POS. NO
VERS.
COLOR
PART NO.
(FOR EUR)
DESCRIPTION
PART NO.
(MJI)
RF111 nsp nsp RES. 1.2kΩ, 1/6W ERD16TJ122T
RF112 nsp nsp RES. 1kΩ, 1/6W ERD16TJ102T
RF113 nsp nsp RES. 8.2kΩ, 1/6W ERD16TJ822T
RF114 nsp nsp RES. 3.9kΩ, 1/6W ERD16TJ392T
RF115 nsp nsp RES. 1.8kΩ, 1/6W ERD16TJ182T
RF116 nsp nsp RES. 1.2kΩ, 1/6W ERD16TJ122T
RF117 nsp nsp RES. 1kΩ, 1/6W ERD16TJ102T
RF118 nsp nsp RES. 8.2kΩ, 1/6W ERD16TJ822T
RF119 nsp nsp RES. 3.9kΩ, 1/6W ERD16TJ392T
RF120 nsp nsp RES. 1.8kΩ, 1/6W ERD16TJ182T
RF121 nsp nsp RES. 1.2kΩ, 1/6W ERD16TJ122T
RF122 nsp nsp RES. 1kΩ, 1/6W ERD16TJ102T
RF123 nsp nsp RES. 330Ω, 1/6W ERD16TJ331T
RF124 nsp nsp RES. 330Ω, 1/6W ERD16TJ331T
RF125 nsp nsp RES. 10kΩ, 1/6W ERD16TJ103T
RF126 nsp nsp RES. 10kΩ, 1/6W ERD16TJ103T
RF127 nsp nsp RES. 10kΩ, 1/6W ERD16TJ103T
RF128 nsp nsp RES. 10kΩ, 1/6W ERD16TJ103T
RF129 nsp nsp RES. 10kΩ, 1/6W ERD16TJ103T
RF130 nsp nsp RES. 2.2kΩ, 1/6W ERD16TJ222T
SWF101
*SP001200R *SP001200R SWITCH 4PIN TACT SWITCH EVQ21505K
SWF111
SWF114
*SP001200R *SP001200R SWITCH 4PIN TACT SWITCH EVQ21505K
SWF122
SWF123 *SR000220R *SR000220R ENCODER EVAR1612E25FB124P
VFF101 *HQ300580R *HQ300580R FL DISPLAY VSLVFD291403FS
H/P OUT PCB
CH01 nsp nsp CERAMIC CAP. 50V, 100000pF, 2F4 ECKR1H104Z06F
CH02 nsp nsp CERAMIC CAP. 50V, 100000pF, 2F4 ECKR1H104Z06F
CH03 nsp nsp CERAMIC CAP. 50V, 100000pF, 2F4 ECKR1H104Z06F
GND nsp nsp TERMINAL L=110mm VJR11004K01E
JH01 nsp nsp CONNECTOR 4pin, 2.0mm, UL VJS04PH01E
MIC1 *YJ002650R *YJ002650R CONNECTOR L=9 HEADPHONE JACK VJJ02905
MAIN PCB
A nsp nsp FUSE CRIP VJFHF004N
AN01 nsp nsp TERMINAL FKV7.725.014
AN02 nsp nsp TERMINAL FKV7.725.014
AN03 nsp nsp TERMINAL FKV7.725.014
B nsp nsp FUSE CRIP VJFHF004N
C nsp nsp FUSE CRIP VJFHF004N
CN101 nsp nsp CERAMIC CAP. 50V, 100000pF, 2F4 ECKR1H104Z06F
CN102 nsp OA10701620 ELECT. CAP 16V, 100µF ECEA1CAE101MB
CN103 nsp nsp CERAMIC CAP. 50V, 100000pF, 2F4 ECKR1H104Z06F
CN104 nsp nsp CERAMIC CAP. 50V, 100000pF, 2F4 ECKR1H104Z06F
CN105 nsp OA10701620 ELECT. CAP 16V, 100µF ECEA1CAE101MB
CN106 nsp nsp CERAMIC CAP. 50V, 100000pF, 2F4 ECKR1H104Z06F
CN107 nsp nsp CERAMIC CAP. 50V, 100000pF, 2F4 ECKR1H104Z06F
CN201 nsp nsp CERAMIC CAP. 50V, 100000pF, 2F4 ECKR1H104Z06F
CN202 nsp OA47601640 ELECT. CAP 16V, 47µF ECEA1CAE470MB
CN203 nsp nsp CERAMIC CAP. 50V, 100000pF, 2F4 ECKR1H104Z06F
CN204 nsp OA47601640 ELECT. CAP 16V, 47µF ECEA1CAE470MB
CN205 nsp nsp CERAMIC CAP. 50V, 100000pF, 2F4 ECKR1H104Z06F
CN206 nsp nsp CERAMIC CAP. 50V, 100000pF, 2F4 ECKR1H104Z06F
CN207 nsp nsp CERAMIC CAP. 50V, 100000pF, 2F4 ECKR1H104Z06F
CN208 nsp OA47601640 ELECT. CAP 16V, 47µF ECEA1CAE470MB
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
