Example connections when using front height speakers
This 7.1-channel surround system is the same as a basic 5.1-channel system but with front height speakers.
.
FL
SW C
SL
FHR
FR
SR
FHL
0
Set “Assign Mode” to “Front Height” in the menu. (v p. 215)
.
SW
FHR FHL
FLFR C SR SL
