Marantz SR4600 - Page 39

53
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
BIAS T.R PWB
BIAS TR C851
nsp 00MOA10605020
ELECT CAP. 10UF 50V ZF CCEA1HH100T
BIAS TR CN81
nsp nsp
CONN. WAFER, ANGLE, 2PIN CJP02GB46Z
Y
BIAS TR Q851
90M-HT800120R 90M-HT800120R
TRS. KTC3114A HVTKTC3114
A
BIAS TR R874
nsp nsp
RES. 330 OHM 1/5W J CRD20TJ331
T
BIAS TR R882
nsp nsp
RES. 1.2K OHM 1/5W J CRD20TJ122
T
BIAS TR VR81
90M-RA001100R 90M-RA001100R
TRIM. RES. RH0615C100221 HVN1RA221B01
T
COMPONENT DIG INPUT PWB
(
CUP11819Z-4
)
COMP. BN13
nsp nsp
CORD WIRE ASS'Y CWB2B907100EN
COMP. BN29
90M-YJ002800R 90M-YJ002800R
CONN. 3011-DR12-G KJP12GB143ZP
COMP. C601
nsp nsp
CER. CAP. 22PF 50V J HCBS1H220JCT
COMP. C602
nsp nsp
CER. CAP. 22PF 50V J HCBS1H220JCT
COMP. C603
nsp nsp
CER. CAP. 22PF 50V J HCBS1H220JCT
COMP. C604
nsp nsp
CER. CAP. 22PF 50V J HCBS1H220JCT
COMP. C605
nsp nsp
CER. CAP. 22PF 50V J HCBS1H220JCT
COMP. C606
nsp nsp
CER. CAP. 22PF 50V J HCBS1H220JCT
COMP. C607
nsp nsp
CER. CAP. 22PF 50V J HCBS1H220JCT
COMP. C608
nsp nsp
CER. CAP. 22PF 50V J HCBS1H220JCT
COMP. C609
nsp nsp
CER. CAP. 22PF 50V J HCBS1H220JCT
COMP. C610
nsp nsp
CER. CAP. 0.022UF 50V
Z
HCBS1H223ZFT
COMP. C611
nsp 00MOA10701620
ELECT CAP. 100UF 16V ZF CCEA1CH101T
COMP. C612
nsp nsp
CER. CAP. 0.022UF 50V
Z
HCBS1H223ZFT
COMP. C613
nsp 00MOA10701620
ELECT CAP. 100UF 16V ZF CCEA1CH101T
COMP. C614
nsp 00MOA10605020
ELECT CAP. 10UF 50V ZF CCEA1HH100T
COMP. C615
nsp 00MOA10605020
ELECT CAP. 10UF 50V ZF CCEA1HH100T
COMP. C616
nsp 00MOA10605020
ELECT CAP. 10UF 50V ZF CCEA1HH100T
COMP. C617
nsp 00MOA10605020
ELECT CAP. 10UF 50V ZF CCEA1HH100T
COMP. C618
nsp 00MOA10605020
ELECT CAP. 10UF 50V ZF CCEA1HH100T
COMP. C619
nsp 00MOA10605020
ELECT CAP. 10UF 50V ZF CCEA1HH100T
COMP. C620
nsp nsp
CER. CAP. 0.022UF 50V
Z
HCBS1H223ZFT
COMP. C621
nsp nsp
CER. CAP. 0.022UF 50V
Z
HCBS1H223ZFT
COMP. C622
nsp nsp
CER. CAP. 0.022UF 50V
Z
HCBS1H223ZFT
COMP. C630
nsp 00MOA10701620
ELECT CAP. 100UF 16V ZF CCEA1CH101T
COMP. C631
nsp 00MOA10701620
ELECT CAP. 100UF 16V ZF CCEA1CH101T
COMP. C632
nsp 00MOA10701620
ELECT CAP. 100UF 16V ZF CCEA1CH101T
COMP. C633
nsp nsp
CER. CAP. 100PF 50V KB CCKT1H101KB
COMP. C634
nsp nsp
CER. CAP. 100PF 50V KB CCKT1H101KB
COMP. C635
nsp nsp
CER. CAP. 100PF 50V KB CCKT1H101KB
COMP. C636
nsp nsp
CER. CAP. 0.1UF 50V ZF CCFT1H104ZF
COMP. C637
nsp nsp
CER. CAP. 0.1UF 50V ZF CCFT1H104ZF
COMP. C638
nsp nsp
CER. CAP. 0.1UF 50V ZF CCFT1H104ZF
COMP. C639
nsp nsp
CER. CAP. 0.047UF 50V ZF CCKT1H473ZF
COMP. C640
nsp 00MOA10701620
ELECT CAP. 100UF 16V ZF CCEA1CH101T
COMP. J501
nsp nsp
CORD SN95/PB5, 0.6 C3A206
COMP. J502
nsp nsp
CORD SN95/PB5, 0.6 C3A206
COMP. J503
nsp nsp
CORD SN95/PB5, 0.6 C3A206
COMP. J504
nsp nsp
CORD SN95/PB5, 0.6 C3A206
COMP. J505
nsp nsp
CORD SN95/PB5, 0.6 C3A206
COMP. J506
nsp nsp
CORD SN95/PB5, 0.6 C3A206
COMP. J507
nsp nsp
CORD SN95/PB5, 0.6 C3A206
COMP. J531
nsp nsp
CORD SN95/PB5, 0.6 C3A206
COMP. J532
nsp nsp
CORD SN95/PB5, 0.6 C3A206
COMP. J533
nsp nsp
CORD SN95/PB5, 0.6 C3A206
COMP. J561
nsp nsp
CORD SN95/PB5, 0.6 C3A206
COMP. J562
nsp nsp
CORD SN95/PB5, 0.6 C3A206
COMP. J563
nsp nsp
CORD SN95/PB5, 0.6 C3A206
COMP. J564
nsp nsp
CORD SN95/PB5, 0.6 C3A206
COMP. J581
nsp nsp
CORD SN95/PB5, 0.6 C3A206
COMP. J595
nsp nsp
CORD SN95/PB5, 0.6 C3A206
COMP. J601
nsp nsp
CORD SN95/PB5, 0.6 C3A206
COMP. J602
nsp nsp
CORD SN95/PB5, 0.6 C3A206
COMP. J603
nsp nsp
CORD SN95/PB5, 0.6 C3A206
COMP. J606
nsp nsp
CORD SN95/PB5, 0.6 C3A206
COMP. J611
nsp nsp
CORD SN95/PB5, 0.6 C3A206
COMP. J612
nsp nsp
CORD SN95/PB5, 0.6 C3A206
COMP. J613
nsp nsp
CORD SN95/PB5, 0.6 C3A206
COMP. J614
nsp nsp
CORD SN95/PB5, 0.6 C3A206
