NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
INPUT D411
nsp 00MHD20015210
DIODE 1SS133T-77 HVD1SS133M
T
INPUT D412
nsp 00MHD20015210
DIODE 1SS133T-77 HVD1SS133M
T
INPUT D413
nsp 00MHD20015210
DIODE 1SS133T-77 HVD1SS133M
T
INPUT D414
nsp 00MHD20015210
DIODE 1SS133T-77 HVD1SS133M
T
INPUT D415
nsp 00MHD20015210
DIODE 1SS133T-77 HVD1SS133M
T
INPUT D416
nsp 00MHD20015210
DIODE 1SS133T-77 HVD1SS133M
T
INPUT D417
nsp 00MHD20015210
DIODE 1SS133T-77 HVD1SS133M
T
INPUT D418
nsp 00MHD20015210
DIODE 1SS133T-77 HVD1SS133M
T
INPUT D419
nsp 00MHD20015210
DIODE 1SS133T-77 HVD1SS133M
T
INPUT D420
nsp 00MHD20015210
DIODE 1SS133T-77 HVD1SS133M
T
INPUT D421
nsp 00MHD20015210
DIODE 1SS133T-77 HVD1SS133M
T
INPUT D422
nsp 00MHD20015210
DIODE 1SS133T-77 HVD1SS133M
T
INPUT D423
nsp 00MHD20015210
DIODE 1SS133T-77 HVD1SS133M
T
INPUT D424
nsp 00MHD20015210
DIODE 1SS133T-77 HVD1SS133M
T
INPUT D425
nsp 00MHD20015210
DIODE 1SS133T-77 HVD1SS133M
T
INPUT D426
nsp 00MHD20015210
DIODE 1SS133T-77 HVD1SS133M
T
INPUT D427
nsp 00MHD20015210
DIODE 1SS133T-77 HVD1SS133M
T
INPUT D428
nsp 00MHD20015210
DIODE 1SS133T-77 HVD1SS133M
T
INPUT D451
nsp 00MHD20015210
DIODE 1SS133T-77 HVD1SS133M
T
INPUT D452
nsp 00MHD20015210
DIODE 1SS133T-77 HVD1SS133M
T
INPUT IC11
90M-HC108920R 90M-HC108920R
IC CS42428CQ HVICS42428CQ
INPUT IC12
90M-HC700550R 90M-HC700550R
IC TC74HCU04AFNG
(
T HVI74HCU04AFNG
INPUT IC13
00MHC10418030 00MHC10418030
IC LC89057W-VF4-E HVILC89057WVF4E
INPUT IC15
90M-HC108910R 90M-HC108910R
IC 74VHC08 HVI74VHC08TTR
INPUT IC16
90M-HC108930R 90M-HC108930R
IC 74LCX32 HVI74LCX32TTR
INPUT IC17
90M-HC108910R 90M-HC108910R
IC 74VHC08 HVI74VHC08TTR
INPUT IC18
90M-HC108430R 90M-HC108430R
IC TC74HC7007AFE
L
HVITC74HCT7007F
INPUT IC19
00MHC10014880 00MHC10014880
IC CS49400-CQ HVICS49400-CQ
INPUT IC20
90M-HS42BWX0R 90M-HS42BWX0R
IC MX29LV400TTC-70 HVIMX29LV400TTC
INPUT IC21
00MHC10102090 00MHC10102090
IC NJM2068MD-TE1 HVINJM2068MDTE1
INPUT IC22
00MHC10102090 00MHC10102090
IC NJM2068MD-TE1 HVINJM2068MDTE1
INPUT IC23
00MHC10102090 00MHC10102090
IC NJM2068MD-TE1 HVINJM2068MDTE1
INPUT IC24
00MHC10102090 00MHC10102090
IC NJM2068MD-TE1 HVINJM2068MDTE1
INPUT IC26
90M-HC300670R 90M-HC300670R
IC L7808 HVIL7808CP
INPUT IC27
00MHC3990809
F
00MHC3990809
F
