Marantz SR4021 - Page 25

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
FRONT X102
/
N1S 90M-JX001310R 90M-JX001310R X'TAL 4.332MHZ HOX04332E200C
H/P PWB
(
CUP11896Z-2
)
H/P C939 ns
p
ns
p
FILM CAP. 3300PF 50V J HCQI1H332JZT
H/P C940 ns
p
ns
p
FILM CAP. 3300PF 50V J HCQI1H332JZT
H/P CN36 ns
p
ns
p
CONN. STRAIGHT 4PIN CJP04GA01ZY
H/P CN94 ns
p
ns
p
CONN. 2PIN CJP02GA19ZY CJP02GA19ZY
H/P HP91
/
N1B 90M-YT003160R 90M-YT003160R TERMINAL HTJ-064-05NG HEADPHONE JACK CJJ2E020Z
H/P HP91
/
N1S 90M-YT004500R 90M-YT004500R TERMINAL JACK HEADPHONE
(
SILVER
)
CJJ2E026Z
H/P HP91
/
U1B ns
p
90M-YT003160R TERMINAL HTJ-064-05NG HEADPHONE JACK CJJ2E020Z
H/P JW91 ns
p
ns
p
CORD WIRE ASSY CWE8202110RV
H/P R972 ns
p
ns
p
RES. METAL OXIDE FILM 470 OHM 1W CRG1ANJ471H
H/P R973 ns
p
ns
p
RES. METAL OXIDE FILM 470 OHM 1W CRG1ANJ471H
JOG PWB
(
CUP11896Z-6
)
JOG C929 ns
p
ns
p
CER. CAP. 100PF 50V K HCBS1H101KBT
JOG C930 ns
p
ns
p
CER. CAP. 100PF 50V K HCBS1H101KBT
JOG CN93 ns
p
ns
p
CONN. 6P STRAIGHT CJP06GA19ZY
JOG D902 90M-HI101040R 90M-HI101040R L.E.D. SLR342VCTB7T089 HVD342VCTB7T089
JOG R921
/
U1B ns
p
ns
p
RES. 2.7K OHM 1/5W J CRD20TJ272T
JOG R922 ns
p
ns
p
RES. 3.3K OHM 1/5W J CRD20TJ332T
JOG R967 ns
p
ns
p
RES. 2.7K OHM 1/5W J CRD20TJ272T
JOG R968 ns
p
ns
p
RES. 2.7K OHM 1/5W J CRD20TJ272T
JOG S908 90M-SP001210R 90M-SP001210R SW SKHV10910G TACT CST1A012ZT
JOG VR92 90M-SR000340R 90M-SR000340R ROTARY SW ENCODER MULTI JOG CSR2A041Z
MAIN PWB
(
CUP11895Z
)
MAIN BN30 90M-HP000060R 90M-HP000060R VARISTOR P42T7D330BW20 KRTP42T7D330B
MAIN BN31 ns
p
ns
p
CORD WIRE ASS'Y CWB2B903180EN
MAIN BN34 ns
p
ns
p
CORD WIRE ASS'Y CWB1C905350BM
MAIN BN36 ns
p
ns
p
CORD WIRE, ASS'Y CWB1C904380BM
MAIN C109 90M-OF100490R 90M-OF100490R FILM CAP. 0.1UF 250V KCME2E104JP04T
MAIN C110 90M-OF100490R 90M-OF100490R FILM CAP. 0.1UF 250V KCME2E104JP04T
MAIN C111 ns
p
ns
p
FILM CAP. 0.01UF 50V J HCQI1H103JZT
MAIN C112 ns
p
ns
p
FILM CAP. 0.01UF 50V J HCQI1H103JZT
MAIN C113 ns
p
ns
p
FILM CAP. 0.01UF 50V J HCQI1H103JZT
MAIN C114 ns
p
ns
p
FILM CAP. 0.01UF 50V J HCQI1H103JZT
MAIN C201 ns
p
ns
p
CER. CAP. 270PF 50V KB CCKT1H271KB
MAIN C202 ns
p
ns
p
CER. CAP. 270PF 50V KB CCKT1H271KB
MAIN C203 ns
p
ns
p
CER. CAP. 100PF 50V KB CCKT1H101KB
MAIN C204 ns
p
ns
p
CER. CAP. 100PF 50V KB CCKT1H101KB
MAIN C205 ns
p
ns
p
CER. CAP. 100PF 50V KB CCKT1H101KB
MAIN C206 ns
p
ns
p
CER. CAP. 100PF 50V KB CCKT1H101KB
MAIN C207 ns
p
ns
p
CER. CAP. 100PF 50V KB CCKT1H101KB
MAIN C208 ns
p
ns
p
CER. CAP. 100PF 50V KB CCKT1H101KB
MAIN C209 ns
p
ns
p
CER. CAP. 100PF 50V KB CCKT1H101KB
MAIN C210 ns
p
ns
p
CER. CAP. 100PF 50V KB CCKT1H101KB
MAIN C211 ns
p
ns
p
CER. CAP. 100PF 50V KB CCKT1H101KB
MAIN C212 ns
p
ns
p
CER. CAP. 100PF 50V KB CCKT1H101KB
MAIN C213 ns
p
ns
p
CER. CAP. 100PF 50V KB CCKT1H101KB
MAIN C214 ns
p
ns
p
CER. CAP. 100PF 50V KB CCKT1H101KB
MAIN C215 ns
p
ns
p
CER. CAP. 100PF 50V KB CCKT1H101KB
MAIN C216 ns
p
ns
p
CER. CAP. 100PF 50V KB CCKT1H101KB
MAIN C217 ns
p
ns
p
CER. CAP. 100PF 50V KB CCKT1H101KB
MAIN C218 ns
p
ns
p
CER. CAP. 100PF 50V KB CCKT1H101KB
MAIN C219 ns
p
ns
p
CER. CAP. 100PF 50V KB CCKT1H101KB
MAIN C220 ns
p
ns
p
CER. CAP. 100PF 50V KB CCKT1H101KB
MAIN C221 ns
p
ns
p
CER. CAP. 100PF 50V KB CCKT1H101KB
MAIN C222 ns
p
ns
p
CER. CAP. 100PF 50V KB CCKT1H101KB
MAIN C225 ns
p
ns
p
CER. CAP. 100PF 50V KB CCKT1H101KB
MAIN C226 ns
p
ns
p
CER. CAP. 100PF 50V KB CCKT1H101KB
MAIN C227 ns
p
ns
p
CER. CAP. 1000PF 50V KB CCKT1H102KB
MAIN C228 ns
p
ns
p
CER. CAP. 1000PF 50V KB CCKT1H102KB
MAIN C229 ns
p
00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T
MAIN C230 ns
p
00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T
MAIN C231 90M-OF100370R 90M-OF100370R FILM CAP. 0.022UF 50V J HCQI1H223JZT
MAIN C232 90M-OF100370R 90M-OF100370R FILM CAP. 0.022UF 50V J HCQI1H223JZT
MAIN C233 ns
p
ns
p
FILM CAP. 5600PF 50V J HCQI1H562JZT
MAIN C234 ns
p
ns
p
FILM CAP. 5600PF 50V J HCQI1H562JZT
MAIN C235 ns
p
00MOA47505020 ELECT CAP. 4.7UF 50V CCEA1HH4R7T
