Marantz SR4021 - Page 26

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
MAIN C236 ns
p
00MOA47505020 ELECT CAP. 4.7UF 50V CCEA1HH4R7T
MAIN C237 ns
p
00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T
MAIN C238 ns
p
00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T
MAIN C239 ns
p
ns
p
CER. CAP. 0.01UF 50V Z CCFT1H103ZF
MAIN C240 ns
p
ns
p
CER. CAP. 0.01UF 50V Z CCFT1H103ZF
MAIN C241 ns
p
ns
p
CER. CAP. 0.01UF 50V Z CCFT1H103ZF
MAIN C242 ns
p
ns
p
CER. CAP. 0.01UF 50V Z CCFT1H103ZF
MAIN C243 ns
p
ns
p
CER. CAP. 330PF 50V KB CCKT1H331KB
MAIN C244 ns
p
ns
p
CER. CAP. 470PF 50V KB CCKT1H471KB
MAIN C247 ns
p
ns
p
CER. CAP. 0.01UF 50V Z CCFT1H103ZF
MAIN C248 ns
p
ns
p
CER. CAP. 0.01UF 50V Z CCFT1H103ZF
MAIN C249 ns
p
ns
p
CER. CAP. 330PF 50V KB CCKT1H331KB
MAIN C250 ns
p
ns
p
CER. CAP. 470PF 50V KB CCKT1H471KB
MAIN C251 ns
p
00MOA10701620 ELECT CAP. 100UF 16V CCEA1CH101T
MAIN C252 ns
p
ns
p
CER. CAP. 0.01UF 50V Z CCFT1H103ZF
MAIN C253 ns
p
00MOA10701620 ELECT CAP. 100UF 16V CCEA1CH101T
MAIN C254 ns
p
ns
p
CER. CAP. 0.01UF 50V Z CCFT1H103ZF
MAIN C255 ns
p
ns
p
CER. CAP. 180PF 50V KB CCKT1H181KB
MAIN C256 ns
p
ns
p
CER. CAP. 180PF 50V KB CCKT1H181KB
MAIN C257 ns
p
00MOA47505020 ELECT CAP. 4.7UF 50V CCEA1HH4R7T
MAIN C258 ns
p
00MOA47505020 ELECT CAP. 4.7UF 50V CCEA1HH4R7T
MAIN C259 ns
p
00MOA47505020 ELECT CAP. 4.7UF 50V CCEA1HH4R7T
MAIN C264 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
MAIN C265 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
MAIN C266 ns
p
ns
p
FILM CAP. 8200PF 50V J HCQI1H822JZT
MAIN C267 ns
p
ns
p
FILM CAP. 0.015UF 50V J HCQI1H153JZT
MAIN C268 90M-DF100340R 90M-DF100340R FILM CAP. 0.33UF 63V J KCFE1J334JBT
MAIN C269 ns
p
00MOA10701620 ELECT CAP. 100UF 16V CCEA1CH101T
MAIN C270 ns
p
ns
p
CER. CAP. 0.01UF 50V Z CCFT1H103ZF
MAIN C271 ns
p
00MOA47505020 ELECT CAP. 4.7UF 50V CCEA1HH4R7T
MAIN C272 ns
p
00MOA47505020 ELECT CAP. 4.7UF 50V CCEA1HH4R7T
MAIN C273 ns
p
ns
p
CER. CAP. 82PF 50V JC CCCT1H820JC
MAIN C274 ns
p
ns
p
CER. CAP. 82PF 50V JC CCCT1H820JC
MAIN C275 ns
p
00MOA47505020 ELECT CAP. 4.7UF 50V CCEA1HH4R7T
MAIN C276 ns
p
00MOA47505020 ELECT CAP. 4.7UF 50V CCEA1HH4R7T
MAIN C277 ns
p
ns
p
CER. CAP. 0.01UF 50V Z CCFT1H103ZF
MAIN C278 ns
p
ns
p
CER. CAP. 0.01UF 50V Z CCFT1H103ZF
MAIN C279 ns
p
ns
p
CER. CAP. 100PF 50V KB CCKT1H101KB
MAIN C280 ns
p
ns
p
CER. CAP. 100PF 50V KB CCKT1H101KB
MAIN C281 ns
p
00MOA47505020 ELECT CAP. 4.7UF 50V CCEA1HH4R7T
MAIN C282 ns
p
ns
p
FILM CAP. 8200PF 50V J HCQI1H822JZT
MAIN C283 ns
p
ns
p
FILM CAP. 0.015UF 50V J HCQI1H153JZT
MAIN C284 90M-DF100340R 90M-DF100340R FILM CAP. 0.33UF 63V J KCFE1J334JBT
MAIN C301 ns
p
00MOA47505020 ELECT CAP. 4.7UF 50V CCEA1HH4R7T
MAIN C302 ns
p
00MOA47505020 ELECT CAP. 4.7UF 50V CCEA1HH4R7T
MAIN C303 ns
p
ns
p
CER. CAP. 470PF 50V KB CCKT1H471KB
MAIN C304 ns
p
ns
p
CER. CAP. 470PF 50V KB CCKT1H471KB
MAIN C305 ns
p
ns
p
CER. CAP. 15PF 50V JC CCCT1H150JC
MAIN C306 ns
p
ns
p
CER. CAP. 15PF 50V JC CCCT1H150JC
MAIN C307 ns
p
00MOA10701620 ELECT CAP. 100UF 16V CCEA1CH101T
MAIN C308 ns
p
00MOA10701620 ELECT CAP. 100UF 16V CCEA1CH101T
MAIN C309 ns
p
ns
p
CER. CAP. 180PF 50V KB CCKT1H181KB
MAIN C310 ns
p
ns
p
CER. CAP. 180PF 50V KB CCKT1H181KB
MAIN C311 ns
p
00MOA22706320 ELECT CAP. 220UF 63V CCEA1JH221E
MAIN C312 ns
p
00MOA22706320 ELECT CAP. 220UF 63V CCEA1JH221E
MAIN C313 ns
p
00MOA22706320 ELECT CAP. 220UF 63V CCEA1JH221E
MAIN C314 ns
p
00MOA22706320 ELECT CAP. 220UF 63V CCEA1JH221E
MAIN C315 90M-OF100370R 90M-OF100370R FILM CAP. 0.022UF 50V J HCQI1H223JZT
MAIN C316 90M-OF100370R 90M-OF100370R FILM CAP. 0.022UF 50V J HCQI1H223JZT
MAIN C317 90M-OF100370R 90M-OF100370R FILM CAP. 0.022UF 50V J HCQI1H223JZT
MAIN C318 90M-OF100370R 90M-OF100370R FILM CAP. 0.022UF 50V J HCQI1H223JZT
MAIN C319 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
MAIN C320 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
MAIN C321 ns
p
ns
p
FILM CAP. 0.047UF 50V J HCQI1H473JZT
MAIN C322 ns
p
ns
p
FILM CAP. 0.047UF 50V J HCQI1H473JZT
MAIN C323 ns
p
ns
p
FILM CAP. 0.01UF 50V J HCQI1H103JZT
MAIN C324 ns
p
ns
p
FILM CAP. 0.01UF 50V J HCQI1H103JZT
36
