Marantz SR4021 - Page 27

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
MAIN C325 ns
p
ns
p
FILM CAP. 0.01UF 50V J HCQI1H103JZT
MAIN C326 ns
p
ns
p
FILM CAP. 0.01UF 50V J HCQI1H103JZT
MAIN C381 ns
p
00MOA47605020 ELECT CAP. 47UF 50V CCEA1HH470T
MAIN C382 ns
p
00MOA47701020 ELECT CAP. 470UF 10V CCEA1AH471T
MAIN C383 ns
p
ns
p
CER. CAP. 0.022UF 50V Z CCFT1H223ZF
MAIN C389 ns
p
00MOA47505020 ELECT CAP. 4.7UF 50V CCEA1HH4R7T
MAIN C390 ns
p
00MOA47505020 ELECT CAP. 4.7UF 50V CCEA1HH4R7T
MAIN C391 ns
p
ns
p
CER. CAP. 0.01UF 50V Z CCFT1H103ZF
MAIN C392 ns
p
ns
p
CER. CAP. 0.01UF 50V Z CCFT1H103ZF
MAIN C401 90M-EX000230R 90M-EX000230R ELECT CAP. 8200UF 63V HCET63VSMH822NN
MAIN C402 90M-EX000230R 90M-EX000230R ELECT CAP. 8200UF 63V HCET63VSMH822NN
MAIN C403 ns
p
00MOA22803520 ELECT CAP. 2200UF 35V CCEA1VH222E
MAIN C404 ns
p
00MOA10803520 ELECT CAP. 1000UF 35V CCEA1VH102E
MAIN C405 ns
p
ns
p
CER. CAP. 0.01UF 50V Z CCFT1H103ZF
MAIN C406 ns
p
ns
p
CER. CAP. 0.01UF 50V Z CCFT1H103ZF
MAIN C407 ns
p
00MOA47702520 ELECT CAP. 470UF/25V CCEA1EH471E
MAIN C408 ns
p
00MOA47702520 ELECT CAP. 470UF/25V CCEA1EH471E
MAIN C409 ns
p
ns
p
CER. CAP. 0.01UF 50V Z CCFT1H103ZF
MAIN C410 ns
p
ns
p
CER. CAP. 0.01UF 50V Z CCFT1H103ZF
MAIN C411 ns
p
00MOA33505020 ELECT CAP. 3.3UF 50V CCEA1HH3R3T
MAIN C412 ns
p
00MOA33505020 ELECT CAP. 3.3UF 50V CCEA1HH3R3T
MAIN C421 ns
p
ns
p
CER. CAP. 0.1UF 50V Z HCBS1H104ZFT
MAIN C422 ns
p
ns
p
CER. CAP. 0.1UF 50V Z HCBS1H104ZFT
MAIN C423 ns
p
ns
p
FILM CAP. 0.1UF 50V ZF CCFT1H104ZF
MAIN C424 ns
p
ns
p
FILM CAP. 0.1UF 50V ZF CCFT1H104ZF
MAIN C425 90M-OF100370R 90M-OF100370R FILM CAP. 0.022UF 50V J HCQI1H223JZT
MAIN C426 90M-OF100370R 90M-OF100370R FILM CAP. 0.022UF 50V J HCQI1H223JZT
MAIN C427 ns
p
ns
p
FILM CAP. 0.1UF 50V ZF CCFT1H104ZF
MAIN C428 ns
p
ns
p
FILM CAP. 0.1UF 50V ZF CCFT1H104ZF
MAIN CN35 ns
p
ns
p
CONN. WAFER CJP03GA89ZY
MAIN D102 90M-HE200340R 90M-HE200340R DIODE ! GBJ804 HVDGBJ804
MAIN D201 90M-HD302360R 90M-HD302360R ZENER DIODE ZJ6.8B 1/2W CVDZJ6.8BT
MAIN D202 00MHD30511000 00MHD30511000 ZENER DIODE MTZJ5.1B CVDZJ5.1BT
MAIN D203 90M-HD302360R 90M-HD302360R ZENER DIODE ZJ6.8B 1/2W CVDZJ6.8BT
MAIN D301 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
MAIN D302 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
MAIN D303 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
MAIN D304 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
MAIN D305 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
MAIN D306 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
MAIN D381 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
MAIN D391 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
MAIN D392 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
MAIN D401 ns
p
90M-HD201730R DIODE 1N4003 CVD1N4003ST
MAIN D402 ns
p
90M-HD201730R DIODE 1N4003 CVD1N4003ST
MAIN D403 ns
p
90M-HD201730R DIODE 1N4003 CVD1N4003ST
MAIN D404 ns
p
90M-HD201730R DIODE 1N4003 CVD1N4003ST
MAIN D405 ns
p
00MHD20015210 DIODE 1SS133T-77 CVD1SS133MT
MAIN ET91 ns
p
ns
p
TERMINAL MET37-0002 HJT1A025
MAIN IC21 00MHC10102090 00MHC10102090 IC NJM2068MD-TE1 HVINJM2068MDTE1
MAIN IC22 90M-HC109720R 90M-HC109720R IC TC9163CFG FUNCTION SW HVITC9163CFG
MAIN IC23 90M-HC109730R 90M-HC109730R IC TC9164CFG FUNCTION SW HVITC9164CFG
MAIN IC24 90M-HC108220R 90M-HC108220R IC M62446AFP HVIM62446AFP
MAIN IC25 00MHC10102090 00MHC10102090 IC NJM2068MD-TE1 HVINJM2068MDTE1
MAIN IC26 00MHC10102090 00MHC10102090 IC NJM2068MD-TE1 HVINJM2068MDTE1
MAIN IC41 90M-HC300900R 90M-HC300900R IC ! L7815CP HVIL7815CP
MAIN IC42 90M-HC300900R 90M-HC300900R IC ! L7815CP HVIL7915CP
MAIN J101 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
MAIN J102 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
MAIN J103 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
MAIN J104 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
MAIN J107 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
MAIN J201 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
MAIN J202 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
MAIN J203 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
MAIN J204 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
MAIN J205 ns
p
ns
p
CORD SN95/PB5, 0.6 C3A206
37
