57
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
R843U
U p 470-J 1/6W-52RE-AX nsp
R844U
U p 1M-J 1/6W-52RE-AX nsp
R864
nsp 1K-J 1/6W-52RE-AX nsp
R865
nsp 1K-J 1/6W-52RE-AX nsp
R871
nsp CHIP 10K-J 1/16W-1608 nsp
R873
nsp CHIP 47-J 1/16W-1608 nsp
R874
nsp 1K-J 1/6W-52RE-AX nsp
R875
nsp CHIP 10K-J 1/16W-1608 nsp
R876
nsp CHIP 56-J 1/16W-1608 nsp
R877
nsp CHIP 10K-J 1/16W-1608 nsp
R878
nsp CHIP 75-J 1/16W-1608 nsp
R879
nsp CHIP 56-J 1/16W-1608 nsp
R880
nsp CHIP 75-J 1/16W-1608 nsp
R881
nsp CHIP 75-J 1/16W-1608 nsp
R882
nsp CHIP 75-J 1/16W-1608 nsp
R883
nsp 2.2K-J 1/6W-52RE-AX nsp
R884
nsp 1-J 1/6W-52RE-AX nsp
R885
nsp CHIP 2.2-J 1/16W-1608 nsp
R886
nsp CHIP 47K-J 1/16W-1608 nsp
R889
nsp 33K-J 1/6W-52RE-AX nsp
R890
nsp 68-J 1/6W-52RE-AX nsp
R891
nsp 2.2K-J 1/6W-52RE-AX nsp
R897
nsp CHIP 10K-J 1/16W-1608 nsp
R899
nsp 1K-J 1/6W-52RE-AX nsp
VIDEO - SEMICONDUCTORS
D870
4822 130 32778 DIODE 1SS133T-72-52MM HD20015210
D871
9965 000 10747 DIODE CHIP KDS160 *HD201560R
D872
4822 130 32778 DIODE 1SS133T-72-52MM HD20015210
D873
4822 130 32778 DIODE 1SS133T-72-52MM HD20015210
D884
4822 130 32778 DIODE 1SS133T-72-52MM HD20015210
J902
K p JUMPER (0.6/52MM) nsp
J904
K p JUMPER (0.6/52MM) nsp
J905
K p JUMPER (0.6/52MM) nsp
IC805
4822 130 91429 IC M35010-001SP
ON SCREEN DISP DIP20
*HC107310R
IC806
9965 000 10990 IC BA7046 VIDEO SYNC DIP8 *HC107230R
IC872
9965 000 03394 IC NJM2296M
VIDEO SW SOP16
HC10210090
IC874
4822 209 90218 IC BU4094BCF-E2
SHIFT RESISTOR SOP16
*HC400010R
Q821
4822 130 60107 TRS.2SA933S 0.3W/TO92M *HT100610R
Q822
9965 000 10445 TRS.2SC KTC2874B TO92 *HT300880R
Q870
9965 000 10444 TRS. NPN RC KRC107M 0.4W/
TO92M
*BA001190R
Q871
4822 130 62787 TRS. PNP RB TR KRA107M *BA000190R
VIDEO - MISCELLANEOUS
CN106
nsp CN.WAFER 2.0MM
TUC-P15X-B1 BD-TO-BD
15P HOUSING ST (35237-15)
nsp
CN105
nsp CN.WAFER 2.0MM
TUC-P09X-B1 BD-TO-BD
9P HOUSING ST (35237-09)
nsp
CP301S
nsp CN.WAFER 2.5MM5267-02A 2P nsp
CP301SV
nsp CN.WAFER 2.0MM
G1L-S-4P-S2T2-EF
nsp
CP301V
nsp CN.WAFER 2.0MM
GIL-S-2P-S2T2-EF
nsp
XTAL801
U p CRYSTAL 14.31818MHZ
HC49U-CL;18pF-S.BLK
*JX000780R
XTAL802
K p CRYSTAL 17.734475MHz
HC/49U CL;18pF-S.BLK
*JX000790R
XTAL803
K p CRYSTAL 14.31818MHZ
HC49U-CL;18pF-S.BLK
*JX000780R
S-VIDEO CIRCUIT BOARD
S-VIDEO - CAPACITORS
C801
nsp ELECT 10
µ
F-M/50V 5*11-5RE nsp
C802
nsp ELECT 470
µ
F-M/6.3V 8*11.5-5 nsp
C802N
nsp CER.CHIP 47pF-J/50V-1608 nsp
