Marantz SR4600 - Page 31

45
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
POS. NO.
CB15
/
U1S ns
p
90M-YU001260R FFC CABLE, CARD HTS-3000 CWC1C4A15B080B
CB27 ns
p
90M-YU001690R FPC CARD, CABLE CWC1C4A27B110B
CB80 ns
p
90M-YU001670R FPC CARD, CABLE CWC1B2A15A200B
CB83 ns
p
90M-YU001680R FPC CARD, CABLE CWC1B2A15A220B
F901
/
A1B ns
p
90M-FS001200R FUSE ! FUSE KBA2C4000TLEZ
F901
/
A1S ns
p
90M-FS001200R FUSE ! FUSE KBA2C4000TLEZ
F901
/
N1B 90M-FS001200R 90M-FS001200R FUSE ! FUSE KBA2C4000TLEZ
F901
/
N1G 90M-FS001200R 90M-FS001200R FUSE ! FUSE KBA2C4000TLEZ
F901
/
N1S 90M-FS001200R 90M-FS001200R FUSE ! FUSE KBA2C4000TLEZ
F901
/
U1B ns
p
90M-FS001190R FUSE ! FUSE KBA2C6300TLUZ
F901
/
U1S ns
p
90M-FS001190R FUSE ! FUSE KBA2C6300TLUZ
RC91 90M-YJ002690R 90M-YJ002690R INLET ! R-301
(
187-2P
)
10A/250
V
HJJ8A001Z
T901
/
A1B ns
p
90M-TS002490R TRANSF. ! POWER TRANSFORMER CLT5W014YE
T901
/
A1S ns
p
90M-TS002490R TRANSF. ! POWER TRANSFORMER CLT5W014YE
T901
/
N1B 90M-TS002490R 90M-TS002490R TRANSF. ! POWER TRANSFORMER CLT5W014YE
T901
/
N1G 90M-TS002490R 90M-TS002490R TRANSF. ! POWER TRANSFORMER CLT5W014YE
T901
/
N1S 90M-TS002490R 90M-TS002490R TRANSF. ! POWER TRANSFORMER CLT5W014YE
T901
/
U1B ns
p
90M-TS002180R TRANSF. ! POWER TRANSFORMER CLT5W014ZU
T901
/
U1S ns
p
90M-TS002180R TRANSF. ! POWER TRANSFORMER CLT5W014ZU
90M-FC500030R 90M-FC500030R FERRITE CORE FERRITE RING 29X7.7X19 CLZ9W003Z
90M-FC500040R 90M-FC500040R FERRITE CORE FERRITE CORE 21.2X6.4X12.7 K5C
T
CLZ9Z028Z
PACKING
/
A1B ns
p
USER GUIDE USER GUIDE SR4500 A CQX1A1018Z
/
A1S ns
p
USER GUIDE USER GUIDE SR4500 A CQX1A1018Z
/
N1B 00M42BW851310 00M42BW851310 USER GUIDE USER GUIDE SR4500 N CQX1A1016Z
/
N1G 00M42BW851310 00M42BW851310 USER GUIDE USER GUIDE SR4500 N CQX1A1016Z
/
N1S 00M42BW851310 00M42BW851310 USER GUIDE USER GUIDE SR4500 N CQX1A1016Z
/
U1B ns
p
00M42BW851250 USER GUIDE USER GUIDE SR4500 U CQX1A1017Z
/
U1S ns
p
00M42BW851250 USER GUIDE USER GUIDE SR4500 U CQX1A1017Z
00MZK08BW0010 00MZK08BW0010 UNIT KIT REMOTE CONTROLLER RC5500SR HARTSR5500
38
/
U1B ns
p
90M-ZC000310R MAINS CORD ! MAINS CORD UL 032508/12 CJA2A070Z
38
/
U1S ns
p
90M-ZC000310R MAINS CORD ! MAINS CORD UL 032508/12 CJA2A070Z
38
/
N1B 90M-ZC000320R 90M-ZC000320R MAINS CORD ! MAINS CORD 2WIRE 10A/250
V
CJA2B054Z
38
/
N1G 90M-ZC000320R 90M-ZC000320R MAINS CORD ! MAINS CORD 2WIRE 10A/250
V
CJA2B054Z
38
/
N1S 90M-ZC000320R 90M-ZC000320R MAINS CORD ! MAINS CORD 2WIRE 10A/250
V
CJA2B054Z
38
/
A1B ns
p
90M-ZC000430R MAINS CORD ! MAINS CORD DETACHABLE HJA2S084Z
38
/
A1S ns
p
90M-ZC000430R MAINS CORD ! MAINS CORD DETACHABLE HJA2S084Z
NOT STANDARD SPARE PART
/
N1B ns
p
00M42BW805010 MASS CARTON MASTER PKG SR4500 N CPG1A766Y
/
N1G ns
p
00M42BW805010 MASS CARTON MASTER PKG SR4500 N CPG1A766Y
/
N1S ns
p
00M42BW805010 MASS CARTON MASTER PKG SR4500 N CPG1A766Y
ns
p
00M42BW801010 PACKING CASE PACKING CASE SR4500 CPG1A765W
ns
p
00M07BW809010 CUSHION CUSHION L CPS1A671
ns
p
00M07BW809020 CUSHION CUSHION R CPS1A672
40
/
A1B ns
p
00M07BW257010 LID TOP COVER
(
BLACK
)
CKC1A155K117
40
/
A1S ns
p
00M07BW257210 LID TOP COVER
(
SILVER
)
CKC1A155G14
40
/
N1B ns
p
00M07BW257010 LID TOP COVER
(
BLACK
)
CKC1A155K117
40
/
N1G ns
p
00M07BW257110 LID TOP COVER
(
GOLD
)
CKC1A155K118
40
/
N1S ns
p
00M07BW257210 LID TOP COVER
(
SILVER
)
CKC1A155G14
40
/
U1B ns
p
00M07BW257010 LID TOP COVER
(
BLACK
)
CKC1A155K117
40
/
U1S ns
p
00M07BW257210 LID TOP COVER
(
SILVER
)
CKC1A155G14
ns
p
ns
p
ANTENNA AM LOOP ANT CSA1A020Z
ns
p
ns
p
ANTENNA ANT FM WIRE
(
PIGTAIL
)
CSA1A007