IC NJM7908 HVINJM7908F
A
INPUT IC31
90M-HC108900R 90M-HC108900R
IC NJW1157FC2 HVINJW1157FC2
INPUT IC32
00MHC10102090 00MHC10102090
IC NJM2068MD-TE1 HVINJM2068MDTE1
INPUT IC33
00MHC10102090 00MHC10102090
IC NJM2068MD-TE1 HVINJM2068MDTE1
INPUT IC34
00MHC10102090 00MHC10102090
IC NJM2068MD-TE1 HVINJM2068MDTE1
INPUT IC35
00MHC10102090 00MHC10102090
IC NJM2068MD-TE1 HVINJM2068MDTE1
INPUT IC41
90M-HS42BWH0R 90M-HS42BWH0R
IC HD64F2398F20 HVIHD64F2398F20
INPUT IC42
00MHC10099540 00MHC10099540
IC S-80145ALMC HVIS-80145ALMC
INPUT IC43
90M-HC108390R 90M-HC108390R
IC AT24C08N10SC2.7 HVIAT24C08N10SC
INPUT IC45
90M-HC900070R 90M-HC900070R
IC NJM2391DL133 HVINJM2391DL133
INPUT IC46
90M-HC900060R 90M-HC900060R
IC NJM2391DL125 HVINJM2391DL125
INPUT J101
nsp nsp
CORD SN95/PB5, 0.6 C3A206
INPUT J102
nsp nsp
CORD SN95/PB5, 0.6 C3A206
INPUT JK31
90M-YT004010R 90M-YT004010R
TERMINAL CINCH 6P AUDIO CJJ4R019
W
INPUT JK32
90M-YT003970R 90M-YT003970R
TERMINAL CINCH JACK 4P AUDIO CJJ4P014
W
INPUT JK33
90M-YT003970R 90M-YT003970R
TERMINAL CINCH JACK 4P AUDIO CJJ4P014
W
INPUT JK34
90M-YT004010R 90M-YT004010R
TERMINAL CINCH 6P AUDIO CJJ4R019
W
INPUT JK35
90M-YT003960R 90M-YT003960R
TERMINAL CINCH JACK 6P AUDIO CJJ4R037
W
INPUT JK36
90M-YT003970R 90M-YT003970R
TERMINAL CINCH JACK 4P AUDIO CJJ4P014
W
INPUT L101
90M-FC900340R 90M-FC900340R
FERRITE CORE HU-1H4516-600J
T
HLZ9Z014Z
INPUT L111
90M-FN000090R 90M-FN000090R
FERRITE CORE BEAD, CORE KLZ9H001Z
INPUT L112
90M-FN000090R 90M-FN000090R
FERRITE CORE BEAD, CORE KLZ9H001Z
INPUT L113
90M-FN000090R 90M-FN000090R
FERRITE CORE BEAD, CORE KLZ9H001Z
INPUT Q301
00MHT805501B0 00MHT805501B0
TRS. KTC2874B HVTKTC2874B
T
INPUT Q302
00MHT805501B0 00MHT805501B0
TRS. KTC2874B HVTKTC2874B
T
INPUT Q303
00MHT805501B0 00MHT805501B0
TRS. KTC2874B HVTKTC2874B
T
INPUT Q304
00MHT805501B0 00MHT805501B0
TRS. KTC2874B HVTKTC2874B
T
INPUT Q305
00MHT805501B0 00MHT805501B0
TRS. KTC2874B HVTKTC2874B
T
INPUT Q306
00MHT805501B0 00MHT805501B0
TRS. KTC2874B HVTKTC2874B
T
INPUT Q307
00MHT805501B0 00MHT805501B0
TRS. KTC2874B HVTKTC2874B
T
INPUT Q308
00MHT805501B0 00MHT805501B0
TRS. KTC2874B HVTKTC2874B
T
INPUT Q309
90M-HX900010R 90M-HX900010R
CHIP TRS. KTD1304 HVTKTD1304T
INPUT Q310
90M-HX900010R 90M-HX900010R
CHIP TRS. KTD1304 HVTKTD1304T
