56
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
C435
nsp ELECT 4.7
µ
F-M/50V 5*11 nsp
C438
C439
nsp ELECT 1
µ
F-M/50V 5*11-5RE nsp
C440
nsp ELECT 1
µ
F-M/50V 5*11-5RE nsp
C441
nsp ELECT 4.7
µ
F-M/50V 5*11 nsp
C444
C445
nsp CER. B100pF-K/50V-52RE nsp
C446
nsp CER. B100pF-K/50V-52RE nsp
C447
nsp CER. B100pF-K/50V-52RE nsp
C464
nsp
nsp CER. 0.01
µ
F-M/16V-52RE nsp
C467
nsp
C498
nsp CER. F0.1
µ
F-Z/50V-52RE nsp
C499
nsp CER. F0.1
µ
F-Z/50V-52RE nsp
CLAMP
101
nsp CLAMP HMX9800 DARA-2
(W=2.6 L=50)/WIRE(SOLDER)
nsp
CLAMP
102
nsp CLAMP HMX9800 DARA-2
(W=2.6 L=50)/WIRE(SOLDER)
nsp
CN107
nsp CN.WAFER 2.0MM
TUC-P10X-B1 BD-TO-BD
10P HOUSING ST (35237-10)
nsp
CN108
nsp CN.WAFER 2.0MM
TUC-P20X-B1 BD-TO-BD
20P HOUSING ST (35237-20)
nsp
CP130
nsp CN WIRE 570MM/4P
5264-04=51088-04 RD1007#22
nsp
CP301I
nsp CN.WAFER 2.0MM
G1L-S-3P-S2T2-EF
nsp
INPUT1 - RESISTORS
R433
nsp 470-J 1/6W-52RE-AX nsp
R449
R466
nsp 150-J 1/6W-52RE-AX nsp
R467
nsp 4.7-J 1/6W-52RE-AX nsp
R468
nsp 150-J 1/6W-52RE-AX nsp
R469
nsp 150-J 1/6W-52RE-AX nsp
R470
nsp 150-J 1/6W-52RE-AX nsp
R471
nsp 470K-J 1/6W-52RE-AX nsp
R474
R475
nsp 4.7-J 1/6W-52RE-AX nsp
R481
nsp 470K-J 1/6W-52RE-AX nsp
R484
R487
nsp 150-J 1/6W-52RE-AX nsp
R490
R495
nsp 470K-J 1/6W-52RE-AX nsp
R498
R503
nsp 1K-J 1/6W-52RE-AX nsp
R504
nsp 1K-J 1/6W-52RE-AX nsp
R505
nsp 1K-J 1/6W-52RE-AX nsp
R536
4822 053 10331 RES MF 330 2W 5% GA05331010
R537
4822 053 10331 RES MF 330 2W 5% GA05331010
INPUT1 - SEMICONDUCTORS
IC401
9965 000 10989 IC TC9274N-011 SDIP42-P-600
ANALOG SW
*HC107320R
IC403
4822 209 73064 IC NJM2068DD-DIP8P HC10053090
IC404
4822 209 73064 IC NJM2068DD-DIP8P HC10053090
INPUT1 - MISCELLANEOUS
WIRE401
nsp RING TER WIRE nsp
INPUT2 CIRCUIT BOARD
INPUT2 - CAPACITORS
C448
K nsp CER. B100pF-K/50V-52RE nsp
C453
C462
nsp CER. 0.01
µ
F-M/16V-52RE nsp
C463A
nsp CER. F0.1
µ
F-Z/50V-52RE nsp
C468
nsp CER. F0.1
µ
F-Z/50V-52RE nsp
C599
nsp CER. F0.1
µ
F-Z/50V-52RE nsp
INPUT2 - RESISTORS
R517
nsp 470-J 1/6W-52RE-AX nsp
R522
R535
nsp 47-J 1/6W-52RE-AX nsp
INPUT2 - SEMICONDUCTORS
D501
4822 130 32778 DIODE 1SS133T-72-52MM HD20015210
D502
4822 130 32778 DIODE 1SS133T-72-52MM HD20015210
INPUT2 - MISCELLANEOUS
CN109
nsp CN.WAFER 2.0MM
TUC-P04X-B1 BD-TO-BD
4P HOUSING ST (35237-04)
nsp
CN110
nsp CN.WAFER 2.0MM
TUC-P11X-B1 BD-TO-BD
11P HOUSING ST (35237-11)
nsp
POWER S
W
CIRCUIT BOARD
POWER S
W
-MISCELLANEOUS
CNT401
K nsp CN WIRE 500MM 2P 35156-03
JE201-03 BK1617#22 7.92
nsp
VIDEO CIRCUIT BOARD
VIDEO - CAPACITORS
C840U
U p CER. 20pF-J/50V-5RE nsp
C841U
U p CER. 20pF-J/50V-5RE nsp
C871
nsp CER.CHIP 47pF-J/50V-1608 nsp
C873
nsp ELECT 470
µ
F-M/6.3V 8*11.5-5 nsp
C874
nsp CER.CHIP 47pF-J/50V-1608 nsp
C875
nsp ELECT 470
µ
F-M/6.3V 8*11.5-5 nsp
C876
nsp CER.CHIP 47pF-J/50V-1608 nsp
C877
nsp ELECT 470
µ
F-M/6.3V 8*11.5-5 nsp
C878
nsp ELECT 10
µ
F-M/50V 5*11-5RE nsp
C881
C882
nsp ELECT 47
µ
F-M/16V 5*11 nsp
C883
nsp CER.CHIP 0.1
µ
F-K/50V-1608 nsp
C884
nsp CER.CHIP 0.1
µ
F-K/50V-1608 nsp
C885
nsp ELECT 47
µ
F-M/16V 5*11 nsp
C886
nsp ELECT 10
µ
F-M/50V 5*11-5RE nsp
C887
nsp CER.CHIP 100pF-J/50V-1608 nsp
C888
nsp CER. 0.01
µ
F-M/16V-52RE nsp
C889
nsp ELECT 100
µ
F-M/10V 5*11-5RE nsp
C890
nsp CER. 0.001
µ
F-K/50V-52RE nsp
C891
nsp ELECT 2.2
µ
F-M/50V 5*11-5RE nsp
C892
nsp CER.CHIP 100pF-J/50V-1608 nsp
C894
nsp ELECT 10
µ
F-M/50V 5*11-5RE nsp
C895
nsp ELECT 10
µ
F-M/50V 5*11-5RE nsp
C896
nsp CER.CHIP 100pF-J/50V-1608 nsp
VIDEO - RESISTORS
J911
nsp CHIP 0-J 1/16W-1608 nsp
J916
R838
nsp CHIP 3.3K-J 1/16W-1608 nsp
ns
ns
