R SW SKHV10910G TACT CST1A012ZT
FRONT S911 90M-SP001210R 90M-SP001210R SW SKHV10910G TACT CST1A012ZT
FRONT S912 90M-SP001210R 90M-SP001210R SW SKHV10910G TACT CST1A012ZT
FRONT S913 90M-SP001210R 90M-SP001210R SW SKHV10910G TACT CST1A012ZT
FRONT S914 90M-SP001210R 90M-SP001210R SW SKHV10910G TACT CST1A012ZT
FRONT S915 90M-SP001210R 90M-SP001210R SW SKHV10910G TACT CST1A012ZT
FRONT S916 90M-SP001210R 90M-SP001210R SW SKHV10910G TACT CST1A012ZT
FRONT S917 90M-SP001210R 90M-SP001210R SW SKHV10910G TACT CST1A012ZT
FRONT S918 90M-SP001210R 90M-SP001210R SW SKHV10910G TACT CST1A012ZT
FRONT S919 90M-SP001210R 90M-SP001210R SW SKHV10910G TACT CST1A012ZT
FRONT S920 90M-SP001210R 90M-SP001210R SW SKHV10910G TACT CST1A012ZT
FRONT S921 90M-SP001210R 90M-SP001210R SW SKHV10910G TACT CST1A012ZT
FRONT S922 90M-SP001210R 90M-SP001210R SW SKHV10910G TACT CST1A012ZT
FRONT S923 90M-SP001210R 90M-SP001210R SW SKHV10910G TACT CST1A012ZT
FRONT S924 90M-SP001210R 90M-SP001210R SW SKHV10910G TACT CST1A012ZT
FRONT S925 90M-SP001210R 90M-SP001210R SW SKHV10910G TACT CST1A012ZT
FRONT VR91 90M-SR000330R 90M-SR000330R ROTARY SW VR , ENCODER VOLUME CSR2A038Z
FRONT X101 90M-JX001030R 90M-JX001030R X'TAL 8MHZ HOX08000E160C
FRONT X102
/
N1B 90M-JX001310R 90M-JX001310R X'TAL 4.332MHZ HOX04332E200C
34
