Marantz SR4400 - Page 53

POS. NO
VERS.
COLOR
PART NO.
(FOR EUR)
DESCRIPTION
PART NO.
(MJI)
XRS202 *JX001050R *JX001050R X'TAL VSXEN2005A20B5S
FRONT PCB
CF101 nsp nsp CERAMIC CAP. 50V, 100000pF, 2F4 ECKR1H104Z06F
CF102 nsp nsp CERAMIC CAP. 50V, 47pF, SL ECCR1H470JY
CF103 nsp nsp CERAMIC CAP. 50V, 100000pF, 2F4 ECKR1H104Z06F
CF104 nsp nsp CERAMIC CAP. 50V, 1000pF, 2B4 ECKR1H102K06B
CF105 nsp nsp CERAMIC CAP. 50V, 100000pF, 2F4 ECKR1H104Z06F
CF106 nsp nsp CERAMIC CAP. 50V, 100000pF, 2F4 ECKR1H104Z06F
CF107 nsp nsp CERAMIC CAP. 50V, 100000pF, 2F4 ECKR1H104Z06F
CF108 nsp nsp CERAMIC CAP. 50V, 100000pF, 2F4 ECKR1H104Z06F
CF109 nsp nsp CERAMIC CAP. 50V, 100000pF, 2F4 ECKR1H104Z06F
CF110 nsp OA10605020 ELECT. CAP 50V, 10µF ECEA1HAE100MB
CF111 nsp nsp CERAMIC CAP. 50V, 100000pF, 2F4 ECKR1H104Z06F
CF112 nsp nsp CERAMIC CAP. 50V, 100000pF, 2F4 ECKR1H104Z06F
CF113 nsp nsp CERAMIC CAP. 50V, 100000pF, 2F4 ECKR1H104Z06F
CF114 nsp OA10602550 ELECT. CAP 16V, 10µF ECEA1CAE100MB
CF115 nsp nsp CERAMIC CAP. 50V, 100000pF, 2F4 ECKR1H104Z06F
CF116 nsp OA10701620 ELECT. CAP 16V, 100µF ECEA1CAE101MB
CF117 nsp nsp CERAMIC CAP. 50V, 100000pF, 2F4 ECKR1H104Z06F
CF118 nsp nsp CERAMIC CAP. 50V, 100000pF, 2F4 ECKR1H104Z06F
CF119 nsp nsp CERAMIC CAP. 50V, 100000pF, 2F4 ECKR1H104Z06F
CF120 nsp nsp CERAMIC CAP. 50V, 10000pF, 2F4 ECKR1H103Z08F
CF121 nsp nsp CERAMIC CAP. 50V, 10000pF, 2F4 ECKR1H103Z08F
CF122 nsp OA47601640 ELECT. CAP 16V, 47µF ECEA1CAE470MB
CF123 nsp nsp CERAMIC CAP. 50V, 100000pF, 2F4 ECKR1H104Z06F
CF124 nsp nsp CERAMIC CAP. 50V, 100000pF, 2F4 ECKR1H104Z06F
CF125 nsp nsp CERAMIC CAP. 50V, 100000pF, 2F4 ECKR1H104Z06F
CF126 nsp nsp CERAMIC CAP. 50V, 10000pF, 2F4 ECKR1H103Z08F
CF127 nsp nsp CERAMIC CAP. 50V, 10000pF, 2F4 ECKR1H103Z08F
CF128 nsp nsp CERAMIC CAP. 50V, 100000pF, 2F4 ECKR1H104Z06F
CF129 nsp nsp CERAMIC CAP. 50V, 100000pF, 2F4 ECKR1H104Z06F
CF130 nsp nsp CERAMIC CAP. 50V, 100000pF, 2F4 ECKR1H104Z06F
CF131 nsp nsp CERAMIC CAP. 50V, 100000pF, 2F4 ECKR1H104Z06F
CF132 nsp nsp CERAMIC CAP. 50V, 100000pF, 2F4 ECKR1H104Z06F
CF133 nsp nsp CERAMIC CAP. 50V, 100000pF, 2F4 ECKR1H104Z06F
CF134 nsp nsp CERAMIC CAP. 50V, 100000pF, 2F4 ECKR1H104Z06F
ICF101 *HC108190R *HC108190R IC LQFP OICPT6302001
IRF101 *HW100660R *HW100660R IR SENSOR RPMPIC12042
JFF101 nsp nsp CONNECTOR 7pin, 2.5mm, UL VJS07XH01E
JFF102 nsp nsp FFC CONNECTOR 15pin, 1.25mm VJS15FC11
JFF103 nsp nsp CONNECTOR 4pin, 2.0mm, UL VJS04PH01E
JFF104 nsp nsp CONNECTOR 4pin, 2.0mm, UL VJS04PH01E
JPF101
nsp nsp JUMPER WIRE JPL0000
JPF164
QF101 BA10007210 BA10007210 TRANSISTOR OTRDTA114ES
QF102 BA10007210 BA10007210 TRANSISTOR OTRDTA114ES
QF103 HT317401L0 HT317401L0 TRANSISTOR OTR2SC1740S
QF104 BA10012210 BA10012210 TRANSISTOR OTRDTC144ESA
RF101 nsp nsp RES. 3.3kΩ, 1/6W ERD16TJ332T
RF102 nsp nsp RES. 100Ω, 1/6W ERD16TJ101T
RF103 nsp nsp RES. 8.2kΩ, 1/6W ERD16TJ822T
RF104 nsp nsp RES. 3.9kΩ, 1/6W ERD16TJ392T
RF105 nsp nsp RES. 1.8kΩ, 1/6W ERD16TJ182T
RF106 nsp nsp RES. 1kΩ, 1/6W ERD16TJ102T
RF108 nsp nsp RES. 3.9kΩ, 1/6W ERD16TJ392T
RF109 nsp nsp RES. 1.2kΩ, 1/6W ERD16TJ122T
RF110 nsp nsp RES. 1.8kΩ, 1/6W ERD16TJ182T
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
