SR5001 RS-232C Control Specification Page: 9 / 20
Document Version [1.0]
Company Restricted
5. Definitions of Command, Status and Layer
This section is told how to define “Command”, “Status” and “Layer” of this product.
5-1. Normal Command list
5-1-1. Main function contents
Command Reply from Slave
TOGGLE “PWR:0”
OFF “PWR:1”
POWER
ON “PWR:2”
“PWR:1”
“PWR:2”
TOGGLE “ATT:0”
OFF “ATT:1”
AUDIO ATT
ON “ATT:2”
“ATT:0”(None)
“ATT:1”(OFF)
“ATT:2”(ON)
TOGGLE “AMT:0”
OFF “AMT:1”
AUDIO MUTE
ON “AMT:2”
“AMT:1”
“AMT:2”
TOGGLE “VMT:0”
OFF “VMT:1”
VIDEO MUTE
ON “VMT:2”
“VMT:1”
“VMT:2”
VALUE “VOL:0xxx”
UP “VOL:1”
VOLUME
DOWN “VOL:2”
“VOL:xxx”
xxx = Vol. value as +18 ~ -99,
0db = ”VOL: 00”, -∞ = “VOL:-ZZ”
VALUE “TOB:0xxx”
UP “TOB:1”
TONE BASS
DOWN “TOB:2”
“TOB:xxx”
xxx = vol. value as +6 ~-6
VALUE “TOT:0xxx”
UP “TOT:1”
TONE TREBLE
DOWN “TOT:2”
“TOT:xxx”
xxx = vol. value as +6 ~-6
TV “SRC:1”
DVD “SRC:2”
VCR1 “SRC:3”
DSS/VCR2
“SRC:5”
AUX1 “SRC:9”
AUX2 “SRC:A”
CD “SRC:C”
CD-R “SRC:D”
TAPE “SRC:E”
TUNER “SRC:F”
FM “SRC:G”
AM “SRC:H”
SOURCE Select
XM “SRC:J”
“SRC:va”, (v ,a= ‘0’ – ‘I’)
(v = video, a = audio.)
v = 0 (V-OFF)
a = N (7.1CH)
TOGGLE “71C:0”
OFF “71C:1”
7.1 Channel Input
ON “71C:2”
“71C:1” (OFF)
“71C:2” (ON)
To Next Page
