Marantz SR4600 - Page 41

55
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
FRONT BN14
nsp nsp
CORD WIRE, ASS'Y CWB1B907230EN
FRONT BN86
90M-YP100220R 90M-YP100220R
CONN. DIP SOCKET KJP07GB145ZP
FRONT C801
nsp 00MOA47601640
ELECT CAP. 47UF 16V CCEA1CH470T
FRONT C802
nsp 00MOA10601620
ELECT CAP. 10UF 16V CCEA1CH100T
FRONT C804
nsp nsp
CER. CAP. 0.01UF 50V Z HCBS1H103ZFT
FRONT C805
nsp nsp
CER. CAP. 100PF 50V
K
HCBS1H101KBT
FRONT C806
nsp 00MOA10705020
ELECT CAP. 100UF 50V CCEA1HH101T
FRONT C807
nsp nsp
CER. CAP. 100PF 50V
K
HCBS1H101KBT
FRONT C809
nsp nsp
CER. CAP. 100PF 50V
K
HCBS1H101KBT
FRONT C810
nsp nsp
CER. CAP. 100PF 50V
K
HCBS1H101KBT
FRONT C811
nsp nsp
CER. CAP. 100PF 50V
K
HCBS1H101KBT
FRONT C812
nsp nsp
CER. CAP. 0.1UF 50V Z HCBS1H104ZFT
FRONT C813
nsp 00MOA10701020
ELECT CAP. 100UF 10V CCEA1AH101T
FRONT C814
nsp nsp
CER. CAP. 100PF 50V
K
HCBS1H101KBT
FRONT C815
nsp nsp
CER. CAP. 100PF 50V
K
HCBS1H101KBT
FRONT C816
nsp nsp
CER. CAP. 100PF 50V
K
HCBS1H101KBT
FRONT C817
nsp nsp
CER. CAP. 100PF 50V
K
HCBS1H101KBT
FRONT C818
nsp nsp
CER. CAP. 100PF 50V
K
HCBS1H101KBT
FRONT C820
nsp nsp
CER. CAP. 100PF 50V
K
HCBS1H101KBT
FRONT C821
nsp 00MOA10605020
ELECT CAP. 10UF 50V ZF CCEA1HH100T
FRONT C822
nsp nsp
CER. CAP. 100PF 50V
K
HCBS1H101KBT
FRONT C824
nsp nsp
CER. CAP. 0.1UF 50V Z HCBS1H104ZFT
FRONT C825
nsp nsp
CER. CAP. 390PF 50V KB HCBS1H391KBT
FRONT C826
nsp nsp
CER. CAP. 100PF 50V
K
HCBS1H101KBT
FRONT C827
nsp nsp
CER. CAP. 100PF 50V KB CCKT1H101KB
FRONT C828
nsp 00MOA47601640
ELECT CAP. 47UF 16V CCEA1CH470T
FRONT CN83
nsp nsp
CONN. WAFER, CARD CABLE CJP15GA117Z
Y
FRONT EN81
90M-SR000240R 90M-SR000240R
ROTARY SW EC16B243040HB HSR2A004Z
FRONT FIP1
90M-HQ300620R 90M-HQ300620R
DISPLAY 16-BT-110GN
K
HFL16BT110GN
K
FRONT IC51
00MHC10210090 00MHC10210090
IC NJM2296M HVINJM2296M
FRONT IC52
00MHC10210090 00MHC10210090
IC NJM2296M HVINJM2296M
FRONT IC53
00MHC10210090 00MHC10210090
IC NJM2296M HVINJM2296M
FRONT IC54
90M-HC108890R 90M-HC108890R
IC HCF4053M013
T
HVIHCF4053M013
T
FRONT IC55
90M-HC108850R 90M-HC108850R
IC R59-4174 HVIMM1511XNRE
FRONT IC61
00MHC10236090 00MHC10236090
IC NJM2586AM HVINJM2586AMTE1
FRONT IC62
90M-HC700550R 90M-HC700550R
IC TC74HCU04AFNG
(
T HVI74HCU04AFNG
FRONT IC81
00MHC10220090 00MHC10220090
IC NJU3430F HVINJU3430F
FRONT J803
nsp nsp
CORD SN95/PB5, 0.6 C3A206
FRONT J804
nsp nsp
CORD SN95/PB5, 0.6 C3A206
FRONT J805
nsp nsp
CORD SN95/PB5, 0.6 C3A206
FRONT J806
nsp nsp
CORD SN95/PB5, 0.6 C3A206
FRONT J807
nsp nsp
CORD SN95/PB5, 0.6 C3A206
FRONT J809
nsp nsp
CORD SN95/PB5, 0.6 C3A206
FRONT J810
nsp nsp
CORD SN95/PB5, 0.6 C3A206
FRONT J811
nsp nsp
CORD SN95/PB5, 0.6 C3A206
FRONT J812
nsp nsp
CORD SN95/PB5, 0.6 C3A206
FRONT J813
nsp nsp
CORD SN95/PB5, 0.6 C3A206
FRONT J814
nsp nsp
CORD SN95/PB5, 0.6 C3A206
FRONT J815
nsp nsp
CORD SN95/PB5, 0.6 C3A206
FRONT J816
nsp nsp
CORD SN95/PB5, 0.6 C3A206
FRONT J817
nsp nsp
CORD SN95/PB5, 0.6 C3A206
FRONT J818
nsp nsp
CORD SN95/PB5, 0.6 C3A206
FRONT J821
nsp nsp
CORD SN95/PB5, 0.6 C3A206
FRONT J822
nsp nsp
CORD SN95/PB5, 0.6 C3A206
FRONT J823
nsp nsp
CORD SN95/PB5, 0.6 C3A206
FRONT J824
nsp nsp
CORD SN95/PB5, 0.6 C3A206
FRONT J825
nsp nsp
CORD SN95/PB5, 0.6 C3A206
FRONT J826
nsp nsp
CORD SN95/PB5, 0.6 C3A206
FRONT J827
nsp nsp
CORD SN95/PB5, 0.6 C3A206
FRONT J828
nsp nsp
CORD SN95/PB5, 0.6 C3A206
FRONT J841
nsp nsp
CORD SN95/PB5, 0.6 C3A206
FRONT J842
nsp nsp
CORD SN95/PB5, 0.6 C3A206
FRONT J843
nsp nsp
CORD SN95/PB5, 0.6 C3A206
FRONT J844
nsp nsp
CORD SN95/PB5, 0.6 C3A206
FRONT J845
nsp nsp
CORD SN95/PB5, 0.6 C3A206
FRONT J846
nsp nsp
CORD SN95/PB5, 0.6 C3A206
FRONT J851
nsp nsp
CORD SN95/PB5, 0.6 C3A206