C803
nsp ELECT 10
µ
F-M/50V 5*11-5RE nsp
C803N
nsp CER.CHIP 47pF-J/50V-1608 nsp
C804
nsp ELECT 470
µ
F-M/6.3V 8*11.5-5 nsp
C804N
nsp CER.CHIP 47pF-J/50V-1608 nsp
C805
nsp ELECT 470
µ
F-M/6.3V 8*11.5-5 nsp
C805N
nsp CER.CHIP 47pF-J/50V-1608 nsp
C806
nsp ELECT 10
µ
F-M/50V 5*11-5RE nsp
C806N
nsp CER.CHIP 47pF-J/50V-1608 nsp
C807
nsp ELECT 4.7
µ
F-M/50V 5*11 nsp
C807N
nsp CER.CHIP 47pF-J/50V-1608 nsp
C808
nsp ELECT 4.7
µ
F-M/50V 5*11 nsp
C809
nsp ELECT 10
µ
F-M/50V 5*11-5RE nsp
C810
nsp ELECT 10
µ
F-M/50V 5*11-5RE nsp
C811
nsp ELECT 10
µ
F-M/50V 5*11-5RE nsp
C812
nsp ELECT 4.7
µ
F-M/50V 5*11 nsp
C813
nsp ELECT 4.7
µ
F-M/50V 5*11 nsp
C814
nsp ELECT 10
µ
F-M/50V 5*11-5RE nsp
C815
nsp ELECT 10
µ
F-M/50V 5*11-5RE nsp
C816
nsp ELECT 47
µ
F-M/16V 5*11 nsp
C817
nsp CER.CHIP 0.01
µ
F-Z/50V-1608 nsp
C818
nsp CER. 0.01
µ
F-M/16V-52RE nsp
C820
nsp ELECT 47
µ
F-M/16V 5*11 nsp
C821
nsp CER.CHIP 0.01
µ
F-Z/50V-1608 nsp
C822
nsp ELECT 100
µ
F-M/10V 5*11-5RE nsp
C823
nsp ELECT 10
µ
F-M/50V 5*11-5RE nsp
C824
nsp CER. 0.01
µ
F-M/16V-52RE nsp
C825
nsp ELECT 2.2
µ
F-M/50V 5*11-5RE nsp
C826
nsp CER. 0.001
µ
F-K/50V-52RE nsp
C827
nsp ELECT 2.2
µ
F-M/50V 5*11-5RE nsp
C828
nsp ELECT 10
µ
F-M/50V 5*11-5RE nsp
C829
nsp ELECT 10
µ
F-M/50V 5*11-5RE nsp
C831
nsp CER.CHIP 100pF-J/50V-1608 nsp
C832
nsp ELECT 10
µ
F-M/50V 5*11-5RE nsp
C833
nsp CER.CHIP 0.01
µ
F-Z/50V-1608 nsp
C834
nsp ELECT 100
µ
F-M/10V 5*11-5RE nsp
C835
nsp CER. 47pF-J/50V-52RE nsp
C836
nsp ELECT 1
µ
F-M/50V 5*11-5RE nsp
C837
nsp CER. 20pF-J/50V-5RE nsp
C838
nsp CER.CHIP 100pF-J/50V-1608 nsp
C839
nsp ELECT 100
µ
F-M/10V 5*11-5RE nsp
C841A
nsp CER.CHIP 0.01
µ
F-Z/50V-1608 nsp
C842
nsp CER.CHIP 0.01
µ
F-Z/50V-1608 nsp
C842A
nsp CER.CHIP 0.01
µ
F-Z/50V-1608 nsp
C843
nsp CER. 20pF-J/50V-5RE nsp
C843A
nsp CER. 22pF-J/50V-52RE nsp
C844
nsp ELECT 100
µ
F-M/10V 5*11-5RE nsp
C845
nsp CER. 0.001
µ
F-K/50V-52RE nsp
C845A
nsp ELECT 47
µ
F-M/25V 5*11-5RE nsp
C846
nsp ELECT 1
µ
F-M/50V 5*11-5RE nsp
C847
nsp CER.CHIP 100pF-J/50V-1608 nsp
C848
nsp CER.CHIP 2200pF-K/50V-1608 nsp
C849
nsp ELECT 1
µ
F-M/50V 5*11-5RE nsp
C849A
nsp CER.CHIP 0.01
µ
F-Z/50V-1608 nsp
C850
K p CER. 22pF-J/50V-5RE nsp
C850A
nsp CER.CHIP 0.01
µ
F-Z/50V-1608 nsp
C851
K p CER. 22pF-J/50V-5RE nsp
C852
K p CER. 22pF-J/50V-5RE nsp
C853
K p CER. 22pF-J/50V-5RE nsp
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
