Marantz SR4600 - Page 67

81
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
MAIN R682
nsp nsp
RES. 910 OHM 1/5W J CRD20TJ911
T
MAIN R683
nsp nsp
RES. 910 OHM 1/5W J CRD20TJ911
T
MAIN R684
nsp nsp
RES. 910 OHM 1/5W J CRD20TJ911
T
MAIN R685
nsp nsp
RES. 910 OHM 1/5W J CRD20TJ911
T
MAIN R686
nsp nsp
RES. 22K OHM 1/5W J CRD20TJ223
T
MAIN R687
nsp nsp
RES. 22K OHM 1/5W J CRD20TJ223
T
MAIN R688
nsp nsp
RES. 22K OHM 1/5W J CRD20TJ223
T
MAIN R689
nsp nsp
RES. 22K OHM 1/5W J CRD20TJ223
T
MAIN R690
nsp nsp
RES. 22K OHM 1/5W J CRD20TJ223
T
MAIN R696
nsp nsp
RES. 47 OHM 1/4W J CRD25TJ470
T
MAIN R697
nsp nsp
RES. 47 OHM 1/4W J CRD25TJ470
T
MAIN R698
nsp nsp
RES. 47 OHM 1/4W J CRD25TJ470
T
MAIN R699
nsp nsp
RES. 47 OHM 1/4W J CRD25TJ470
T
MAIN R700
nsp nsp
RES. 47 OHM 1/4W J CRD25TJ470
T
MAIN R771
nsp nsp
RES. 75 OHM 1/5W J CRD20TJ750
T
MAIN R772
nsp nsp
RES. 75 OHM 1/5W J CRD20TJ750
T
MAIN R773
nsp nsp
RES. 75 OHM 1/5W J CRD20TJ750
T
MAIN R774
nsp nsp
RES. 75 OHM 1/5W J CRD20TJ750
T
MAIN R775
nsp nsp
RES. 75 OHM 1/5W J CRD20TJ750
T
MAIN R776
nsp nsp
RES. 75 OHM 1/5W J CRD20TJ750
T
MAIN R777
nsp nsp
RES. 75 OHM 1/5W J CRD20TJ750
T
MAIN R781
nsp nsp
RES. 75 OHM 1/5W J CRD20TJ750
T
MAIN R782
nsp nsp
RES. 75 OHM 1/5W J CRD20TJ750
T
MAIN R783
nsp nsp
RES. 75 OHM 1/5W J CRD20TJ750
T
MAIN R784
nsp nsp
RES. 75 OHM 1/5W J CRD20TJ750
T
MAIN R785
nsp nsp
RES. 75 OHM 1/5W J CRD20TJ750
T
MAIN R786
nsp nsp
RES. 75 OHM 1/5W J CRD20TJ750
T
MAIN R787
nsp nsp
RES. 75 OHM 1/5W J CRD20TJ750
T
MAIN R801
nsp nsp
RES. 22K OHM 1/5W J CRD20TJ223
T
MAIN R802
nsp nsp
RES. 22K OHM 1/5W J CRD20TJ223
T
MAIN R803
nsp nsp
RES. 910 OHM 1/5W J CRD20TJ911
T
MAIN R804
nsp nsp
RES. 910 OHM 1/5W J CRD20TJ911
T
MAIN R805
nsp nsp
RES. 1K OHM 1/5W J CRD20TJ102
T
MAIN R807
nsp nsp
RES. 1K OHM 1/5W J CRD20TJ102
T
MAIN R808
nsp nsp
RES. 1K OHM 1/5W J CRD20TJ102
T
MAIN R809
nsp nsp
RES. 1K OHM 1/5W J CRD20TJ102
T
MAIN R810
90M-GO000013R 90M-GO000013R
RES. 0.27 OHM
(
*2
)
5
W
CRF5EKR27HX2
K
MAIN R811
90M-GO000013R 90M-GO000013R
RES. 0.27 OHM
(
*2
)
5
W
CRF5EKR27HX2
K
MAIN R812
nsp nsp
RES. 47 OHM 1/4W J CRD25TJ470
T
MAIN R813
nsp nsp
RES. 47 OHM 1/4W J CRD25TJ470
T
MAIN R814
nsp nsp
RES. 47 OHM 1/4W J CRD25TJ470
T
MAIN R815
nsp nsp
RES. 47 OHM 1/4W J CRD25TJ470
T
MAIN R817
nsp nsp
RES. 3.3 OHM 1/4
W
KRD25FJ3R3
T
MAIN R818
nsp nsp
RES. 3.3 OHM 1/4
W
KRD25FJ3R3
T
MAIN R819
nsp nsp
RES. 3.3 OHM 1/4
W
KRD25FJ3R3
T
MAIN R820
nsp nsp
RES. 3.3 OHM 1/4
W
KRD25FJ3R3
T
MAIN R821
nsp nsp
RES. 18 OHM 1/4
W
KRD25FJ180
T
MAIN R822
nsp nsp
RES. 18 OHM 1/4
W
KRD25FJ180
T
MAIN R823
nsp nsp
RES. 18 OHM 1/4
W
KRD25FJ180
T
MAIN R824
nsp nsp
RES. 18 OHM 1/4
W
KRD25FJ180
T
MAIN R830
nsp nsp
RES. 22K OHM 1/5W J CRD20TJ223
T
MAIN R831
nsp nsp
RES. 22K OHM 1/5W J CRD20TJ223
T
MAIN R832
nsp nsp
RES. 22K OHM 1/5W J CRD20TJ223
T
MAIN R833
nsp nsp
RES. 22K OHM 1/5W J CRD20TJ223
T
MAIN R834
nsp nsp
RES. 560 OHM 1/5W J CRD20TJ561
T
MAIN R835
nsp nsp
RES. 560 OHM 1/5W J CRD20TJ561
T
MAIN R836
nsp nsp
RES. 560 OHM 1/5W J CRD20TJ561
T
MAIN R837
nsp nsp
RES. 560 OHM 1/5W J CRD20TJ561
T
MAIN R838
nsp nsp
RES. 560 OHM 1/5W J CRD20TJ561
T
MAIN R839
nsp nsp
RES. 560 OHM 1/5W J CRD20TJ561
T
MAIN R840
nsp nsp
RES. 560 OHM 1/5W J CRD20TJ561
T
MAIN R841
nsp nsp
RES. 560 OHM 1/5W J CRD20TJ561
T
MAIN R842
nsp nsp
RES. 560 OHM 1/5W J CRD20TJ561
T
MAIN R843
nsp nsp
RES. 560 OHM 1/5W J CRD20TJ561
T
MAIN R844
nsp nsp
RES. 560 OHM 1/5W J CRD20TJ561
T
MAIN R845
nsp nsp
RES. 560 OHM 1/5W J CRD20TJ561
T
MAIN R848
nsp nsp
RES. 33K OHM 1/5W J CRD20TJ333
T
